Commax DRC-40BS Manual

VIDEO PHONE CAMERA
• Thank you for purchasing our COMMAX product.
• Please carefully read this User Guide (in particular, precautions for safety)
before using the product and follow the instructions to use your productexactly.
• The company is not responsible for any safety accidents caused in abnormal
operation of the product.
SPECIFICATION
Model
DRC-40BS
Spec.
Pick Up Device
B/W C.C.D 1/3"
Wiring
(House/Door Releasa) 4 wires in NonPolarity 2 wires in NonPolarity
Related voltage
12V DC (from a mointor)
Conversation Method
Simultaneous Conversation
Angle Adjustment
H: 68。H: 55。
Horizontal/Vetical Scanning
15.734KHz/60Hz, 15.625KHz/50Hz
Min. Illumination
0 LUX(300mm from Camera)
Temperature
-10℃ ~ +40℃
Dimension
99.5(W)×141.5(H)×37(D)mm
weight
300g
Package contents
◆
SCREW : T4X18mm 2EA, M3X10mm 1EA
Manual
OUTDOOR CAMERA
DRC-40BS/40CS
DRC-40CS
COLOR C.C.D 1/4"
Up: 8。Down: 12。
VIDEO PHONE CAMERA
SPECIFICATION
Model
DRC-40BS
Spec.
Pick Up Device
B/W C.C.D 1/3"
Wiring
(House/Door Releasa) 4 wires in NonPolarity 2 wires in NonPolarity
Related voltage
12V DC (from a mointor)
Conversation Method
Simultaneous Conversation
Angle Adjustment
H: 68。H: 55。
Horizontal/Vetical Scanning
15.734KHz/60Hz, 15.625KHz/50Hz
Min. Illumination
0 LUX(300mm from Camera)
Temperature
-10℃ ~ +40℃
Dimension
99.5(W)×141.5(H)×37(D)
weight
300g
OUTDOOR CAMERA
DRC-40BS/40CS
DRC-40CS
COLOR C.C.D 1/4"
Up: 8。Down: 12。
