- Page 1 VLS SERIES Professional loudspeakers Operation Manual...
-
Page 2: Important Safety Instructions
The lightning ash with arrowhead symbol within an equilateral triangle, is intended to alert the user to the Important Safety Instructions presence of uninsulated "dangerous voltage " within the product's enclosure that may be of su cient magnitude to constitute a risk of electric shock to persons. The lightning ash with arrowhead symbol within an The exclamation point within an equilateral triangle is equilateral triangle, is intended to alert the user to the... -
Page 3: Table Of Contents
Table of Contents Table of Contents 2. Introduction ................................ 4 3. Unpacking ................................4 4. Selection of operating mode ..........................5 5. Wiring and connections ............................ 6 5.1 Connector type ..............................6 5.2 Low-impedance mode ............................ 6 5.3 Constant voltage (70 /100 V) Mode ......................... 7 5.4 Wiring for EN54 and outdoor applications ....................... 8 6. Polarity checking ............................... 8 7. -
Page 4: Introduction
2. Introduction 2. Introduction The latest addition to Tannoy’s extensive line of column loudspeakers, VLS Series introduces another proprietary Tannoy innovation: FAST™ (Focussed Asymmetrical Shaping Technology). By combining transducer technology from the acclaimed QFlex Series with an innovative new passive crossover design, FAST provides exceptional acoustical benefits, including an asymmetrical vertical dispersion pattern which gently shapes acoustical coverage toward the lower quadrant of the vertical axis. The VLS Series comprises three models. The VLS 7 (7 × 3.5” LF) is designed for speech-only applications while VLS 15 (7 × 3.5” LF with 8 × 1” HF) and VLS 30 (14 × 3.5” LF and 16 × 1” HF) are designed for more demanding full-range music applications as well as speech. All are IP65 rated for dust and water ingress, are resistant to salt spray and UV, and have been subjected to rigourous high/low operational temperature and humidity testing. The VLS 7 and 15 are EN54 certified for use in fire detection and fire alarm systems. The loudspeakers are suitable for both indoor applications (house of worship, retail malls, auditoria) as well as covered outdoor use (transport hubs, concourses). Easy mounting is facilitated via supplied wall and flying brackets, with an optional pan-tilt bracket available. Aided by an addition of an exclusive Tannoy edition of EASE Focus v2.0 software, consultants can design systems with predictable results and also specify VLS Series in conjunction with Tannoy’s existing column loudspeakers – including I Series and QFlex – within the familiar environs of an industry standard software wizard. VLS Series loudspeakers can easily be switched from low-impedance mode (6 ohms for VLS 30, 12 ohms for VLS 7 and VLS 15) to 70/100 V distributed line operation. For quick and simple commissioning, this selection is made (along with the transformer tapping options) via a single rotary switch located on the rear termination. For applications requiring extended low frequency enhancement, a range of Tannoy sub-bass systems are available for use in conjunction with the VLS Series. 3. Unpacking Each Tannoy VLS Series loudspeaker is carefully tested and inspected prior to shipment. After unpacking, please inspect for any exterior physical damage, and save the carton and any relevant packaging materials in case the loudspeaker again requires packing and shipping. In the event that damage has been sustained in transit, please notify your dealer and the shipping carrier immediately. VLS Series Operation Manual rev 1.1.0... -
Page 5: Selection Of Operating Mode
4. Selection of operating mode 4. Selection of operating mode All VLS Series models can be operated as either a low-impedance loudspeaker or within a 70/100 V distributed system. The operation mode is selectable via a single switch located on the rear of the cabinet. Low-impedance mode is recommended if the cable runs are relatively short and the number of speakers is small. If, on the other hand, the cable runs are long and more than a few loudspeakers are required, then a distributed line system is ideal. When operating in low-impedance mode, the loudspeaker is able to deliver a wider frequency and dynamic range. However, if the cable runs are excessively long, then the sound quality may be compromised due to the increase in cable resistance and the resulting power losses. To keep the load to the amplifier manageable, it is also recommended that a small number of speakers be used, thus avoiding complex series/parallel combinations. When a large number of speakers are installed over long cable runs, it is recommended that a distributed (70/100 V) system be used. For distributed line, the cable need not have as large a cross sectional area as for low-impedance, resulting in savings in cable cost. All speakers are placed in parallel with the output of the amplifier, allowing easy installation. The wattage tappings can be individually adjusted, giving more flexibility within an installation. VLS Series Operation Manual rev 1.1.0... -
Page 6: Wiring And Connections
5. Wiring and connections 5. Wiring and connections 5.1 Connector type Each VLS Series loudspeaker is equipped with a pair of internally paralleled barrier strip terminals for connection to the amplifier (or to other loudspeakers in a 70/100 V system or series/parallel configuration). Barrier strips accept wire up to 4 mm sq CSA (AWG 12). Barrier strip polarity is as indicated. 5.2 Low-impedance mode If connecting directly to the amplifier in low-impedance mode, connect the positive (+) conductor to a positive (+) barrier strip terminal and the negative (-) conductor to a negative (-) terminal. Several loudspeakers may be connected to one amplifier output in parallel, series, or series/parallel configurations using the other internally paralleled barrier strip connector. Please refer to following section on series/parallel configuration before connecting. When choosing cable type, it is important to select the correct cross sectional area in relation to the cable length and the load impedance. A small cross sectional area will increase the cable’s series resistance, inducing power loss and response variations (damping factor). Connectors wired with 2.5 sq. mm (12 AWG) cable will satisfactory under normal conditions; with very long cable runs, the wire size should be increased. Please refer to the following table for guidance: Cable Run C.S.A.of Cable % Power dB loss into % Power dB loss into each resistance loss into... -
Page 7: Constant Voltage (70 /100 V) Mode
5. Wiring and connections is continually clipping. A high-powered amplifier running at less than 90% of output power generally sounds superior to a lower power amplifier running at 100%. An amplifier with insufficient drive capability will not allow the full performance or the loudspeaker to be realised. (See technical specifications section for recommended amplifier power.) When using amplifiers from different manufacturers in a single installation, make certain that all amplifiers have closely matched gains. (Variation should be less than +/- 0.5 dB.) This precaution is important to the overall system balance when only a single active crossover is being used with multiple cabinets. When possible, it is recommended that the same amplifiers be used throughout. Series/parallel connections - When running low-impedance loudspeakers in parallel, care must be taken not to allow the impedance to drop too low, as damage may be sustained by the amplifier. Most low impedance amplifiers will be able to handle loads of 2 ohms to 8 ohms. This means for example that when using an amplifier with 2 ohm load rating, up to three VLS 30 or six VLS 7/15 may be connected in parallel per output, although care should be taken as impedance varies with frequency and at some frequencies the impedance will drop to below 2 ohms. 5.3 Constant voltage (70 /100 V) Mode In constant voltage distributed systems, normally a number of loudspeakers are connected in parallel to a single amplifier output. Connect the positive (+) conductor from the amplifier or prior loudspeaker in the system to a positive (+) barrier strip terminal and the negative (-) conductor to a negative (-) terminal. The other parallel barrier strip is available for connecting additional loudspeakers. A multi-position rotary switch on the rear input panel selects either the low-impedance operating mode or the high-impedance modes (70 V or 100 V) with available transformer taps. When using VLS Series loudspeakers in distributed line systems, the transformer can be tapped with available power levels shown in the table below: 70 V 100 V 9.5 W 9.5 W 19 W 19 W 37.5 W 37.5 W... -
Page 8: Wiring For En54 And Outdoor Applications
6. Polarity checking All transformer primaries should be connected in parallel to the output of the amplifier. The summed total power rating in watts of the selected tap settings for all connected loudspeakers must not exceed the total output power rating of the connected amplifier output channel in watts. It is recommended that a generous power safety margin (minimum 3 dB headroom) be maintained between the total loudspeaker power requirements and the amplifier output capacity to avoid continuous amplifier operation at full rated output. 5.4 Wiring for EN54 and outdoor applications A right angled water tight cable gland is supplied with the VLS 7 and 15 for use in outdoor applications (Fig.1). The VLS 30 has an input panel cover with rubber wiring grommet for use in outdoor applications (Fig.2). Before making connections, pass the wire(s) through the cable grand/rubber grommet. The input panel cover is secured to the cabinet using the four screws already inserted around the input. Fig.1 VLS 7 & VLS 15 Fig.2 VLS 30 6. Polarity checking Checking the polarity of the wiring before the speaker system is mounted or flown will help ensure satisfactory performance. If you do not have a pulse-based polarity checker, you may check LF units as follows: Connect two wires to the + and - terminals of a PP3 (9 V) battery. Apply the wire connected to the positive (+) terminal of the battery to the speaker cable leg which you believe to be connected the positive terminal of the speaker connector; likewise connect the negative (-) terminal of the battery to the negative terminal of the speaker. If you have wired it correctly, the LF drive unit will move forward. At this point, connect the positive (+) speaker lead to the + terminal on the amplifier and the negative (-) lead to the - terminal on the amplifier. However, if the LF driver moves backwards with the battery test, the input connections need to be inverted before connecting the amplifier. If problems are encountered, inspect the cable wiring. Note that different amplifier manufacturers may utilise different pin configurations and polarity conventions; if you are using amplifiers from... -
Page 9: Equalisation
8. Mounting and flying 8.1 Asymmetrical pattern considerations VLS Series loudspeakers are designed with an asymmetrical vertical dispersion pattern, a feature which allows improved performance with simplified mounting in many applications. The vertical dispersion of the VLS 7 and VLS 15 is +6 / -22 degrees from acoustic center axis, while the pattern of the VLS 30 is +3 / -11 degrees from acoustic center axis. Please be aware of this feature when planning your installation. In many situations where conventional column loudspeakers would require substantial downward tilt, a VLS Series loudspeaker would require less tilt or even allow flush mounting, thus providing a simpler installation with improved visual aesthetics. VLS 7 VLS 15 VLS 30 +6° +6° -22° -22° 536 [21,11] 536 [21,11] +3° -11° 671 [26,41] VLS Series Operation Manual rev 1.1.0... -
Page 10: Mounting And Flying Hardware
8. Mounting and flying 8.2 Mounting and flying hardware Wall Bracket – Each VLS Series loudspeaker is supplied with a standard wall bracket suitable for mount- ing on most wall surfaces. The bracket is supplied as two interlocking U plates. One plate attaches to the rear of the loudspeaker with four supplied screws. The other part is secured to the wall. The bar on the bottom of the speaker plate slides into the bottom notch of the wall plate, while the top is secured with the two supplied screws. The bracket for the VLS 7 and 15 is slotted to allow an angle between 0 and 6 degrees (Fig.3). Aligning the top two screw holes of the VLS 30 results in a flat flush mount; using the lower two screw positions provides a 4 degree downward tilt. (Fig.4) Fig.3 VLS 7 & VLS 15 Fig.4 VLS 30 Flying Bracket – Each VLS Series loudspeaker is also supplied with a flying bracket. The bracket is attached to the top two inserts using the supplied M6 screws (Fig.5). The two bottom inserts can be used as pull back if required. VLS Series Operation Manual rev 1.1.0... -
Page 11: Rigging And Safety Procedures
8. Mounting and flying Pan-Tilt Bracket (optional) – A pan-tilt bracket is available which allows panning and tilting for flexible orientation along both horizontal and vertical axes. Detailed installation instructions are included with the pan-tilt bracket. 8.3 Rigging and safety procedures WARNING: As the legal requirements for mounting, suspending, hanging, flying or rigging equipment change from country to country, please consult your local safety standards office before installing any product. We also recommend that you thoroughly check any laws and bylaws prior to installation. The installation of Tannoy loudspeakers using the dedicated hardware should carried out only by fully qualified installers in accordance with all the required safety codes and standards that are applied at the place of installation. The Tannoy professional hardware covered in this guide has been designed to offer quick, simple, cost effective and secure solutions for mounting specific Tannoy professional loudspeakers. This hardware has been designed and manufactured with a high safety load factor for its specific role. To ensure the safest possible use of the hardware covered in this guide, it must be assembled in strict accordance with the instructions specified. The information in these Operation Manuals relating to the assembly and the safe use of these accessories must be understood and followed. Tannoy professional hardware has been designed for use with specific Tannoy professional loudspeakers, and is not designed or intended for use with any other Tannoy professional products, or any other devices. Using Tannoy professional hardware for any purpose other than that indicated in this guide is considered to be improper use. Such use can be very dangerous: overloading, modifying, damaging, or assembling in a manner other than that clearly stated in the operation will compromise safety. The component parts of any Tannoy professional hardware device must only be assembled using the accessory kits supplied and in strict compliance with the Operation Manual. The use of other accessories or non-approved methods of assembly may result in an unsafe hardware system by reducing the load safety factor. Welding, or any other method of permanently fixing hardware components together or to the integral fixing points in the cabinet, should never be used. Whenever a Tannoy professional loudspeaker is fixed to a surface using a Tannoy professional hardware device, the installer must ensure that the surface is capable of safely and securely supporting the load. The hardware employed must be safely and securely attached both to the loudspeaker and also to the surface in question, in accordance with the Operation Manual, using only the fixing holes provided as standard and covered in the manual. Secure fixings to the building structure are vital. Seek help from architects, structural engineers or other... -
Page 12: Outdoor Applications
9. Outdoor applications 9. Outdoor applications VLS Series loudspeakers are rated IP65 for resistance to dust and moisture ingress, and are resistant to both salt spray and UV exposure, making them suitable for use in most outdoor applications. Please consult with your Tannoy dealer before installation in applications with extreme exposure to adverse environmental conditions such as prolonged heavy rainfall, prolonged temperature extremes, etc. VLS Series Operation Manual rev 1.1.0... -
Page 13: Technical Specifications
10. Technical Specifications 10. Technical Specifications 10.1 VLS 7 Performance Ordering Information Frequency response (-3 dB) 150 Hz - 11 kHz Part Number Colour Frequency range (-10 dB) 110 Hz - 14 kHz 8001 7860 Black System sensitivity (1 m, LoZ) 90 dB 8001 7861 White Sensitivity as per EN54... -
Page 14: Vls 15
Transformer Taps (via front rotary switch) radiation in the vertical plane is - 8 ° below 70 V 150 W (33 Ω) / 75 W (66 Ω) / 37.5 W (133 Ω) / 19 W (265 Ω) / horizontal. 9.5 W (530 Ω) / 5 W (1050 Ω) OFF & low impedance operation A full range of measurements, performance 100 V 150 W (66 Ω) / 75 W (133 Ω) / 37.5 W (265 Ω) / 19 W (530 Ω) / data, CLF and Ease™ Data for VLS 15 can be 9.5 W (1050 Ω) OFF & low impedance operation downloaded from www.tannoypro.com. Coverage angles Tannoy operates a policy of continuous research Horizontal plane Vertical plane and development. The introduction of new materials 500 Hz 226° 80° or manufacturing methods may introduce variations 1 kHz 191° 41° in actual performance; however, actual performance always will equal or exceed the published 2 kHz 131°... -
Page 15: Vls 30
Long term power handling capacity as defined Average 120 dB in EIA - 426B test Peak 126 dB A full range of measurements, performance Transformer Taps (via front rotary switch) data, CLF and Ease™ Data for VLS 30 can be 70 V 150 W / 75 W / 37.5 W / 19 W / 9.5 W / 5 W downloaded from www.tannoypro.com. OFF & low impedance operation 100 V 150 W / 75 W / 37.5 W / 19 W / 9.5 W Tannoy operates a policy of continuous research OFF & low impedance operation and development. The introduction of new materials or manufacturing methods may introduce variations in actual performance; however, actual performance Distortion always will equal or exceed the published 10% full power Harmonics specifications, which Tannoy reserves the right to alter without prior notice. Please verify the latest 250 Hz 1.60% 0.91% specifications when dealing with critical applications. -
Page 16: Service Parts And Accessories
Tweeter - 0305 1” HF 12. Warranty No maintenance of the VLS Series loudspeakers is necessary. All Tannoy VLS Series professional loudspeaker products are covered by a 5 year warranty from the date of manufacture, subject to the absence of misuse, overload or accidental damage. Claims will not be considered if the serial number has been altered or removed. Work under warranty should only be carried out by a Tannoy Professional dealer or service agent. This warranty in no way affects your statutory rights. For further information please contact your dealer or distributor in your country. If you cannot locate your distributor please contact Customer Services, Tannoy Ltd at the address given below or check at www.tannoypro.com. Customer Services Tannoy Ltd. Rosehall Industrial Estate Coatbridge Strathclyde ML5 4TF Scotland Tel: 01236 420199 (National) +44 1236 420199 (International) Fax: 01236 428230 (National) +44 1236 428230 (International) Support: http://support.tannoy.com DO NOT SHIP ANY PRODUCT TO TANNOY WITHOUT PREVIOUS AUTHORISATION VLS Series Operation Manual rev 1.1.0... -
Page 17: Declaration Of Conformity
13. Declaration of conformity 13. Declaration of conformity (in accordance with ISO/IEC 1750-1) Document No: CE-VLS-1 We: Tannoy Ltd Rosehall Industrial Estate, Coatbridge, ML5 4TF, United Kingdom In accordance with the following Directive(s): 2004/108/RC Electromagnetic Compatibility (EMC) 2011/65/EU Restriction of the use of certain hazardous substances (RoHS) Hereby declare that: Type of equipment Column loudspeakers Models VLS 7, VLS 15, VLS 30 Is/are in conformity with the requirements of the following documents: Ref. No Title Edition BS EN 55103-1 Electromagnetic compatibility. Product family standard for audio, video, audio-visual and entertainment lighting control apparatus 2009 for professional use. Emissions BS EN 55103-2 Electromagnetic compatibility. Product family standard for audio, video, audio-visual and entertainment lighting control apparatus 2009 for professional use. Immunity Name: Philippe Robineau Position:... - Page 18 All specifications are subject to change without notice. FAST is a trademark of Tannoy Limited. All other trademarks remain the property of their respective owners. Copyright (c) 2014 Tannoy Limited. All rights reserved.
