Husqvarna BZ6127TD/968999262 Operator's Manual

Husqvarna lawn mower operator's manual
Hide thumbs

Advertisement

Quick Links

Operator's manual
BZ6127TD/968999262
BZ7234TD/968999264
Please read the operator's manual carefully and make sure you
English
understand the instructions before using the machine.

Advertisement

loading

  Also See for Husqvarna BZ6127TD/968999262

  Related Manuals for Husqvarna BZ6127TD/968999262

  Summary of Contents for Husqvarna BZ6127TD/968999262

  • Page 1 Operator's manual BZ6127TD/968999262 BZ7234TD/968999264 Please read the operator’s manual carefully and make sure you English understand the instructions before using the machine.
  • Page 2 ©2005 Husqvarna All righs reserved. Beatrice, NE Printed U.S.A.
  • Page 3: Table Of Contents

    Contents ...3 Introduction ...4 Congratulations ...4 General ...4 Driving and Transport on Public Roads ...4 Operating ...4 Good Service ...5 Manufacturing Number ...5 Symbols and Decals ...6 Safety Instructions ...7 General Use...7 Driving on Slopes ...9 Children ...10 Maintenance ...10 Transport ...12 Roll Over Protection System ...13 Customer Responsibilities ...13...
  • Page 4: Introduction

    Introduction Congratulations Thank you for purchasing a Husqvarna ride-on mower. This machine is built for the greatest efficiency and rapid mowing of large areas. Conveniant controls and a hydrostatic transmission regulated by steering levers also contribute to the machine’s performance.
  • Page 5: Good Service

    Good Service Husqvarna’s products are sold only in specialized retail stores with complete service. This ensures that you as a customer receive only the best support and service. Before the product is delivered, the machine has, for example, been inspected and adjusted by your retailer, see the certificate in the Service Journal in this operator’s manual.
  • Page 6: Symbols And Decals

    SYMBOLS AND DECALS Symbols and Decals These symbols are found on the machine and in the operator’s manual. Study them carefully so that you know what they mean. WARNING! Xxxxxxxxxx xxx xxxxx xxxxxxxx. Xxxxxx xxxxx xxxxxxxxx xxxxx xxxxx xxx x xxxxx. Used in this publication to notify the reader of a risk of personal injury, particularly if the reader should neglect to follow instructions given in the manual.
  • Page 7: Safety Instructions

    SAFETY INSTRUCTIONS Safety Instructions These instructions are for your safety. Read them carefully. WARNING! This symbol means that important safety instructions need to be emphasized. It concerns your safety. General Use • Read all instructions in this operator’s manual and on the machine before starting it. Ensure that you understand them and then abide by them.
  • Page 8 SAFETY INSTRUCTIONS • Be careful when rounding fixed objects, so that the blades do not hit them. Never drive over foreign objects. • Only use the machine in daylight or in other well-lit conditions. Keep the machine a safe distance from holes or other irregularities in the ground.
  • Page 9: Driving On Slopes

    SAFETY INSTRUCTIONS Driving on Slopes Driving on slopes is one of the operations where the risk is greatest that the driver will lose control or the machine will tip over, which can result in serious injury or death. All slopes require extra caution.
  • Page 10: Children

    SAFETY INSTRUCTIONS Children: • Serious accidents may occur if you fail to be on guard for children in the vicinity of the ma- chine. Children are often attracted to the ma- chine and mowing work. Never assume that children will stay put where you last saw them. •...
  • Page 11 SAFETY INSTRUCTIONS • Allow the engine to cool before refueling. Do not smoke. Do not fill fuel in the vicinity of sparks or open flames. • If leaks arise in the fuel system, the engine must not be started until the problem has been resolved.
  • Page 12: Transport

    SAFETY INSTRUCTIONS • Never use the machine indoors or in spaces lacking proper ventilation. The exhaust fumes contain carbon monoxide, and odorless, poi- sonous, and lethal gas. • Stop and inspect the equipment if you run over or into anything. If necessary, make repairs before starting.
  • Page 13: Roll Over Protection System

    SAFETY INSTRUCTIONS Roll Over Protection System This structure’s capability may be imparired by structural damage if overturned, or al- teration occurs. If any of these conditions take place, the total structure MUST be re- placed. DO NOT use ROPS as a lifting, attaching or anchoring point. DO NOT exceed Max GVW: 3553;...
  • Page 14: Setup & Adjustment

    SETUP AND ADJUSTMENTS WARNING! No settings or adjustments are to be made unless: Engine is stopped, key has been removed, park brake is on and bat- tery cable removed from battery. Setup Uncrate machine. Seat Assembly 1. Remove inner seat latch pin `E’ ring and slide pin out to left releasing latch, spring and washer.
  • Page 15: Rops

    SETUP AND ADJUSTMENTS ROPS Assembly (Roll Over Protection System) ROPS Assembly Components 1 - Top Loop 1 - Left Side Post 1 - Right Side Post 1 - Hardware Bag 2 - 1/2” Latch Pins w/lanyard 2 - 1/2C x 3 1/4” Cap screws 2 - 1/2C Centerlock nuts 4 - 5/8C X 3”...
  • Page 16: Control Arms

    SETUP AND ADJUSTMENTS Control Arms Remove top bolt in control arm and loosen bot- tom bolt, rotate the control levers to the upright position. Align the levers so they are even in the neutral position. Reinstall hardware and tighten. FIG - 1 Wire Harness 1.
  • Page 17: Setup And Adjustments

    SETUP AND ADJUSTMENTS Mower Deck Leveling Position machine on a flat surface. Preferably level concrete. Check the tire pressure in all four tires. Inflation should be 15 psi. Place 2x4’s on edge under the cutting deck from front to rear and lower the deck down onto 2x4’s. Adjust the four lower chain bolts to the center slots on the deck.
  • Page 18: Controls

    Presentation This operator’s manual describes the Husqvarna Lever-Steered Rider Mower. The mower is fitted with a liquid cooled, 3 cylinder Daihatsu diesel engine (27 HP) or Daihatsu Turbo diesel engine (34 HP). Transmission from the engine is made via two belt-driven hydraulic pumps, which in turn drive a hydraulic motor for each drive wheel.
  • Page 19: Gauges

    Gauges Water temperature gauge- indicates coolant temperature and warns of overheat situation. Ammeter - indicates amount of electrical flow at the battery. Under normal operating conditions the needle will be slightly on the plus (+) side of the gauge, showing that current is being supplied to the battery.
  • Page 20: Engaging The Mower Deck

    Engaging the Mower Deck In order to engage the mower deck, pull the knob out; the mower deck is disengaged when the knob is depressed. Deck should be engaged at mid throttle and disengaged at idle speed to prolong clutch life. Parking Brake The parking brake is found on the left of the machine.
  • Page 21: Motion Control Levers

    Motion Control Levers The machine’s speed and direction are continuously variable using the two motion control levers. The motion control levers can be moved forward or backward from a neutral position. Furthermore, there is a neutral position, which is locked if the motion control levers are moved outward into the neutral slots.
  • Page 22: Hydraulic Lift Switch

    If the steering controls are in uneven positions when standing still, they can be adjusted using the adjustment screws, not the link system, for the controls Hydraulic Lift Switch Used to raise and lower the mower deck hydraulically. Only used on units with power deck lifts.
  • Page 23: Refueling

    Refueling The machine has two fuel tanks, one on each side just behind the seat. The tanks hold 11.4 gallons, 5.7 gallons each. The engine is run on clean, fresh, diesel fuel with a minumum of 40 cetane. WARNING! Diesel fuel is highly flammable. Observe caution and fill the tanks outdoors (see the safety rules).
  • Page 24: Hydraulic Lift For Mower Deck

    Manual Lifting Lever with Foot Assist for the Mower Deck The lifting lever is used to place the mower deck in the transport position or one of the 17 different cutting height positions. The cutting height is set by placing a pin in the hole for the desired cutting height and the pin is then locked on the inside (hidden in the illustration) with the supplied cotter pin.
  • Page 25: Relays

    Relays The relays and glow plug timer are located in a holder to the right side of the seat. Tracking The tracking knob is located in front of the left con- trol lever. Rotating this knob allows fine tuning ad- justments so that the machine tracks straight with the drive levers in the full forward position.
  • Page 26: Operation

    Running Before Starting • Read the sections Safety Instructions and Presentation before starting the machine. • Perform the daily maintenance before starting (see Maintenance Schedule Maintenance section). • Check that there is sufficient fuel in the fuel tanks. • Adjust the seat to the desired position. The following conditions must be fulfilled before the engine can be started: •...
  • Page 27 5. Move the steering controls outward to the locked (outer) neutral position. 6. Move the throttle to the middle position. OPERATION Steering controls in the outward, locked neutral position Set the throttle STEERINGPOSITIONS BAM - 2...
  • Page 28 7. Open the fuel switch for the selected fuel tank. 8. Turn the ignition key to the run position to activate the glow plug. Wait till the light goes out, then turn key to start position. IMPORTANT INFORMATION Wait till the glow plug light goes out or dam- age could result to the engine.
  • Page 29: Running

    10. Set the desired engine speed with the throttle. Allow the engine to run at a moderate speed, “half throttle”, for 1 minute before increasing the engine speed. Use full throttle when mowing. WARNING! Never run the engine indoors, in enclosed or poorly ventilated spaces.
  • Page 30 3. Select the cutting height by placing the pin in one of the holes. Lock the pin on the inside with the cotter pin. 4. Press in the stop handle, counter hold, and carefully move the lifting lever forward from the transport position toward the pin on manual units.
  • Page 31: Mowing Tips

    disengaged before the motion control levers can be moved from the neutral slots or the engine will kill. By moving the levers an equal amount forward or back the machine will move in a straight line in that direction. Movement of either lever forward will cause the right or left wheel to rotate in a forward direction.
  • Page 32 dense, the driving speed can be increased without noticeably depreciating the mowing result. • The finest lawns are obtained by mowing often. The mowing becomes more even and the grass clippings more evenly distributed over the mown area. The total time taken is not increased as a higher driving speed can be used without poorer mowing results.
  • Page 33: Stopping The Engine

    Stopping the Engine Allow the engine to idle a minute in order to attain normal operating temperature before stopping it if it has been worked hard. Avoid idling the engine for long periods. 1. Disengage the mower deck by depressing the control.
  • Page 34: Maintenance

    Maintenance Maintenance Schedule The following is a list of maintenance procedures that must be performed on the machine. For those points not described in this manual, visit an authorized service workshop. An annual service carried out by an authorized service workshop is recommended in order to maintain your machine in the best possible condition and to ensure safe operation.
  • Page 35: Checking The Safety System

    Maintenance Lubricate the steering control shafts Lubricate the mower deck’s struts Lubricate the mower deck’s cutting height adjuster Check/adjust the cutting height Change inner (safety) air filter element Clean the air cleaner’s filter cartridge (paper filter) Change the engine oil Change the hydraulic oil filter (every 300 hours) Replace the engine oil filter Replace the fuel filter (800 hours)
  • Page 36: Mower Deck Leveling

    Checking the Safety System The machine is equipped with a safety system that prevents starting or driving under the following conditions. The engine can only be started when: 1. The mower deck is disengaged. 2. The motion control levers are in the outer, locked neutral position.
  • Page 37: Checking The Engine's Cooling Air Intake

    Checking the Engine’s Cooling Air Intake Check that the engine’s cooling air intake is free from leaves, grass, and dirt. If the cooling air intake is clogged, engine cooling deteriorates, which can lead to engine damage. The radiator screen can be removed and cleaned Checking and Adjusting the Throttle Cable Check that the engine responds to throttle...
  • Page 38: Replacing The Air Filter

    Replacing the Air Filter If the engine seems weak or runs unevenly and the dust load indicator has turned red the air filter may be clogged. If run with a clogged air filter, disruption of operation can occur. Cleaning/replacing the air filter is carried out as follows Only do so when the dust indicator is red.
  • Page 39: Replacing The Fuel Filter

    Replacing the Fuel Filter The fuel filter is located with the priming pump. Replace the fuel filter every 800 hours (once per season) or more regularly if it becomes clogged. Replace the filter as follows: Unscrew fuel filter from pump and replace. Every 50 hours check for water in the fuel filter.
  • Page 40: Checking The Parking Brake

    When refilling the system, it is important that all trapped air be purged. The following procedure will help to insure this: 1. Make sure the engine is level. Fill the overflow reservoir up to the MAX mark with coolant mixture. 2.
  • Page 41: Checking The Blades

    contact between brake shoes and drum can be felt. Hold in this position. 4. Rotate clevis until clevis pin can just be inserted thru clevis and brake lever with pin resting against rear of the hole in brake lever. 5. Remove clevis pin and rotate clevis two (2) full turns toward rear to allow correct clearance between brake shoes and drum.
  • Page 42: Checking Hydraulic System

    Checking the Hydraulic System Total System Capacity...1.125 gal. To check the hydraulic fluid level, locate the hydraulic reservoir under the seat. Remove cap and check level. Fill to 1/4" from top of tank WARNING! If a leak is suspected, use a piece of cardboard or wood, NOT your hands.
  • Page 43: Caster Wheels

    Caster Wheels Check every 200 hours. Lift front of unit off of ground so caster wheels can rotate freely. Tighten caster bolt then back off 1/2 turn. Check that wheel rotates freely. If wheel does not rotate freely back the caster bolt off in 1/4 turn increments until wheel rotates freely.
  • Page 44: Cutter Housings

    MAINTENANCE Begin with either side and put the motion control lever into the neutral position. Adjust the motion control linkage by rotating the double nuts (D) in the proper direction until the wheel stops rotating. See illustration. Move the motion control lever forward then into the neutral position and place it into the neutral slot.
  • Page 45: Lubrication

    Lubrication Lubrication Schedule Lubrication schedule General Remove the ignition key to prevent unintentional movements during lubrication. When lubricating with an oil can, it should be filled with engine oil. When lubricating with grease, unless otherwise stated, a lithium based grease or another chassis or ball bearing grease, offering good corrosion protection should be used.
  • Page 46: Lubricating The Cables

    Lubricating the Cables If possible, grease both ends of the cable and move the controls to end stop positions when lubricating. Refit the rubber covers on the cable after lubrication. Cables with sheaths will bind if they are not lubricated regularly.
  • Page 47 3. Engine Oil Changing the Engine Oil Change the engine oil and filter for the first time after 50 hours of operation. Thereafter, the oil should be changed every 150 hours and the filter every other oil change. WARNING! Engine oil can be very hot if it is drained directly after stopping the engine.
  • Page 48 The oil level should be between the markings on the dipstick. If the level is approaching the “ADD” mark, add the oil to the “FULL” mark on the dipstick. Never fill above the “FULL” mark. The oil is topped off through the dipstick hole. Use engine oil SAE 30 or SAE 10W-30 or, alternately, 10W/40, class CF - 4, CI - 4 (over 0 °C/+32 °F).
  • Page 49 5. Front Wheel Mount Lubricate with a grease gun, one zerk for each wheel mount, use 10 pumps of the grease gun at the recommended service intervals. Use only good quality lithium based grease. Grease from well-known brand names (petrochemical companies, etc.) usually maintains a good quality.
  • Page 50 9. Steering Control Shafts Tip the driver’s seat. Lubricate with a grease gun, one zerk for each steering control shaft, until the grease is forced out. Use only good quality lithium based grease. Grease from well-known brand names (petrochemical companies, etc.) usually maintains a good quality.
  • Page 51 12. Belt Adjuster, Hydraulic Pumps Lubricate using a grease gun, one zerk, until the grease squeezes out. Use only good quality lithium based grease. Grease from well-known brand names (petrochemical companies, etc.) usually maintains a good quality. IMPORTANT INFORMATION Be careful and remove excess lubricant so that is does not come into contact with belts or belt pulley drive surfaces.
  • Page 52: Trouble Shooting Guide

    TROUBLE SHOOTING GUIDE Trouble Shooting Guide Problem The engine will not start. The starter motor does not turn the engine over. The engine seems weak. Cause • The control for engaging the mower deck is not depressed. • The steering controls are not locked in the neutral position.
  • Page 53 TROUBLE SHOOTING GUIDE The engine overheats. Battery not charging. The machine moves slowly, unevenly, or not at all. Mower deck not engaging. Uneven mowing results. • Clogged air intake or cooling fins. • Engine overloaded. • Poor ventilation around engine. •...
  • Page 54 TROUBLE SHOOTING GUIDE The machine vibrates. • The blades are loose. • The blades are incorrectly balanced. • The engine is loose. • Wheels loose.
  • Page 55: Storage

    Service When ordering spare parts, please specify the purchase year, model, type, and serial number. Always use genuine Husqvarna spare parts. An annual check-up at an authorized service workshop is a good way to ensure that your machine performs its best the following season.
  • Page 56: Technical Data

    Technical Data Measurements, Weights, Etc. Length Width (lowered discharge chute) Width (raised discharge chute) Height Weight Cutting width Cutting height Air pressure, front and rear Tires, front Tires, rear Driver’s seat Speed, forward Speed, backward Engine Manufacturer Models Power Cooling System Coolant Cylinder volume Max.
  • Page 57: Noise Emissions And Cutting Width

    Clutch Electric w/intragal stop brake rating torque rating 300 ft./lbs. Noise Emissions and Cutting Width Measured noise level Guaranteed noise level Cutting width Electrical System Type Battery Primary fuse Electric clutch ransmission Hydrostatic drive Hydraulic oil, volume Hydraulic oil, type Mower Deck Cutting width Cutting height...
  • Page 58: Service Journal

    Service Journal Action Delivery Service 1. Charge the battery. 2. Mount the rear wheels. 3. Adjust the tire pressure of all wheels to 16 PSI. 4. Mount the steering controls in the normal position. 5. Connect the lever to the seat stop. 6.
  • Page 59: Delivery Service

    Action Inform the customer about: The need and advantages of following the service schedule. The need and advantages of leaving the machine for service every 300 hours. The effects of service and maintaining a service journal on the machine’s resale value. Application areas for Mulch kit.
  • Page 60: 25-Hour Service

    SERVICE JOURNAL Action Date, mtr reading, stamp, sign 25-Hour Service 1. Check the hydraulic system’s oil level. 2. Check the tire pressures. 3. Lubricate the belt adjuster, mower deck. 4. Lubricate the belt adjuster, hydraulic pumps. 5. Lubricate the belt adjuster, mule drive.
  • Page 61: 50-Hour Service

    SERVICE JOURNAL Action Date, mtr reading, stamp, sign 50-Hour Service 1. Perform the 25-hour service. 2. Change oil and oil filter for the first time. See engine manual. 3. Check dust load indicator on air filter.Change filter only if indicator is red. See engine manual. 4.
  • Page 62: 100-Hour Service

    SERVICE JOURNAL Action Date, mtr reading, stamp, sign 100-Hour Service 1. Perform the 25-hour service. 2. Perform the 50-hour service. 3. Change engine oil at 150 hours. See engine manual. 4. Check fuel pump filter. See engine manual. 5. Check fan belt clearance. See engine manual. 6.
  • Page 63: 300-Hour Service

    SERVICE JOURNAL Action Date, mtr reading, stamp, sign 300-Hour Service 1. Inspect the machine. Come to agreement with the customer as to which additional work is to be carried out. 2. Perform the 25-hour service. 3. Perform the 50-hour service. 4.
  • Page 64: At Least Once Each Year

    Action At Least Once Each Year 1. Replace the air cleaner’s safety element. 2. Replace the air filter’s paper cartridge. 3. Change the engine oil (150 hours). 4. Replace the engine oil filter (300 hours). 5. Change the oil and filter in the hydraulic system (300 hours).
  • Page 66 110889R02 08/11/05...
