VIDEO PHONE CAMERA DRC-40BS/40CS
Thank you for purchasing COMMAX products.
Please carefully read this User's Guide (in particular, precautions for safety) before using a product and follow
instructions to use a product exactly.
The company is not responsible for any safety accidents caused by abnormal operation of the product.
Advertisement
Table of Contents
Related Manuals for Commax DRC-40BS
Summary of Contents for Commax DRC-40BS
-
Page 1: User Manual
User Manual VIDEO PHONE CAMERA DRC-40BS/40CS Thank you for purchasing COMMAX products. Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow instructions to use a product exactly. The company is not responsible for any safety accidents caused by abnormal operation of the product. -
Page 2: Table Of Contents
Contents 1. Introdution............. 3 2. Important Safeguard ........4 3. Part Names........... 4 4. Wiring and Installation ........5 5. Package contents ......... 7 6. Specification ..........7... -
Page 3: Introdution
The model number is located on the bottom and record the serial number in the space provided below(available). Refer to these numbers whenever you call upon your COMMAX dealer regarding this product. Model No. -
Page 4: Important Safeguard
2. Important Safeguard Damage Requiring Service: This equipment from the power source and source and refer servicing to qualified service personnel under the following conditions: when the power is damaged. if liquid has been spiled or objects have hallen into the unit if the equipment has been exposed to rain or water. -
Page 5: Part Names
3. Part Names. 1. Protection shield. 7. Monitor Connection terminal. 2. Lamp at night 8. Description Label. 3. C.C.D Camera Lens 9. Bracket mounting a wall 4. Speaker 10. Angle adjustment lever. 5. MIC. 11. Power lamp : When talking with a monitor, it is on. 6. -
Page 6: Wiring And Installation
4. W iring and Installation 1. Fix a bracket to wall with screws (M3 x 10mm) supplied. 2. Please fix the desired angle of a lens with angle adjustment lever before fixing it. 3. Put a camera unit into a bracket. A Monitor A door camera unit 4. - Page 7 A Monitor A door camera unit 60cm...
-
Page 8: Package Contents
5. Package contents 1. SCREW : T4X18mm 2EA, M3X10mm 1EA 2. Manual 6. Specification Model DRC-40BS DRC-40CS Spec. Pick Up Device B/W C.C.D 1/3” COLOR C.C.D 1/4” Wiring 4 wires in Polarity / 2 wires in NonPolarity (House/Door Releasa) Related voltage... - Page 9 Memo...
