- Page 1 User Manual of DS-6100-SATA Digital Video Server User Manual DS-6100-SATA Series Video Server...
-
Page 2: Table Of Contents
User Manual of DS-6100-SATA Digital Video Server Index CHAPTER 1 INTRODUCTION ........................4 1.1 F ......................... 4 UNCTIONS AND FEATURES 1.2 C ..........................5 OMMON APPLICATION CHAPTER 2 INSTALLATION ........................6 2.1 H ......................... 6 ARDWARE INSTALLATION 2.1.1 Installation steps ..........................6 2.1.2 Installation notice .......................... - Page 3 User Manual of DS-6100-SATA Digital Video Server Thanks for purchasing the products of Hikvision. If you have any requests or questions, please contact us immediately. This manual applicable DS-6104HCI-SATA & DS-6101HFI-SATA Series Video Server with one SATA HDD interface for local recording.
-
Page 4: Chapter 1 Introduction
4-ch CIF compression resolution real time, or 4-ch DCIF/2CIF at 4fps per channel, or 4-ch 4CIF at 2fps per channel. DS-6101HFI-SATA: 1 channel video input and 1 channel audio input, can max support 4CIF compression resolution real time. If you set the channel frame rate as 4CIF resolution, please set the bit rate as 1.5Mbps above to get the excellent image quality. -
Page 5: Common Application
User Manual of DS-6100-SATA Digital Video Server Support FAT32 files system Support HDD S.M.A.R.T technology. Support cycle or non-cycle record. Network Function Support one 10M/100M adaptive NIC; Support TCP/IP protocols; support video, audio, alarm, voice data, serial device data transmission through TCP/IP network;... -
Page 6: Chapter 2 Installation
User Manual of DS-6100-SATA Digital Video Server Chapter 2 Installation 2.1 Hardware installation 2.1.1 Installation steps Open packing case, and check the integrity; Take out things needed in installation; Connect cables needed (video signal input cable, audio signal input cable, RS485 cable and cable for LAN);... -
Page 7: Panel Description
HDD indicator lamp; Tx/Rx indicator lamp; Link indicator lamp; Power supply indicator lamp; Back panel of DS-6101HFI-SATA Back panel of DS-6104HCI-SATA Interface Instruction (From left to Right in return): One line in audio input for voice talk. - 7 -... -
Page 8: The Pin Definition Of Physical Interfaces
User Manual of DS-6100-SATA Digital Video Server One audio output for voice talk. One RJ45 UTP network port and one RJ45 RS-485 PTZ port. 4 external alarm input and 2 relay output. 4 channels video input and audio input. Power supply adapter. 2.4 The pin definition of physical interfaces 2.4.1 PIN definition of RS-232 serial interface The DVS has one RS-232 standard serial interface, with RJ-45 connector. - Page 9 User Manual of DS-6100-SATA Digital Video Server (2) 25-pin to 9-pin converter’s internal connection is like this: (3) If you don’t want to use 25-pin to 9-pin convertor to connect DVS and DTE through RS232 interface, you must use RJ45-DB9 cable. Its internal connection description is: (4) When the RS232 interface of the DVS connects with the DCE (such as MODEM), one end of the cable is the 8-pin RJ45 connector and the other is the DB25 male connector.
-
Page 10: Pin Definition Of Rs-485 Serial Interface
User Manual of DS-6100-SATA Digital Video Server 2.4.2 PIN definition of RS-485 serial interface TXD+ 8 TXD- 7 RXD+ 6 RXD- 5 GND 2 2.4.3 PIN definition of Ethernet interface (1) PIN definition of the direct network cable connecting DVS and HUB: (2) PIN definition of the cross network cable connecting DVS and host PC: - 10 -... - Page 11 User Manual of DS-6100-SATA Digital Video Server - 11 -...
-
Page 12: P Arameter S 3.1.1 Hyper Terminal Setup
User Manual of DS-6100-SATA Digital Video Server Chapter 3 Video Server Setup There are three kinds of methods to configure the parameters of video server. 1. Through Hyper Terminal (connect DVS with the PC through RS-232 serial ports) 2. Through client-end application software (connect DVS with PC through network) 3.1 Parameter Setup through RS-232 serial port Mainly set up IP parameters of the video server through serial port. - Page 13 User Manual of DS-6100-SATA Digital Video Server Step2: To name the connection name and to define the icon. Input a name (e.g. aa), select a icon, press “OK”, the dialogue box like Fig. 3.2 appears. Fig. 3.2 Select communication port Step 3”: to select the communication port.
- Page 14 User Manual of DS-6100-SATA Digital Video Server Fig. 3.4 Hyper Terminal Interface Step 5: To close the window, the Fig. 3.5 will appear. Select “Yes” and Fig. 3.6 will appear: Fig. 3.5 Disconnect Fig. 3.6 Save Hyper Terminal session Step 6: Save the Hyper Terminal session for using next time. After saving, it will new establish a “Hyper Terminal”...
-
Page 15: Shell Commands Under Hyper Terminal
User Manual of DS-6100-SATA Digital Video Server 3.1.2 Shell Commands under Hyper Terminal Please use the DTE cable and the DB9/DB25 convertor to connect PC with DVS RS-232 port. Step 1: Enter into the Hyper Terminal. Click “Start” “Programs” “Accessories” “Communications”... - Page 16 User Manual of DS-6100-SATA Digital Video Server Fig. 3.8 Check command The following is the introduction of getIp, setIp commands. getIp Function: get the fixed IP, subnet mask, gateway, command port, IP address of PPPoE dialup (the IP address of PPPoE will be 0.0.0.0 if there is no dialup or dialup is not successful). Parameter: none.
- Page 17 User Manual of DS-6100-SATA Digital Video Server Fig. 3.9 Get parameters of IP, PPPoE setIp Function: set the IP, subnet mask and gateway of the device Parameter: IP address, subnet mask, gateway Grammar format: setIp IP: mask Explanation: Please pay attention whether the inputting letters are capital or low case. And separate the parameters by colons.
-
Page 18: Video Server Hdd Format
User Manual of DS-6100-SATA Digital Video Server 3.2 Video Server HDD format Please refer to chapter 3.1 to get video server IP address. Then use remote client software to access video server. Please refer to client software user manual for detail information. 3.3 Video Server Recording Setup Please use remote client software to remote setup video server local recording parameters. -
Page 19: Remote Setup Video Server Parameters
User Manual of DS-6100-SATA Digital Video Server 3.5 Remote setup video server parameters Before the configuration, please make sure that the PC and the video server has been established the network connection, you can confirm using PING command. Please refer to the user manual of DVRDVS client software for detail information. -
Page 20: Chapter 4 Upgrade Firmware
User Manual of DS-6100-SATA Digital Video Server Chapter 4 Upgrade Firmware There are two methods to upgrade the DVS firmware. One is using shell commands to ask DVS to download firmware from TFTP server. The other is using PC client software. 4.1 Use Shell Command and TFTP Server Step 1: Before the update start you should do the follow steps:... - Page 21 User Manual of DS-6100-SATA Digital Video Server Fig 4.3 Step 2: Then reboot the device and press any button in the pc keyboard again and again until the HIK # come out in the Hyper Terminal interface, show as Fig 4.4. Then input the “print” to check if the IP of the server and device is correct, also both of them should be in the same LAN.
- Page 22 User Manual of DS-6100-SATA Digital Video Server Fig 4.5 Step 3: Input commend “save” and press enter button. Show as Fig.4.5. Step 4: Input the commend “update” and press enter button, then space button. After that the update will start. Show as Fig.4.6 Fig.
-
Page 23: Use Client Software To Upgrade Firmware
User Manual of DS-6100-SATA Digital Video Server Step 5: After the update finished, please input the command “reset” and press the enter button. The device will reset. Show as Fig.4.7. Fig 4.7 4.2 Use Client Software to upgrade firmware In the system setup dialog of DVRDVS client software (refer to client software user manual), there is a button named “Other”: - 23 -... - Page 24 User Manual of DS-6100-SATA Digital Video Server Fig.4.8 Remote upgrading Click “Explore” button and select the firmware file. Fig.4.9 Then click “Upgrade” button, to complete the upgrading process of the video server firmware. - 24 -...
- Page 25 User Manual of DS-6100-SATA Digital Video Server Fig.4.10 - 25 -...
-
Page 26: Chapter 5 Pppoe Dialup Operation
User Manual of DS-6100-SATA Digital Video Server Chapter 5 PPPoE Dialup Operation DS-6100-SATA video server supports remote access through network, through browser, through PPPoE or PPP dialup. Before using this function, please make sure that the software you used in your device support such functions or not. 5.1 Using PPPoE to establish connection In the local LAN, use the client software remote setup the DVS parameters. -
Page 27: Client Access Dvs When Using Pppoe
User Manual of DS-6100-SATA Digital Video Server Fig.5.2 [Explanation] please make sure that ADSL Modem is installed. If it is the first time to set PPPoE parameters, it needs to reboot video server to establish the connection. 5.2 Client access DVS when using PPPoE There are two methods: One is to access using the current WAN IP address of the video server. - Page 28 User Manual of DS-6100-SATA Digital Video Server the network connection with the video server to get the video images directly. Fig.5.3 Here the fixed WAN IP address of PC is 220.184.114.48. We call it as DNS IP. In that the PC, one demo analysis server software named IP Server is run.
-
Page 29: Chapter 6 Frequent Ask Questions
User Manual of DS-6100-SATA Digital Video Server Chapter 6 Frequent Ask Questions Failure to control PTZ It is possible that the camera and equipment are not connected through RS485 port, or the wrong configuration of the decoder. 2. certain individual channel picture is un-normal Please check whether the video cable is well connected with the camera and the Embedded DVS 3. -
Page 30: Appendix Aspecifications
User Manual of DS-6100-SATA Digital Video Server Appendix A Specifications Model DS-6101HFI-SATA DS-6104HCI-SATA Video compression H.264 Preview resolution 4CIF (PAL: 704*576, NTSC: 704*480) 4CIF/DCIF/2CIF/CIF/QCIF Recording resolution Support dual stream Video input Video input interface BNC(1.0Vp-p, 75Ω ), Support PAL, NTSC... -
Page 31: Appendix Bgood List
User Manual of DS-6100-SATA Digital Video Server Appendix B Good list One piece of DS- 6100-SATA video server; One CD contains client application and user manual; One power cable; One DTE cable; - 31 -... -
Page 32: Appendix Ccustomer Information Card
User Manual of DS-6100-SATA Digital Video Server Appendix C Customer Information Card User’s Name Mr./Mrs. Company Name Post Address Postcode Phone Number E-mail Model Number of Product Serial Number of Product Purchase Date Distributor Suggestions: - 32 -...
