Third Party Applications

Adobe Premiere Pro CS4 v4.0.1
Adobe Premiere Pro is a powerful real-time video and audio non-linear editing application. Full
™
presets for Premiere Pro are included with the Blackmagic driver software and will be automatically
loaded into your system during the installation process. Premiere Pro must be installed on your
system before running the Blackmagic driver installer.
Premiere Pro CS4 introduced the ability to capture and playback with sequences of different formats
within the one project. For example, Intensity cards can capture 1080i59.94, 1080i50 and NTSC
video to corresponding sequences within the one Premiere Pro CS4 project.
Setting Up
1. Launch Premiere Pro CS4 v4.0.1.
2. Create a and set the Capture Format to
New Project
3. Click on the Properties button and then choose from the desired properties for your project.
The Video Standard can be set to
uncompressed or compressed and you should also specify the number of audio channels to be
captured. Now click .
OK
4. Select your disk array as the Location for your media.
5. Type the name of your project and click
6. The New Sequence window will appear and you will usually want to select a sequence preset which
matches the preset you chose for the project, e.g. Blackmagic Design>HD1080>MotionJPEG>
Interlaced>59.94i.
7. You may wish to use the default sequence name or rename it. Then click
Audio
Blackmagic software features support for multiple channels of audio in Premiere Pro CS4 using
the new Blackmagic audio plugin. Blackmagic audio hardware is automatically chosen when a
new project is created and the capture format is set to Blackmagic Capture. The choice of audio
hardware can also be configured through
Settings button serves no function as ASIO audio is not used for capture or playback.
You may also wish to visit
Edit > Preferences > Audio Output Mapping
multi-channel audio. Set
Map Output for
as both are the same as each other. Intensity cards support 2 channels of audio.
(CS4)
Using for Capture and Playback
Blackmagic Capture
, , or . The Video Format can be
NTSC PAL HD720 HD1080
.
OK
OK
Edit > Preferences > Audio Hardware
to select the mix of the
to either or
Blackmagic Audio
.
.
. The ASIO
Blackmagic Audio
Adobe Premiere Pro.
New Sequence
Audio Output Mapping.
