- Page 1 Blazer Pro All-in-One Server Quick Start Guide UD00877B...
-
Page 2: About This Manual
(hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision. Unless otherwise stipulated, Hikvision does not make any warranties, guarantees or representations, express or implied, regarding to the Manual. - Page 3 SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.
-
Page 4: Regulatory Information
Quick Start Guide of Blazer Pro Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 5: Safety Instruction
Quick Start Guide of Blazer Pro Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected. Cautions: Injury or equipment damage may occur if any of the cautions are neglected. - Page 6 Quick Start Guide of Blazer Pro Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Indicates a potentially hazardous situation, which if not avoided, could result in equipment damage, data loss, performance degradation, or unexpected results.
-
Page 7: Table Of Contents
Quick Start Guide of Blazer Pro TABLE OF CONTENTS Overview ................................. 7 Blazer Pro Pre-Installation ..........................7 Blazer Pro Installation ............................. 7 Front Panel ............................... 8 Rear Panel ................................ 9 Specifications ..............................10 HDD Storage Calculation Chart ........................11 Basic Hardware Connection and Startup ....................12 Network Connection .......................... -
Page 8: Overview
Quick Start Guide of Blazer Pro Overview The Blazer Pro is an all-in-one server that combines Hikvision’s powerful video management system (VMS) with a video storage device. The Blazer Pro can manage up to 256 network cameras for recording, live view, and playback. -
Page 9: Front Panel
Quick Start Guide of Blazer Pro Front Panel Name Function Description Front Panel Lock You can lock or unlock the panel by the key. Hardware Normally blue when the master board works properly. Master Board Normally blue when the CMS (Central Management Server) of Indicator System the video management system running properly. -
Page 10: Rear Panel
Quick Start Guide of Blazer Pro Rear Panel Item Description AUDIO OUT RCA connector for audio output. This connector is synchronized with VGA video output. AUDIO IN RCA connector for audio input. LAN Interface LAN network interfaces. HDMI HDMI video output connector. The HDMI interfaces can also be used for video wall display. -
Page 11: Specifications
Quick Start Guide of Blazer Pro Specifications Model Blazer Pro (256-channel) Blazer Pro (128-channel) Maximum 256 Maximum 128 Number of Connected Cameras per System Number of Connected Devices or Mobile Video Maximum 256 Maximum 128 Recorders (Sold Separately) per System Number of Connected Mobile Terminals (Sold Maximum 64 Maximum 64... -
Page 12: Hdd Storage Calculation Chart
Quick Start Guide of Blazer Pro HDD Storage Calculation Chart The following chart shows an estimation of storage space used based on recording at one camera for an hour at a fixed bit rate. Bit Rate Storage Used 96 K 42 MB 128K 56 MB... -
Page 13: Basic Hardware Connection And Startup
Quick Start Guide of Blazer Pro Basic Hardware Connection and Startup Before you can access the system via network, you need to properly power on the server and connect it to network. Network Connection Note: Consult your network administrator before installing the server to avoid possible network conflicts. Use the network port on the rear panel and a network cable with RJ-45 connectors to connect the server to your system network. - Page 14 Quick Start Guide of Blazer Pro 3. Press the buttons on the panel of two sides and open the front panel. 4. Insert the hard disk along the slot until it is placed into position. 5. Repeat the above steps to install other hard disks onto the Blazer Pro. After having finished the installation of all hard disks, close the front panel and lock it with the key again.
-
Page 15: Peripheral Connections
Quick Start Guide of Blazer Pro Peripheral Connections Wiring of Alarm Input The alarm input is an open/closed relay. To connect the alarm input to the device, use the following diagram. Notes: If the alarm input is not an open/close relay, please connect an external relay between the alarm input and the device. -
Page 16: Controller Connection
Quick Start Guide of Blazer Pro 2. Unfasten stop screws from the pluggable block, insert signal cables into slots and fasten stop screws. Ensure signal cables are in tight. 3. Connect pluggable block back into terminal block. Controller Connection To connect a controller to the Blazer Pro: 1. - Page 17 Quick Start Guide of Blazer Pro other undesirable consequences. For changing the password, please refer to the help file of the operating system for detailed configuration. For your privacy, we strongly recommend changing the password to something of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
-
Page 18: For Blazer Pro Storage Device
Quick Start Guide of Blazer Pro appropriate IP settings. Click OK to save the settings. For Blazer Pro Storage Device Before you start: The Blazer Pro Storage Device (secondary board) should be properly connected to the network and the video output should be connected to a display unit. -
Page 19: Accessing Blazer Pro Via Web Manager
Quick Start Guide of Blazer Pro 3. In the General Settings interface, you can configure the following settings: Working Mode, NIC Type, IPv4 Address, IPv4 Gateway, MTU and DNS Server. Working Mode There are two 10M/100M/1000M NIC cards provided, and it allows the device to work in the Multi-address, Load Balance and Net-fault Tolerance modes. - Page 20 Quick Start Guide of Blazer Pro Steps: In the address bar of the web browser, input the address of the CMS (Central Management Server) and press the Enter key. A login window will pop up. For locally accessing the system, you can also double-click on the desktop to pop up the login window.
-
Page 21: Quick Start
Quick Start Guide of Blazer Pro If you have updated your Blazer Pro, you may need to clear the cache of your web browser to display the Web Manager page properly. Consult your IT system administrator if you do not know how to clear the cache. -
Page 22: Resource Management And Live View
Quick Start Guide of Blazer Pro click Setting. Input the Video Management System IP address that you set in Section Network Parameters Settings in CMS IP field. Click OK to save the settings. Resource Management and Live View Purpose: Before you can live view, playback via the Control Client or set recording schedule, event configuration via Web Manager, you need to add network cameras to the system and manage them by areas. -
Page 23: Area Management
Quick Start Guide of Blazer Pro Click Add and edit the parameters in the pop-up window to add the network cameras. Registration Mode: Select to add the camera via IP address or domain name. IP/Domain: Input the IP address or domain name of the camera. ... -
Page 24: Live View
Quick Start Guide of Blazer Pro Input an area name as you want. Optionally, you can select a stream media server for the area to get the video stream of the cameras belonging to this area via the server. Click Save to add the new area. In the area tree panel, click to select an element of the area. -
Page 25: Recording Schedule Settings And Playback
Quick Start Guide of Blazer Pro If failed login attempt is detected, you are required to input the verification code before you can login successfully. The account will be frozen for 10 minutes after 5 failed password attempts. Live View Steps: Open the Main View page. - Page 26 Quick Start Guide of Blazer Pro Click to select the camera for configuring the recording settings. Click Next to set the recording schedule and storage location. By default, the Storage 1 is enabled. You can check Get Device Recording Schedule checkbox to obtain the recording schedule configured on the local device.
-
Page 27: Remote Playback
Quick Start Guide of Blazer Pro Remote Playback Purpose: After configuring the recording settings for the camera via the Web Manager, the video files stored on the local device can be searched and played back remotely via Control Client. Note: Here we only introduce the playback of continuous video files. -
Page 28: Event Configuration
Quick Start Guide of Blazer Pro Event Configuration Purpose: In Blazer Pro Web Manager, you can assign linkage actions to the event by setting up a rule. For example, when motion is detected, an audible warning appears or other linkage actions happen. Log into the Blazer Pro via Web Manager, and click the Event tab to open the Event Configuration page. -
Page 29: Checking Alarm Information
Quick Start Guide of Blazer Pro 3. In the Camera field, select a camera for event configuration. You can input the key word and click Search to look for the camera. 4. Select Motion Detection as the event type for the camera. 5. -
Page 30: Shutting Down The Blazer Pro
Quick Start Guide of Blazer Pro The received alarm information (e.g., alarm time, alarm name, alarm content) lists on the Alarm Center interface. Shutting Down the Blazer Pro Press the power switch on the front panel and the server will shut down properly. Note: The password is required if you have not logged into the Blazer Pro Storage Device. - Page 31 Quick Start Guide of Blazer Pro...
