Page 1: Evaluation Board
Fujitsu Microelectronics Europe FMEMCU-UG-960008-10 User Guide F²MC-16LX/FX FAMILY EVALUATION BOARD FLASH-CAN-64P-350-PMC USER GUIDE... -
Page 2: Revision History
FLASH-CAN-64P-350-PMC Revision History Revision History Date Issue 20.06.2007 V1.0, DGo, First Release This document contains 29 pages. UG-960008-10 - 2 - © Fujitsu Microelectronics Europe GmbH... -
Page 3: Warranty And Disclaimer
Product or parts thereof, if the Product is returned to Fujitsu Microelectronics Europe GmbH in original packing and without further defects resulting from the customer’s use or the transport. -
Page 4: Table Of Contents
CAN”A”, CAN”B” Interface connector (X10, X11)........... 23 USER-LEDs & LC-Display (optional) ..............23 VG96 connector (X4)..................... 24 7 SILK-PLOT OF THE BOARD ..................26 8 RELATED PRODUCTS ....................27 9 INFORMATION IN THE WWW..................28 UG-960008-10 - 4 - © Fujitsu Microelectronics Europe GmbH... -
Page 5: Overview
Chapter 2 Overview 2 Overview 2.1 Abstract The FLASH-CAN-64P-350-PMC is a multifunctional evaluation board for the Fujitsu 16-Bit Flash microcontroller MB90350 and MB96350 Series. It can be used stand alone for software development and testing or as a simple target board to work with the emulator system. -
Page 6: General Description
FLASH-CAN-64P-350-PMC Chapter 2 Overview 2.3 General Description The FLASH-CAN-64P-350-PMC supports 16-Bit Flash microcontrollers of the MB90350 Series and MB96350 Series. It can be used as a stand alone evaluation board or as a target board for emulator debugger. The evaluation board supports the following package: FPT-64P-M09 / M23 The board is supplied with a socketed 4 MHz crystal as the main oscillation clock. -
Page 7: Installation
Do not screw the cover too tight (max 0.054 Nm). If you have connectivity problems then please loosen the screws and tighten again the screws equally. Do not clean NQPACK, YQPACK, and YQSOCKET with steam. Cleaning material will contaminate inside of connector. © Fujitsu Microelectronics Europe GmbH - 7 - UG-960008-10... -
Page 8: Jumpers And Switches
CAN transceiver A VCC 3V3 / 5V solder-Jumper JP49 CAN transceiver B VCC 3V3 / 5V solder-Jumper JP52 LIN TLE6259 (2-3) / TLE7259 (1-2) solder-Jumper JP53 LIN TLE6259 (2-3) / TLE7259 (1-2) solder-Jumper UG-960008-10 - 8 - © Fujitsu Microelectronics Europe GmbH... - Page 9 FLASH-CAN-64P-350-PMC Chapter 4 Jumpers and Switches LIN A LIN B © Fujitsu Microelectronics Europe GmbH - 9 - UG-960008-10...
-
Page 10: Operating-Mode (S2)
Default: MD0, 1, 2 = 1 1 0 P00, P01 = 0 0 By default, the Single Chip Run-Mode is selected. MD0 MD1 MD2 nc P01 P00 Dip-Switch S2 (default setting) UG-960008-10 - 10 - © Fujitsu Microelectronics Europe GmbH... -
Page 11: Power Supply Voltage (Jp: 29, 34)
Power supply Vcc connected to IC JP34 (MCUVcc) OFF (open) Disconnected from Power supply Vcc Default: JP29 = 1-2, JP34 = closed, By default, the on-board Voltage regulation is used and the microcontroller is powered. © Fujitsu Microelectronics Europe GmbH - 11 - UG-960008-10... -
Page 12: Analogue Power Supply Voltage (Jp: 11, 13, 15)
(AVcc and AVss) to the A/D-converter. If JP13 is open, the resistors R11 and R23 define AVRH. By default the resistor network (R11 and R23) is not mounted on the board. UG-960008-10 - 12 - © Fujitsu Microelectronics Europe GmbH... -
Page 13: Subclock (Jp: 36, 37)
JP37 (X1A/P41) Pin 20 is used as P41 and is connected to X1-20 and X4-A17 Default: JP36: 1-4, JP37: 1-2 By default, the 32 kHz subclock-crystal is connected to the microcontroller. © Fujitsu Microelectronics Europe GmbH - 13 - UG-960008-10... -
Page 14: Uart"A" (Jp: 1, 2, 31)
RTS and CTS is shortcut on X5 JP31 (RTS-CTS) OFF (open) RTS and CTS is not shortcut on X5 Default: JP6=closed, JP8=closed, JP32 = closed By default, UART3 is used as UART”B”. UG-960008-10 - 14 - © Fujitsu Microelectronics Europe GmbH... -
Page 15: Lin"A" (Jp: 17, 18)
SIN8 is connected to LIN-Transceiver open SOT8 is disconnected from LIN-Transceiver JP39 (LIN”B”TXD) closed SOT8 is connected to LIN-Transceiver Default: JP9=open, JP10=open, JP38=open, JP39=open By default, UART8 is not used as LIN-interface. © Fujitsu Microelectronics Europe GmbH - 15 - UG-960008-10... -
Page 16: Can"A" (Jp: 25, 26)
Pin 56 (P32) is connected to LED D3 JP28 (RX2) RX2 is connected to CAN-Transceiver (U8, X11) Default: JP27=1-2, JP28=1-2 By default, LED D3 and D4 are connected to Port P32 and P33 of the microcontroller. UG-960008-10 - 16 - © Fujitsu Microelectronics Europe GmbH... -
Page 17: Reset-Generation (Jp: 3, 4, 5, 24, 35)
If JP35 (Polarity) is set, than JP4 and JP5 have to be set, too. If the reset LED is steadily on, check the power supply input voltage and the settings for the reset-generation by UART. © Fujitsu Microelectronics Europe GmbH - 17 - UG-960008-10... -
Page 18: Buttons Int10, Int11, Tin1, In0, In1, Reset (Jp: 7, 12, 14, 16, 20, 23)
IN1 is connected to Push-button “IN1” JP23 (IN1) Open no connection to IN1 Default: JP7, JP12, JP14, JP16, JP20, JP23 =closed By default, INT10, INT11, TIN1, IN0, IN1 RSTX microcontroller are connected to the Push buttons. UG-960008-10 - 18 - © Fujitsu Microelectronics Europe GmbH... -
Page 19: Programming The Internal Flash
In order to program the Flash-ROM asynchronously via UART3, the tool “Fujitsu Flash MCU Programmer for FMC16LX” can be used to flash MB90350 series devices or the tool “Fujitsu Flash MCU Programmer for FMC16FX” for MB96350 series devices. These tools are available free on the Fujitsu Micros DVD or Web Site (http://mcu.emea.fujitsu.com/: select <... - Page 20 FLASH-CAN-64P-350-PMC Chapter 5 Programming the internal Flash 7. Start the tool “Fujitsu Flash MCU Programmer for FMC16LX” for MB90350 Series or “Fujitsu Flash MCU Programmer for FMC16FX” for MB96F350 Series software and follow the instructions: Set Device Type Select COM Port...
-
Page 21: Synchronous Mode
In case that another Programming-Tool is used and the Mode-settings have to be done manually then use the following configuration of DIP-switch S2 in order to select the synchronous-serial Flash-programming mode: MD0 MD1 MD2 nc P01 P00 synchronous Boot-Mode © Fujitsu Microelectronics Europe GmbH - 21 - UG-960008-10... -
Page 22: Connectors
TXD is the transmit output, RXD is the receive input. The DTR or RTS signal can be used to generate a reset. Please use 1:1 cable for PC-connection. Connectors X3, X5: CTS RTS DSR UG-960008-10 - 22 - © Fujitsu Microelectronics Europe GmbH... -
Page 23: Lin"A", Lin"B" Interface Connector (X6, X8)
Eight LEDs are reserved for user-application. In order to disconnect the LEDs from the related microcontroller port, the resistor network N1 can be removed. Instead of the user-LEDs one alphanumeric LC-Display (optional) can be connected. The following control-signals are reserved: VCC GND Port © Fujitsu Microelectronics Europe GmbH - 23 - UG-960008-10... -
Page 24: Vg96 Connector (X4)
ABC2 ABC3 P40/X0A (A16) P25/A21/IN1/ADTG P41/X1A (A17) P44/SDA0/FRCK0 P45/SCL0/FRCK1 P30/ALE/IN4 P31/RDX/IN5 P00/AD00/INT8 P32/WRX/INT10R P01/AD01/INT9 P33/WRHX P02/AD02/INT10 P34/HRQ/OUT4 P03/AD03/INT11 P35/HAKX/OUT5 P04/AD04/INT12 P36/RDY/OUT6 P05/AD05/INT13 P37/CLK/OUT7 P06/AD06/INT14 P60/AN0 P07/AD07/INT15 P61/AN1 P10/AD08/TIN1 AVcc extVCC ABC1 UG-960008-10 - 24 - © Fujitsu Microelectronics Europe GmbH... - Page 25 ABC2 ABC3 P40/X0A (A16) P25/A21/IN1/ADTGR P41/X1A (A17) P44/SDA0/FRCK0/TIN0R P45/SCL0/FRCK1/TIN2R P30/ALE/IN4/TOT0R P31/RDX/IN5/TOT2R P00/AD00/INT8/SCK7R P32/WRX/RX2/INT10R P01/AD01/INT9/SOT7R P33/TX2/WRHX P02/AD02/INT10/SIN7R P34/HRQ/OUT4 P03/AD03/INT11/SCK8R P35/HAKX/OUT5 P04/AD04/INT12/SOT8R P36/RDY/OUT6 P05/AD05/INT13/SIN8R P37/CLK/OUT7 P06/AD06/INT14/PPG10R P60/AN0/PPG0/CS0R P07/AD07/INT15/PPG11R P61/AN1/PPG1/CS1R P10/AD08/CKOT1/TIN1 AVcc extVCC ABC1 © Fujitsu Microelectronics Europe GmbH - 25 - UG-960008-10...
-
Page 26: Silk-Plot Of The Board
Pin 2 90F352 Pin 32 Pin 34 4MHz Pin 31 Pin 33 FlashKit Power- MAX232 Jack optional: LCD MAX232 CAN”B” UART”B” User-LEDs (P30-P37) TIN1 Reset INT10 INT11 UART”A” CAN”A” LIN”A” LIN”B” UG-960008-10 - 26 - © Fujitsu Microelectronics Europe GmbH... -
Page 27: Related Products
< MB2198-500 Emulation adapter < MB2198-504 Emulator probe cable for package (FPT-64P-M09 / M23) < MB96V300 Evaluation chip for MB96300 Series < MB96F356RWAPMC Flash-Microcontroller with Subclock < MB96F356RSAPMC Flash-Microcontroller without Subclock © Fujitsu Microelectronics Europe GmbH - 27 - UG-960008-10... -
Page 28: Information In The Www
Datasheets and Hardware Manuals, Support Tools (Hard- and Software) http://mcu.emea.fujitsu.com Linear Products: Power Management, A/D and D/A Converters http://www.fujitsu.com/emea/services/microelectronics/linears/ Media Products: SAW filters, acoustic resonators and VCOs http://www.fujitsu.com/emea/services/microelectronics/saw/ For more information about FUJITSU MICROELECTRONICS http://www.fujitsu.com/emea/services/microelectronics/ UG-960008-10 - 28 - © Fujitsu Microelectronics Europe GmbH... - Page 29 According to the European WEEE-Directive and its implementation into national laws we take this device back. For disposal please send the device to the following address: Fujitsu Microelectronics Europe GmbH Warehouse/Disposal Monzastraße 4a 63225 Langen © Fujitsu Microelectronics Europe GmbH - 29 - UG-960008-10...
