Confirming Network Extender Operation
LED
Function
Description
PWR
Power
Solid blue: normal
No light or solid magenta: failure
System
System connected
Solid blue: normal
Persistent solid magenta: failure
Persistent solid red or slow or fast blinking red: abnormal
GPS
GPS Signal
Solid blue: normal
Persistent solid magenta: failure
Persistent solid red: external GPS antenna is required*
Blinking blue or red: searching for signals
WAN
WAN (Ethernet
Solid blue: normal
Blinking blue: data communication
connection)
No light or solid red: abnormal
Solid blue: normal (GPS signal is received)
GPS
GPS Signal
Blinking blue or red: while searching for GPS signal
Solid red: abnormal (GPS signal cannot be received, the external GPS antenna is
required)*
SYS
System connected
Solid blue: normal
Solid red: abnormal
Notes
If the WAN LED is solid blue but the SYS LED is solid red, there may be a problem with the Internet connection
* For more information, see "External GPS Antenna" in the User Manual.
NOTE: Allow 3 – 5 minutes for the Network Extender to complete the startup sequence and detect both its connections and available communications.
When the Network Extender is powered up, it may take as long as one hour for GPS acquisition.
Your Network Extender is ready for use when all four LEDs are blue.
Combo_QSG_6x4in_V0_R1.indd 1
Troubleshooting
What if my GPS LED is still red after one hour?
If the GPS LED is still red after one hour, you need to relocate the GPS antenna to receive a stronger signal. See
"External GPS Antenna" in the User Guide.
How do I know my phone is connecting through the Network Extender?
When dialing # 48 on your wireless phone, an announcement will tell you if you are within range of the Network
Extender. In addition, you will hear a short double tone on your wireless phone whenever making or receiving a call.
The tone is played at the beginning of the call.
Optional Accessories
• A wall and ceiling bracket mount is
available to allow for the unit to be
conveniently mounted on the wall or
ceiling.
• Power over Ethernet adaptor
For More Information
• Refer to the Network Extender User Manual at www.verizonwireless.com/networkextender/business
*
• Call Customer Care toll free at 800-922-0204 or
611 from your Verizon Wireless mobile phone.
© 2012 Verizon Wireless. All rights reserved. Verizon Wireless is a trademark of Verizon Trademark Services LLC.
Verizon Wireless
Network Extender
Quick Start Guide
EP68-00488A
A3LSCS-2U01
8/2/2012 9:38:39 AM
