Commax DRC-40CS Use And Care Manual page 3

Do Not Aim The unit At The Sun/Rainning
Do not aim the unit at the sun or point it at the sun/rainning even if you are not shooting.
Do Not Shoot Intense Light
Framing intense light such as a spotlight may cause bloom or smear. A vertical stripe may appear on the screen. However, this is not a
malfunction.
Treat The Unit With Care
Do not drop the unit or subject it strong shock of vibration. Otherwise, the components may malfunction.
Never Touch Internal Parts
Do not touch the internal parts of the camera other than that parts specified. Otherwise, the camera may malfunction.
Check The Ambient Temperature And Humidity
Avoid using the camera where the temperature is hotter or colder than specified. Otherwise, the quality of images may deteriorate or internal
parts may be affected. Special care is required to use the camera at high temperature and humidity.
Should You Notice Any Trouble
If any trouble occurs while you are using the camera, turn off the power and contact your dealer. If you continue to use the camera when there is
something wrong with it, the trouble may much worse and an unpredictable accident may occur.
Do Not Slash Water On The Unit
Install the unit where the unit can be kept dry. If the unit a gets wet, turn off the power and contact you dealer.
1. Checking to polarity that conection to monitor before instllation.
2. Use screw (supplied) and unit attached on the wall (as shown side)
3. Adjustment to angukar field of lens for your desire.
Adjust that unit of rear by angular adjustment lever.
Note : If you have question about installation it, Refer to monitor Operating Manual
Camera Install Height Level / Wiring
Note On Use And Installation
5
System Network And Camera Height Level
(as shown below)
1400
Unit:mm
6
Before Install Consideration
When selecting the location for mounting/attaching your unit,
- Allow adequate space on the both side of the unit for proper
ventilation access to cable and unit for aural easy.
- For angular field of camera view and just by manually be sure
there is sufficient space behind the unit to adjustment to angular
field of view its position (Refer to System network and Camera
or Note On Use And Installation page).
