YS-DX504
RSE-500/5-400/5
Half duplex video multiplexer with up to 4 cameras
Multiplexing recording to one VCR while switching between each camera by a field for
precise surveillance of multiple points
Live pictures can be displayed in full screen, sequence and quad while simultaneously
recording
Playback can be reviewed in full screen, sequence and quad
Zoom and Freeze functions are available in full screen and quad
Individual sequence dual time
Individual alarm duration/output
Activity detection
Video loss alarm
Recording duration: The recording time of each video camera can be set individually
Post alarm
RS-232C compatible
Menu: English/French/Spanish
YS-DX504 Rear
ISDN video transceiver (RSE-500/5)/transmitter (RSE-400/5)
H.261, H.263 video compression provides high video quality and refresh rates
PRE and POST alarm images can be captured with built in memory
QUAD display.
Supports CIF (352 x 288 pixels), 4CIF (704 x 576 pixels) and QCIF (176 x 144 pixels)
resolution formats
Maximum frame rate of 30 frames per second
8 looping video inputs plus one external video input
Three user selectable transmission modes - Fine, Normal or Fast
Data transparency capability - Two separate ports: RS-232C/422A, RS-232C/RS485
Password and Receive check features
RSE-500/5 transmits/receives audio, video and control data
RSE-400/5 transmits/receives audio and control data: transmits video
Optional RM-R500 wired/wireless remote controller for RSE-500/5
RSE-500/5 Rear
RSE-400/5 Rear
SWITCHERS AND MULTIPLEXERS

VIDEO TRANSMISSION SYSTEM

Video Transmitters

13
