SPT-M320/M324
SPT-M124
1/3 type IT CCD
570 line horizontal resolution
Exwave HAD technology offers extremely high sensitivity (0.07 lux at F1.2)
Wide range electronic CCD IRIS function (ON/OFF switchable, 1/60 - 1/100,000 sec.)
CCD IRIS function allows use of inexpensive manual iris lenses
Backlight compensation is possible with the LEVEL and BLC volume controls (only when
using auto iris lenses or the CCD IRIS function)
DC servo circuit drives auto iris facility
Accepts C or CS-mount lenses
AGC: Always ON
SPT-M320 provides single cable operation (video/sync/power triple multiplex transmission) for
easy installation with the optional YS-W150/W250 camera adaptor (Mode A)
SPT-M320 provides Monitor out function for on-the-spot camera positioning (Mode B)
Alternative power source operation: DC 12 V for SPT-M320, AC 24 V for SPT-M324
1/3 type IT CCD
380 line horizontal resolution
Hyper HAD technology provides high sensitivity (0.1 lux at F1.2)
Wide range electronic CCD IRIS function (ON/OFF switchable, 1/60 - 1/100,000 sec.)
Adjustable level and peak to average light compensation in CCD
IRIS mode
AGC: Always ON
Backlight compensation with the LEVEL and BLC volume
controls (When using auto iris lenses or the CCD IRIS function)
C/CS-mount with easy "thumbwheel" back focus adjustment
Accepts DC and video type auto iris lenses

B/W CCD Cameras

SPT-M320 Rear
CAMERAS
SPT-M324 Rear
SPT-M124 Rear
7
