MODEL: M1
Product id:M108D
The M1.
OWNER'S MANUAL

Advertisement

Table of Contents
loading

Related Manuals for B2 Audio M1

Summary of Contents for B2 Audio M1

  • Page 1 MODEL: M1 Product id:M108D The M1. OWNER’S MANUAL...

  • Page 2: Table Of Contents

    Foreword We congratulate you with your decision to purchase the M1 amplifier. Every product developed by implements the keystones of our company philosophy; Optimum sound reproduction within its range, etter ass & high performance. These elements will enable you to reproduce music the way you prefer.

  • Page 3: Design Features

    Thermal protection, Voltage sensors, DC offset & short circuitry via speaker outputs The double sided pcb features high current mosfet switching devices in both the in- and output stage. The crossover of the M1 is a 24 dB/octave filter. - which features low pass & subsonic options for the amplifier.

  • Page 4: Panel Layout

    For connection to the positive terminal of the The minimum impedance is 1 ohm if used as battery (+12). For optimum performance a single unit. 0 gauge cable is recommended. In linked mode the M1 o ers stable opearation to a minimum of 2 ohms.

  • Page 5: Installation

    3. Installation 3.1 Installation considerations If you choose to install the amplifier by yourself, please read the owner’s manual carefully. Before you start your installation, please take all steps into consideration. If in doubt, please contact authorized distributors / dealers that will be able to configure your set up.

  • Page 6: Power / Speaker Connectors

    3.2 POWER / SPEAKER CONNECTIONS +12V, GND, REM CONNECTION DIAGRAM Headunit Remote turn on FUSE Ground 750A Main Battery We recommend to use 12 gauge speaker cables for increased performance. Run 12 AWG speaker connecting cables from your speakers to the ampli er's mounting location. Keep speaker cables away from power cables and the ampli er’s RCA input cables.

  • Page 7: Daisy Chain Connection

    SPEAKER CONNECTION DIAGRAM II 8 ohm ~ 2ohms 3.3 DAISY CHAIN CONNECTION Daisy chain connection allows linking of 2 mono ampli ers to work as 1. Please read the following connection diagram cautiously to ensure the correct connection. Step 1 .
  • Page 8 DAISY CHAIN CONNECTION DIAGRAM II Step 1 . Connect speaker cable ( + ) on master ampli er to subwoofer ( + ) Step 2. Connect speaker cable ( + ) on slave ampli er to subwoofer ( ) Step 3 .

  • Page 9: Troubleshooting

    4. Troubleshooting Assure that the Power LED is on, if so please proceed with step # 3, if not, continue with the steps below; 1. Check the in line fuse (s) on the battery’s positive cable, replace if needed. 2. Assure that the Ground is properly attached to the vehichle’s chassis on a clean metal point, tighten or grind the connection point once again.
