Front View; Rear View - Commax DRC-40CS Use And Care Manual

- Material prevent corrision-strong construction is achieved by aluminium
- Easy installation and gracefulness design
- Capable of installation for sub-units
- Designed semi-surfaced mount on the wall type
- For DC 12V operation version
On Safety
- Should any solid object or liquid fall into the cabinet, disconnected the unit and have it checked by qualified personnel
before operating it any further.
- Allow adequate air circulation to prevent internal heat build-up.
- Do not place the unit on surfaces (rugs, blankets,etc) or near materials(curtains, drapereis) that may block
On Installation
the ventilation slots.
- Do not install the unit near heat sources such as radiators or air ducts or in a place subject to direct sunlight, excessive
dust, mechanical vibration or shock.
- Keep the unit and glass away from equipment with strong magnets, such as a microwave oven or large loudspeakers.
On Operating
- When the unit is not in use, turn off the power to conserve energy and to extend its useful
life (available).
On Cleaning - Clean the cabinet, glass and controls with a dirt soft cloth, or a soft cloth lightly moistened with mild detergent solution.
- Do not use any type of solvent, such as alcohol or benzene, which might damage the finish.
If you have any questions about this unit, contact your Commax dealer.

Front View

Window Protect for Lens
Infrared L.E.D.
CCD camera lens
Speaker
Microphone
Calling Button
Connection to terminal for residentials
General Features
Preparation
3
Location And Function of Controls

Rear View

Specification Label
Wall Hinge
Dimensions(mm) : 99.5(W) x 141.5(H) x 37 (D)
Camera lens Angualr Adjust Lever
Operating LED Indicator
Reflector Connection Wire
4
