Appearance
indicator Light
2
Wiring
Safety Instruction
● In the use of the product, you must be in strict compliance with the electrical safety
regulations of the nation and region.
● The device shall not be exposed to dripping or splashing and that no objects filled
with liquids, such as vases, shall be placed on the device.
● Caurion:To reduce the risk of fire,replace only with same type and rating of fuse.
● The device must be connected to an earthed mains socket-outlet.
● If the device has been designed or, when required, modified for connection to an IT
power distribution system, the device installation instructions shall so state.
● No naked flame sources, such as lighted candles, should be placed on the device.
● This device is suitable for use in server room or cabinet only.
● Never place the device in an unstable location. The device may fall, causing serious
personal injury or death.
● Do not touch the sharp edges or corners.
● If the device is intended to be moved or used in a certain direction, keep the required
direction when moving or using the device.
PWR
PWR
Front
Side
The product meets the requirements of Class 1 laser products. Class 1 Laser
products that are safe during use, including long-term direct intrabeam viewing,
even when exposure occurs while using telescopic optics.
Do not plug and unplug optical fiber cables with electricity.
Please operate after powering off.
CHANNEL1
LINE OUT RS-485 ALARM RS-232 LAN
Rear Panel Interface of Single Channel
CHANNEL1 CHANNEL2
LINE OUT RS-485 ALARM RS-232 LAN
Rear Panel Interface of Dual Channels
ndicator Light
I
ndicator Light
POWER: Power I
Solid blue: power on.
Light off: power off.
ndicator Light
STATE: State I
Solid blue: normal working.
Flashing red: wired network exception.
Solid red: device error (including all-in-one module
error, FPGA exception, HDD error, tampering alarm).
CLASS 1 LASER PRODUCT
USB USB
USB USB
