Figure 1.1: Example Server Console Switch Configuration
Table 1.1: Descriptions for Figure 1.1
Number Description
1
UTP Connection
Local KVM Connection to
2
the Server Console Switch
3
Remote IP Connection
Server Console Switch
4
(2161AD shown)
xxx |
6
Product Overview
Number
5
6
7
8
xxx
Description
Ethernet
Digital Users (computer with Internet
Browser for OBWI or RCS Software
and/or Avocent Management Software
Server [requires the Dell RAK])
Local Analog Users (OSCAR Interface
and/or Local LCD Tray)
Servers/Target Devices
