Summary of Contents for Hoover Vacuum Cleaner
- Page 1 Owner’s Manual Operating and Servicing Instructions ® www.hoover.com ©2007 All rights reserved. #17-01-58-058-00-H301 Review this manual before operating the cleaner. 6/07...
-
Page 2: Table Of Contents
Parts & accessories mail reorder form ........17-18 If you need assistance: Visit our website at hoover.com. Click on the “Customer Service” link to find the service outlet nearest you OR Call 1-800-944-9200 for an automated referral of authorized service outlet locations (U.S. -
Page 3: Important Safeguards
• Close supervision is necessary when any appliance is used by or near children. Do not allow vacuum cleaner to be used as a toy or to run unattended at any time. • Keep hair, loose clothing, fingers, feet and all parts of body away from openings, rotating agitator and other moving parts. -
Page 4: Cleaner Assembly
1. CLEANER ASSEMBLY Carton contents A. Handle section B. Cleaner base and upper housing assembly C. Cleaning tools and wands D. Powered Hand Tool Remove all parts from carton and identify each item shown. Make sure all parts are located before disposing of packing materials. -
Page 5: How To Use
2. HOW TO USE Cleaner Description 1. Soft Touch handle grip 2. ON/OFF switch 3. Hose 4. Dirt cup release button 5. Dirt cup assembly 6. Hose handle 7. Cord reel window 8. Headlight 9. Nozzle control knob: turn knob to correct setting for height of carpet being cleaned. -
Page 6: Transporting Cleaner
Cord Transporting Handle Rewind Cleaner Positions Grasp the end The handle of the plug of your and pull to cleaner release cord has three from cord positions; reel. After upright for desired cord storage and length is when using reached, the cleaning cord will lock tools;... -
Page 7: Cleaning Tools
3. CLEANING TOOLS Tools allow for cleaning surfaces above the floor and for reaching hard to clean areas. The cleaner is ready for tool use when handle is in upright position. The agitator brush roll will not rotate when the cleaner is in the upright position or the if the agitator brush roll shut off indicator is in the OFF position when the handle is lowered. -
Page 8: Maintenance
Combination Tool Stair Cleaning Use the hose and powered hand tool for stair cleaning. Clean from bottom to top. CAUTION: To avoid personal injury or unnecessary wear to carpet, and to prevent the cleaner from falling, always place it at bottom of stairs. Slide brush to remove. -
Page 9: Filters
Dirt Cup (cont.) How to Empty Press dirt cup release button (A) and pivot Holding dirt cup over trash receptacle, press cup out. dirt cup door release button (A) to open dirt cup door (B). Close door and press dirt cup door release button to latch dirt cup door closed. -
Page 10: Headlight
Secondary Filter: What to Buy When purchasing a new secondary filter cartridge, ask for HOOVER part No. 93002517. To purchase a new black foam filter, ask for HOOVER part No. 93002518. HEPA Final Filter: How to Clean Disconnect cleaner from electrical outlet. -
Page 11: Belt
(B) next to pulley. Belt will “pop” into place. roll through belt and position belt in V-Belt: What to Buy groove (A) on agitator Use only genuine HOOVER belts with your cleaner. When purchasing a brush roll. new belt, ask for V belt - HOOVER part No. 40201-200. -
Page 12: Agitator Brush Roll
Reposition flat belt and bottom plate (Figs. 4-15 Agitator Brush Roll: What to Buy to 4-16). When purchasing a new Agitator Brush Roll, ask for HOOVER part No. 93002361. Powered Hand Tool Replacing Agitator Brush Roll When agitator brushes are worn, the brush roll should be replaced. -
Page 13: Power Hand Tool Belt
Agitator Brush Roll: What to Buy and snap closed. When purchasing a new Powered Hand Tool Agitator Brush Roll, ask for HOOVER part No. 48414-088. Belt Replacement The powered hand tool belt is designed to last a long time and is not normally replaced. However, if the belt is cracked, gouged or broken, it should be replaced. -
Page 14: Lubrication
The agitator brush roll is equipped with two ball Cleaners - Household” bearings that should be lubricated periodically -OR - by a Hoover Sales and Service Center or an • checking the Service section of Hoover on-line Authorized Hoover Warranty Service Dealer. at hoover.com -OR - •... -
Page 15: Troubleshooting
1. Bulb burnt out. 1. Replace bulb - Pg. 10. working 2. Loose electrical wires. 2. Call 1-800-944-9200 for nearest authorized Hoover dealer. ® Cleaner is difficult 1. Carpet height setting is incorrect. 1. Set carpet height adjust lever to appropriate to push or won’t... -
Page 16: Clearing Blockages
Clearing Blockages Disconnect cleaner from electrical outlet. Low suction or pick up may be due to a blockage in the system. Refer to the following steps to check for blockages continuing with each step until the blockage is found: Fullness of Check Airflow Check Secondary Dirt Cup... -
Page 17: Warranty
For an automated referral of authorized service outlets household use, in accordance with the Owner’s in the U.S.A., phone 1-800-944-9200 OR visit Hoover Manual against original defects in material and on-line at hoover.com workmanship for a period of This warranty provides,... - Page 18 Signature (req.) ______________________________________________________ Replacement parts and accessory items may be purchased from your Authorized Hoover Dealer, Leading Retailers, Hoover Sales & Service Centers, on-line at www.hoover.com, or by completing this order form. Mail orders limited to U.S. residents only. OR on-line at hoover.ca In Canada, please call 1-800-263-6376 Please allow 3-4 weeks for delivery.
- Page 19 Ship to: (please print clearly) Name _____________________________________________________________ Street ________________________City _______________State ____ Zip _______ Payment Method: ❏ Check or Money Order made payable to: The Hoover Company ❏ Visa ❏ Mastercard ❏ Discover Number ____________________________________ Exp. Date ________________ Name on Card _______________________________ Day Phone ( ) __________ Signature (req.) ______________________________________________________...
- Page 20 Formulario para el pedido por correo de piezas y accesorios ....17-18 Si necesita asistencia: Visite nuestra página en Internet hoover.com. Haga clic en el botón “Customer Service” para encontrar el centro de servicio más cercano a usted O llame al 1-800-944-9200 para obtener una referencia MERCANCIA TOTAL automatizada de las ubicaciones de los centros de servicio autorizados (solamente en EE.UU.) O llame...
- Page 21 Centro de ventas y de servicio de Hoover o al Concesionario autorizado de servicio de garantía de Hoover (Depósito).
-
Page 22: Position Tools
1. ENSAMBLADO DE LA ASPIRADORA Contenido de la caja A. Sección del mango B. Ensamblado de la base y conjunto del cuerpo superior de la aspiradora C. Accesorios de limpieza y tubos de extensión D. Accesorio de mano turboaccionado Saque todos los componentes de la caja e identifique cada pieza que se muestra. - Page 23 Eliminación de obstrucciones 2. CÓMO USAR LA ASPIRADORA Desconecte la aspiradora de la toma de corriente eléctrica. Descripción de la aspiradora La succión o aspiración baja se puede deber a una obstrucción en el sistema. Consulte los siguientes pasos a fin de revisar si hay obstrucciones, siguiendo los pasos uno a uno hasta que encuentre la obstrucción: 1.
- Page 24 2. Cables eléctricos sueltos. 2. Llame al 1-800-944-9200 para encontrar al espesores, gire la perilla de control de Distribuidor Hoover ® más cercano a su domicilio. la boquilla (B) a la posición deseada.
- Page 25 HOOVER, localice el Centro de difíciles de limpiar. La adición de lubricantes podría causar daños. ventas y de servicio de Hoover o el Concesionario La aspiradora está lista para usarse con los accesorios cuando el mango está en posición vertical. Por lo tanto, autorizado de servicio de garantía de Hoover...
- Page 26 No. Deslice la manguera en las ranuras y gire la manguera para cerrarla. 48414-088 de HOOVER. para trabarla en su lugar. (Para desconectar la manguera, invierta el procedimiento). Coloque los tubos o accesorios en el otro extremo de Reemplazo de la correa la manguera.
- Page 27 Vuelva a colocar la correa plana y la placa inferior Cuando compre un agitador nuevo, pida la pieza (figuras 4-15 a 4-16). No. 93002361 de HOOVER. Accesorio de mano turboaccionado Reemplazo del rodillo de escobillas del agitador El rodillo de escobillas se debe reemplazar cuando las escobillas del agitador estén gastadas.
- Page 28 (A). Cuando compre un nuevo cartucho de filtro secundario, pida la pieza No. 93002517 de HOOVER. Cuando Coloque el otro compre un nuevo cartucho de espuma de goma negra, pida la pieza No. 93002518 de HOOVER.
