Follow these steps in connecting the cables:

It will probably be easiest to set the base unit (the camera) on a flat
table while connecting the cables. Once you are finished, place the base
unit on top of the television set. Placing the base unit on top of the
television set while connecting cables may be awkward and the base
unit may be knocked to the ground.
At this point the PolyCom VSX 5000 is connected and ready for its first
use. The next section of this document will explain how to turn the
device on and make a call.
© Copyright 2006, Oregon State University Extension Service
Plug the LAN cable into the
base unit. Then plug the other end of the LAN cable
into the Internet jack in your wall.
Plug the audio cable into the bottom
jacks on the base unit. Then plug the other end of
the audio cable into the
on the television.
Plug the S-Video cable into the bottom
Video jack on the base unit. Then plug the other end
of the S-Video cable into the
on the television.
Plug the microphone cable into the
microphone jack on the base unit. Then plug the
other end into the microphone. After plugging a first
microphone into the base unit, a second microphone
can be plugged into the available jack on the first
microphone. See page 18 for layout options.
Plug the power cable into the
on the base unit. Then plug the other end into the
power outlet in the wall. Also ensure the television
is plugged into a power outlet on the wall.
Batteries should already be in the remote control. If
not, place three AAA batteries in the remote control.
Page 7 of 23
http://extension.oregonstate.edu/esoc/ectu/
orange LAN port on the
red and white
red and white audio in jacks
yellow
yellow S-Video in jack
brown
blue power connector
S-
