Summary of Contents for Commax CNV-2M03RS

  • Page 2: Precautions

    IR Indoor Mini Dome Network Camera User Manual Precautions Precautions Precautions Fully understand this document before using this device, and strictly observe rules in this document when using this device. If you install this device in public places, provide the tip "You have entered the area of electronic surveillance" in an eye- catching place.
  • Page 3 IR Indoor Mini Dome Network Camera User Manual Precautions Strictly conform to local electrical safety standards and use power adapters that are  marked with the LPS standard when installing and using this device. Otherwise, this device may be damaged. Use accessories delivered with this device.
  • Page 4 IR Indoor Mini Dome Network Camera User Manual Precautions Special Announcement All complete products sold by the manufacturer are delivered along with nameplates, operation instructions, and accessories after strict inspection. The manufacturer shall not be held responsible for counterfeit products. This manual may contain misprints, technology information that is not accurate enough, or product function and operation description that is slightly inconsistent with the actual product.

  • Page 5: Table Of Contents

    IR Indoor Mini Dome Network Camera User Manual Contents Contents Precautions ........................i 1 Overview ........................1 1.1 Hardware Connection ..................... 1 1.2 Features .......................... 3 2 Device Dimensions ....................4 3 Device Installation ....................5 3.1 Preparations ........................5 3.2 Installation Mode......................

  • Page 6: Overview

    IR Indoor Mini Dome Network Camera User Manual 1 Overview Overview 1.1 Hardware Connection Figure 1-1 shows the multi-connector combination lines of the IR Indoor Mini Dome Network Camera and Table 1-1 describes the multi-connector combination lines. Figure 1-1 Hardware connection Table 1-1 Multi-connector combination lines Type Function...
  • Page 7 IR Indoor Mini Dome Network Camera User Manual 1 Overview Figure 1-2 Internal structure of IR mini dome network camera Table 1-2 Descriptions of hardware interfaces Component Description Video Outputs analog video signal and connects a TV monitor to watch analog videos. (Video output) Power POE can be used to supply power or external DC12...

  • Page 8: Features

    IR Indoor Mini Dome Network Camera User Manual 1 Overview Component Description When removing an SD card, make sure that the SD  card is not in the read/write status. Otherwise, data may be lost or the SD card may be damaged. When hot plugging an SD card, stop recording ...

  • Page 9: Device Dimensions

    IR Indoor Mini Dome Network Camera User Manual 2 Device Dimensions Device Dimensions Figure 2-1 shows the camera dimensions. Figure 2-1 Dimensions (unit: mm)

  • Page 10: Device Installation

    IR Indoor Mini Dome Network Camera User Manual 3 Device Installation Device Installation 3.1 Preparations You may need the tools and accessories shown in Table 3-1 during the installation (you need to prepare the tools by yourself, and the accessories are in the package of the camera).

  • Page 11: Installation Mode

    IR Indoor Mini Dome Network Camera User Manual 3 Device Installation To avoid the impact of humidity, after installing the device, power on the device for at least half an hour before sealing the cover. 3.2 Installation Mode The IR Indoor Mini Dome Network Camera can be installed in ceiling mounting or side wall mounting mode.
  • Page 12 IR Indoor Mini Dome Network Camera User Manual 3 Device Installation Figure 3-2 Opening the cover Take out the installation positioning sticker in the package box, remove the release Step 2 paper on the back of the sticker, and paste the sticker on the required installation position on the top.
  • Page 13 IR Indoor Mini Dome Network Camera User Manual 3 Device Installation Figure 3-3 Installing the camera on the ceiling Connect the RJ45 network conversion adapter in the accessory package to the power Step 6 wiring terminal. In this step, you can perform operations such as inserting or removing the SD card, resetting a function, and adjusting a video.
  • Page 14 IR Indoor Mini Dome Network Camera User Manual 3 Device Installation Figure 3-4 Adjusting the direction and angle of the camera Connect the MIC plug to the MIC socket at first, ensure that the plug is not loose, then Step 7 install the cover by using the T15 combination wrench or an electric screwdriver with T15 torx, as shown in Figure 3-5.

  • Page 15: Quick Configuration

    IR Indoor Mini Dome Network Camera User Manual 4 Quick Configuration Quick Configuration 4.1 Login and Logout You must use Internet Explorer 7 or a later version to access the web management system; otherwise, some functions may be unavailable. Login system Open the Internet Explorer, enter the IP address of IP camera (default value: Step 1 192.168.0.120) in the address box, and press Enter.
  • Page 16 IR Indoor Mini Dome Network Camera User Manual 4 Quick Configuration Figure 4-1 Adding the a trusted site 2. In the Internet Explorer, choose Tool > Internet Options > Security > Customer level, and set Download unsigned ActiveX control and initialize and script ActiveX controls not marked as safe for scripting under ActiveX controls and plug-ins to Enable, as shown in Figure 4-2.

  • Page 17: Download Control In The Internet Explorer

    IR Indoor Mini Dome Network Camera User Manual 4 Quick Configuration The login page is display when the control is loaded. 4.2.1 Download control in the Internet Explorer Real-time video page shows the message clicks to play live video with ActiveX control to reduce latency.

  • Page 18: Parameter Description

    IR Indoor Mini Dome Network Camera User Manual 4 Quick Configuration Table 4-1 Local network parameters Parameter Description Setting IP Protocol IPv4 is the IP protocol that uses [Setting method] an address length of 32 bits. Select a value from the drop-down list box.
  • Page 19 IR Indoor Mini Dome Network Camera User Manual 4 Quick Configuration Click Apply. Step 3 If the message "Apply succeed!" is displayed, click Confirm. The system saves the  settings. The message "Set network parameter success, Please login system again" is displayed.

  • Page 20: Technical Specifications

    Progressive Scan Min. Illumination Color 0.2 Lux, IR On 0 Lux IR-LED 1pcs / 6~7m Lens CNV-2M03RS : f = 2.8mm Focal Length CNV-2M04RS : f = 3.6mm CNV-2M03RS : 107° Angle of view CNV-2M04RS :75° Lens / Mount type...
  • Page 21 IR Indoor Mini Dome Network Camera User Manual 5 Technical Specifications Max. Frame rate 30fps@1920x1080 Bit rate Control CBR / VBR Main stream : 500kb-12000kb Bit Rate (CBR/VBR) Sub stream : 100kb-6000kb Audio Input / Output 1ch Audio Input / 1ch Audio Output Audio Compression G.711, RAW_PCM IPv4 / IPv6...
  • Page 22 IR Indoor Mini Dome Network Camera User Manual Hazardous Substance Declaration Hazardous Substance or Element Hexavalent Polybrominated Component Plumbum Mercury Cadmium Polybrominated Chromium Diphenyl Ethers (Pb) (Hg) (Cd) Biphenyls (PBB) (Cr6+) (PBDE) Structural ○ ○ ○ ○ ○ × part Board/circuit ○...
  • Page 23 IR Indoor Mini Dome Network Camera User Manual...
