- Page 1 ™ MTS W RELUDE RACKETS Installation Guide • Prelude MTS-WB Wall Brackets for use with Prelude MTS Tower • Prelude MTS-WBC Wall Brackets for use with Prelude MTS Center...
- Page 2 Toggle Switch in tower cup in bottom to the “Full Range” position. Please consult the Prelude MTS Subwoofer manual for exceptions to this setting. – When mounting each bracket to the wall, try and position it so that you anchor it to wall studs.
- Page 3 SPEAKER SPEAKER LEFT BRACKET securely into place. SPEAKER BRACKET WALL BRACKET CAPS Center: Place left and right Speaker Brackets in back slots of Speaker. Insert (2) longer 10-32 Socket Head Screws provided in each and tighten. PRELUDE MTS WALL BRACKETS...
- Page 4 © 1999 Infinity Systems, Inc., 250 Crossways Park Drive, Woodbury, NY 11797 USA (800) 553-3332 (USA Only) Part No. PREMTSWB Infinity is a registered trademark of Infinity Systems, Inc. Printed in USA 11/99...
