Pbd-1200A Dual Blower - Zephyr AK7000BS Use, Care And Installation Manual

This range hood is equipped standard with a single blower vertical duct option. To convert from single blower
vertical ducting to dual blower vertical ducting please following the instructions below.
PBD-1200A dual blower kit compatible only with AK7036BS and AK7042BS models.
1. Disconnect blower plug.
3. Remove (4) screws from inside hood body
attaching single blower plate. Remove single
blower plate from hood body.
5. Install previously removed blower onto one side
of dual blower plate and attach by (4) previously
removed screws from step 2.
2. Remove (4) screws at top of hood body attaching
blower to single blower plate. Remove blower
from hood body.
4. Install dual blower plate from PBD-1200A kit
into hood body. Attach by (4) screws previously
removed from step 3.
6. Install blower from PBD-1200A kit onto other
side of dual blower plate by (4) 3/16 x 3/8
screws.
13
