Infinity Primus Series P142 Specifications

I P ®
NFINITY RIMUS :
C F C V
APTIVATING IDELITY , OMPELLING ALUE .
Begin by listening.You'll encounter a level
of realism and subtlety beyond what you've
known – even in the music and movies
you know by heart.
Then look.You'll be struck by the simplicity
of a purely functional design that's
also a pleasure to the eye.
Next, factor in the distinguished heritage
of these loudspeakers, as well as the
extraordinary value they represent.
Only then will you fully appreciate what
Infinity engineers have accomplished –
an ideal synthesis of technology, perform-
ance and design destined to transform
your home entertainment experience –
with the Infinity Primus ® Series.
S
PECIFICATIONS .
P142 P152 P162 P252 P362
Frequency Range (±3dB) 100Hz – 20,000Hz 58Hz – 20,000Hz 49Hz – 20,000Hz 49Hz – 20,000Hz 38Hz – 20,000Hz
Recommended 10 – 100 Watts 10 – 100 Watts 10 – 150 Watts 10 – 150 Watts 10 – 200 Watts
Amp Power Range
Sensitivity 86dB 88dB 90dB 92dB 93dB
(2.83V 1 meter)
@
Nominal Impedance 8 Ohms 8 Ohms 8 Ohms 8 Ohms 8 Ohms
Crossover Frequency 3,000Hz; 24dB/octave 3,300Hz; 24dB/octave 3,000Hz; 24dB/octave 2,500Hz; 24dB/octave 350Hz, 3,300Hz; 24dB/octave
Low-Frequency Driver(s) 4" (100mm) MMD, ® 5-1/4" (130mm) MMD, ® 6-1/2" (165mm) MMD, ® Dual 5-1/4" (130mm) MMD, ® Dual 6-1/2" (165mm) MMD,
magnetically shielded magnetically shielded magnetically shielded magnetically shielded magnetically shielded
Mid-Frequency Driver(s) N/A N/A N/A N/A 4" (100mm) MMD,
magnetically shielded
High-Frequency Driver 3/4" (19mm) MMD, 3/4" (19mm) MMD, 3/4" (19mm) MMD, 3/4" (19mm) MMD, 3/4" (19mm) MMD,
magnetically shielded magnetically shielded magnetically shielded magnetically shielded magnetically shielded
Dimensions (H x W x D) 9-7/8" x 5-15/16" x 6-13/16" 13" x 7-3/8" x 10-1/2" 14-3/4" x 8-1/4" x 11" 35-3/4" x 7-3/8" x 11-3/4" 39-1/4" x 8-1/4" x 13"
(with grille) (251mm x 150mm x 173mm) (330mm x 187mm x 267mm) (375mm x 208mm x 280mm) (908mm x 187mm x 300mm) (997mm x 208mm x 330mm)
Weight 7 lb (3.2kg) 13.5 lb (6kg) 16.1 lb (7.3kg) 35.3 lb (16kg) 48.5 lb (22kg)
PS S P
ERIES OWERED
A I S M
DD AN NFINITY UB TO AXIMIZE
Primus Theater Pack II
Satellites Center Channel
Frequency Range (±3dB) 100Hz – 20,000Hz 100Hz – 20,000Hz
Recommended Amp Power Range 10 – 100 Watts 10 – 100 Watts
PS28
Sensitivity (2.83V @ 1 meter) 86dB 87dB
Frequency Range 35Hz – 150Hz
Nominal Impedance 8 Ohms 8 Ohms
Maximum Amp 150 Watts RMS
Output 300 Watts Peak
Crossover Frequency 3,000Hz; 24dB/octave 3,000Hz; 24dB/octave
Low-Frequency Driver(s) 4" (100mm) MMD, ® Dual 4" (100mm) MMD, ® Crossover Frequency 50Hz – 150Hz, 24dB/octave,
magnetically shielded magnetically shielded continuously variable
High-Frequency Driver 3/4" (19mm) MMD, 3/4" (19mm) MMD, Driver 8" (200mm) MMD ®
magnetically shielded magnetically shielded
Dimensions (H x W x D) 17-3/4" x 10-5/8" x 16-3/4"
Dimensions (H x W x D) 9-7/8" x 5-15/16" x 6-13/16" 5-5/16" x 14-3/4" x 6-13/16" (with grille) (451mm x 270mm x 426mm)
(with grille) (251mm x 150mm x 173mm) (150mm x 375mm x 173mm)
Weight 33 lb (15kg)
Weight 7 lb (3.2kg) 10 lb (4.5kg)
250 Crossways Park Drive, Woodbury, NY 11797 USA • 516.674.4INF (4463) • Fax 516.682.3583 • www.infinitysystems.com
© 2007 Harman International Industries, Incorporated. All rights reserved. Printed 1/08 Part No. PRIMUSLITREV11/07
Infinity, Infinity Primus and MMD are trademarks of Harman International Industries, Incorporated, registered in the United States and/or other countries.
Infinity, Cascade and Metal Matrix Diaphragm are trademarks of Harman International Industries, Incorporated.
Kevlar is a registered trademark of E.I. du Pont de Nemours and Company.
Designed, edited and digitally produced by the Harman Consumer Group Marketing & Design Center, Woodbury NY.
Features, specifications and appearance are subject to change without notice.
PC250 PC350
80Hz – 20,000Hz 80Hz – 20,000Hz
10 – 150 Watts 10 – 150 Watts
90dB 91dB
8 Ohms 8 Ohms
3,000Hz; 24dB/octave 650Hz, 2,800Hz; 24dB/octave
® Dual 5-1/4" (130mm) MMD, ® Dual 5-1/4" (130mm) MMD, ®
magnetically shielded magnetically shielded
N/A Dual 3" (75mm) MMD,
magnetically shielded
3/4" (19mm) MMD, 3/4" (19mm) MMD,
magnetically shielded magnetically shielded
7-5/8" x 18" x 9-5/8" 7-3/8" x 23-3/8" x 9-1/4"
(194mm x 457mm x 245mm) (187mm x 594mm x 235mm)
17.6 lb (8kg) 25 lb (11.4kg)
S
UBWOOFERS .
B I R .
ASS MPACT AND EALISM
PS210 PS212
27Hz – 150Hz 25Hz – 150Hz
300 Watts RMS 400 Watts RMS
500 Watts Peak 700 Watts Peak
50Hz – 150Hz, 24dB/octave, 50Hz – 150Hz, 24dB/octave,
continuously variable continuously variable
10" (250mm) MMD ® 12" (300mm) MMD ®
15-5/8" x 12-1/2" x 16-1/2" 17-5/8" x 14-3/8" x 18-3/4"
(397mm x 318mm x 419mm) (448mm x 365mm x 476mm)
39 lb (17.7kg) 45 lb (20.5kg)
Infinity begins here
