Infinity PRELUDE Owner's Manual page 10

FRONT VIEW
SPEAKER
TOWER
10-32 SOCKET
HEAD SCREWS
SCREW
CAPS
SCREW-CAP
ALIGNMENT
SLOTS
SPEAKER
TOWER
S 8
– Fasten the four 10-32 Socket Head Screws
TEP
through the tower base as shown: two through the front baffle
and two in the rear slot. Press flush into place two screw caps to
hide holes in front-baffle base. Make sure that the alignment
slots point toward the center to ensure that the surface curve
matches that of the baffle.
PRELUDE MTS TOWER
10
10-32 SOCKET
HEAD SCREWS
REAR SLOT
IN BOTTOM
OF SPEAKER
TOWER
FLOOR
STAND
REAR VIEW
10-32 SOCKET
HEAD SCREWS
REAR SLOT
IN BOTTOM
OF SPEAKER
TOWER
FLOOR
STAND
