SPECIFICATIONS
B/W CCD Cameras
SPT-M320
Pickup device
1
Interline Transfer CCD
Pic. Elements (HxV)
768 x 494
Lens mount
C and CS adj.
Signal system/
EIA 525/2:1
scanning sys.
Sync system
Internal/External
External sync
VS or MPX-VS
V-phase control
No
Horizontal resolution
570 Lines
S/N Ratio
Better than 50 dB
(AGC OFF)
Min. illumination
0.04 lux at F1.2 (30 IRE)
(AGC, ON)
0.07 lx at F1.2 (50 IRE)
0.3 lx at F1.2 (100 IRE)
H-Phase control
Yes
Video output
1.0 Vp-p, BNC (1)
Operating temperature
-10 to 50 °C
(14 to 122 °F)
Storage temperature
-40 to 60 °C
(-40 to 140 °F)
Power requirements
1) Multiplexing with
2) DC 12 V from
Power consumption
1) 2.8 W supplied from
2) 2.4 W at 12 V
Mass
410 g (14 oz.)
Dimensions (WxHxD),
57 x 50 x 140
mm (inches)
(2
24
SPT-M324
type
1
/
/
3
Interline Transfer CCD
768 x 494
C and CS adj.
EIA 525/2:1
External
AC Line Lock
±90 °
570 Lines
Better than 50 dB
0.04 lux at F1.2 (30 IRE)
0.07 lx at F1.2 (50 IRE)
0.3 lx at F1.2 (100 IRE)
No
1.0 Vp-p, BNC (1)
-10 to 50 °C
(14 to 122 °F)
-40 to 60 °C
(-40 to 140 °F)
DC 24 V, 60 Hz
YS-W150/W250
DC 12 V power supply
2.6 W
YS-W150/W250
340 g (12 oz.)
57 x 50 x 115
1
" x 2" x 5
5
")
/
/
(2
4
8
SPT-M124
type
1
/
3
3
Interline Transfer CCD
510 x 492
C and CS adj.
EIA 525/2:1
External
AC Line Lock
±90 °
380 Lines
Better than 45 dB
0.1 lux at F1.2 (50 IRE)
No
1.0 Vp-p, BNC (1)
-10 to 50 °C
(14 to 122 °F)
-40 to 60 °C
(-40 to 140 °F)
AC 24 V, 60 Hz
2.5 W
320 g (11 oz.)
57 x 50 x 115
1
" x 2" x 4
5
")
(2
/
/
4
8
type
1
/
" x 2" x 4
5
/
")
4
8
