User Manual

OUT DOOR CAMERA DRC-2AB1(B&W)/DRC-2AC1(COLOR)
Thank you for purchasing COMMAX products.
Please carefully read this User's Guide (in particular, precautions for safety) before using a product and follow
instructions to use a product exactly.
The company is not responsible for any safety accidents caused by abnormal operation of the product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DRC-2AB1(B&W) and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Commax DRC-2AB1(B&W)

Summary of Contents for Commax DRC-2AB1(B&W)

  • Page 1: User Manual

    User Manual OUT DOOR CAMERA DRC-2AB1(B&W)/DRC-2AC1(COLOR) Thank you for purchasing COMMAX products. Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow instructions to use a product exactly. The company is not responsible for any safety accidents caused by abnormal operation of the product.

  • Page 2: Table Of Contents

    Table Of Contents Introduction ............3 Important Safeguard ...........4 General Features ..........6 Preparation ............7 Location And Function Of Controls....8 Attaching Consideration........10 How To Installation ...........11 Notes On Use and Installation ......12 Troubleshooting Guide ........13 Specifications............15 COMMAX Limited Warranty ......16...

  • Page 3: Introduction

    The model number is located on the bottom and record the serial number in the space provided below(available). Refer to these numbers whenever you call upon your COMMAX dealer regarding this product. Model No.

  • Page 4: Important Safeguard

    Important Safeguard Damage Requiring Service: This equipment from the power source and source and refer servicing to qualified service personnel under the following conditions: when the power is damaged. if liquid has been spiled or objects have hallen into the unit if the equipment has been exposed to rain or water.
  • Page 5 Power Line -The commax door aamera system should not be located near overhead power lines or other electric light or power circuits, or where it can fall into power lines or circuits. When installing a door camera system, avoid dan- gerous contact with power lines or circuits.

  • Page 6: General Features

    General Features There is no where better than surveillance home, factory, office to make your house a security home COMMAX sur- veillance system are here to provide positive visual and convenience life. General Characteristics The system consists of : - For 12V DC Operation ( power supplied from the monitor).

  • Page 7: Preparation

    - Clean the cabinet, glass and controls with a drt soft cloth, or a soft cloth lightly moistened with mild deter- gent solution. On Cleaning - Do not use any type of solvent, such as alcohol or benzene, which might damage the finish. If you have any questions about this unit, contact your Commax dealer.

  • Page 8: Location And Function Of Controls

    Location and Control of Functions ❶ Microphone When Turn on the [CALL] button on the panel, and conversation with residents. ❷ C.C.D. Camera Lens Built-in Black & White C.C.D. 1/3" lens (for DRC-2AB1) and Color 1/4" C.C.D lens (for DRC-2AC1). ❸...
  • Page 9 Location and Control of Functions ❽ Screw Hole Use the assembly panel. NOTE: Before connection, contact to technical engi- neer. ❾ Angular Field Of View For Camera Adjust the angular field of the camera for manually. ❿ Connection Wire Release ...

  • Page 10: Attaching Consideration

    Attaching Consideration When selecting the location for attaching your unit, please remember... - Bottom should be of sufficient strength to permit attach- ing. - Allow adequate space on the both side of the unit for proper ventilation access to cable and unit for viewing easy.

  • Page 11: How To Installation

    How To Installation Connection Wires : Wiring 1. Connection wires to inside unit on the side of monitor. Monitor1 Camera 1 (Notice : Checking to screw dimension : M3 X 30mm (With washer) :2 pieces - included). 2. Connection Terminal : Check the wire connection termi- nal level of the side of unit (Refer to wiring diagram).

  • Page 12: Notes On Use And Installation

    Note On Use and Installation Do Not Aim The Camera At The Sun Do Not Slash Water On The Camera Do not aim the camera at the sun or point it at Install the camera where the camera can be kept dry. If the the sun even if you are not shooting.

  • Page 13: Troubleshooting Guide

    If you still can? correct an operating problem, contact your dealer. If your dealer is unable to solve your problem, contaact Commax Customer Service, Please don't open the cabinet and attempt to repair the unit, as this will void your warranty.
  • Page 14 Troubleshooting Guide Condition Checking Points Solution No Image - Are the camera and connected Make sure that system unit is plugged. equipment turned on ? Make sure that adjusted properly your desired. - Is the lens adjusted properly ? Make sure that system cable correct connection Noise Picture - Are cables connected correctly? of the unit...

  • Page 15: Specifications

    Specification Model No. DRC-2AB1(B&W) / 2AC1(Color) Input Voltage ,±10% (Power supplied from the monitor) Connection Wire 4 Wires (Polarity) Maximum current 200mA Video input 1Vp-p composited 75Ω Operating Ambient Temperature -10°C to 40°C Weight (g) Dimensions (W/H/D)mm 208/ 123 / 50 External design, features, functions and specifications of the product can be changed without any prior, for promoting the quality of the product.

  • Page 16: Commax Limited Warranty

    Commax warrants this product for normal home use within all over world a follows: - For ninety days from original date of purchase or receipt as a gift and manual, COMMAX will, at its option, repair or replace a detective product at free charge to you.
  • Page 17 Memo...
  • Page 18 513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea Int’l Business Dept. : Tel.; +82-31-7393-540~550 Fax.; +82-31-745-2133 Web site : www.commax.com Printed In Korea / 2011.06.105 PM102AB10010...
