Infinity PRELUDE Owner's Manual page 6

SPEAKER
TOWER
BRACKET
GUIDES
SUBWOOFER
S 7
– Slowly lower the tower assembly onto the
TEP
subwoofer, being careful to insert the alignment pins into
receptacle guide holes.
PRELUDE MTS TOWER
6
SPEAKER
TOWER
10-32 SOCKET
HEAD SCREWS
SCREW
CAPS
SCREW-CAP
ALIGNMENT
SLOTS
GUIDE
HOLES FOR
ALIGNMENT
PINS
S 8
TEP
through the tower base as shown: two through the front baffle
and two in the rear slot. Press flush into place two screw caps to
hide holes in front baffle base. Make sure that the alignment
slots point toward the center to assure that the surface curve
matches that of the baffle.
FRONT VIEW
REAR VIEW
SPEAKER
TOWER
REAR SLOT
IN BOTTOM
OF SPEAKER
TOWER
– Fasten the four 10-32 Socket Head Screws
10-32 SOCKET
HEAD SCREWS
REAR SLOT
IN BOTTOM
OF SPEAKER
TOWER
SUBWOOFER
10-32 SOCKET
HEAD SCREWS
