leszek Błoch
April 5, 2025
jak podłączyć magnetowid VHS do Blacmagic pro , bo podłączam i nie mam połączenia
1 comments:
Mr. Anderson
April 5, 2025
To connect a VHS VCR to the Blackmagic Design Intensity Pro, follow these steps:
1. Use the correct output from the VCR: Most VHS VCRs have a composite output (yellow RCA jack). Some may also have S-Video.
2. Connect through a TBC (Time Base Corrector): This helps stabilize the video signal. Connect the VCR’s composite output to the TBC input, then connect the TBC output to the Intensity Pro’s composite input.
3. Use the Intensity Pro breakout cable: Plug the breakout cable into the Intensity Pro card. Use the corresponding composite (yellow RCA) or S-Video input on the breakout cable.
4. Install drivers and software: Install the required Blackmagic drivers and Media Express software from the Blackmagic Design website.
5. Configure software settings: In Media Express, set the input to match your signal (e.g., composite NTSC or PAL). Choose the correct resolution and frame rate.
6. Test the video: Ensure the signal is stable. If the video is not synced, check the TBC and cable connections.
This setup allows capturing VHS footage using the Intensity Pro card.
This answer is automatically generated
