  • Page 1 MA Series Service Manual Grade 1 Mortise Lever and Knob Locks...
  • Page 2: Table Of Contents

    MA-Series Service Manual Table.of.Contents Introduction............ii Functions............2 MA101.-.Passage.or.Closet.Latch....5 MA161.-.Exit.or.Communicating.Lock..6 MA301.-.Privacy,.Bedroom/Bath....7 MA311.-.Privacy,.Bedroom/Bath....8 MA321.-.Privacy,.Bedroom/Bath....9 MA371.-.Store.Door.Lock......10 MA381.-.Apartment,.Exit......11 MA411.-.Asylum.or.Institutional.Lock..12 MA431.-.Classroom.Security.Lock.with. Deadbolt............. 13 MA441.-.Classroom.Security.Lock..14 MA451.-.Hotel.Guest.Lock......15 MA521.-.Entry/Office.Lock.
  • Page 3: Introduction

    Introduction Introduction This manual contains a complete listing of parts and assemblies for MA-Series mortise locks manufactured by Falcon Lock Company. This edition lists components of MA-Series locks manufactured after April, 2010. All lock case covers are labeled with dates to identify year of manufacture. Example: 12507 = the 125 day of 2007.
  • Page 4 MA-Series Service Manual Introduction 4-7/8" 4-1/8" (124mm) (105mm) 1-1/4" Lock Faceplate Strike (32mm) Lock Dimension Faceplate Dimension Strike 6” (152mm) 8” (203mm) (A) Door Thickness Lip Size 3-39/64” (92mm) 6-3/8” (162mm) 1-3/4” – 1-7/8” 1-1/4” (32mm) 2-27/64” (62mm) 9/16” (14mm) 2”...
  • Page 5: Functions

    MA-Series Service Manual Functions To order Falcon MA Series locksets, please consult page 43 for ordering information and assistance. Catalog Number Prefixes: Add the following prefix for the appropriate trim style. Note: If a special function is required and not listed here, please contact the factory for assistance.
  • Page 6 MA-Series Service Manual Functions Function ANSI.A156.13,.2005 Page FALCON ANSI DESCRIPTION FUNCTION Latch bolt operated by key from outside or by operating inside knob/lever. Outside knob/lever is always inoperative. Dead bolt projected by MA451 Hotel/Guest Lock turn from inside and all keys except emergency key are shut out.
  • Page 7 MA-Series Service Manual Functions Function ANSI.A156.13,.2005 Page FALCON ANSI DESCRIPTION FUNCTION Latch bolt is operated by knob/lever from either Front Door/ side except when outside knob/lever is made F08/ MA621 Apartment inoperative by buttons in face. Dead bolt is Corridor operated by turn inside.
  • Page 8: Ma101.-.Passage.or.closet.latch

    MA-Series Service Manual Lock Case Assemblies MA101.-.Passage.or.Closet.Latch Trim Lever Knob Description Dane Sutro Avalon Quantum Hana KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140 AS76100 INSIDE TRIM KNOB/LEVER ESCUTCHEON AE77280 AE77526 AE77029 AE77140 AE77100 ESCUTCHEON E77012-IP KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140 AS76100 OUTSIDE TRIM KNOB/LEVER ESCUTCHEON...
  • Page 9: Ma161.-.Exit.or.communicating.lock

    MA-Series Service Manual Lock Case Assemblies MA161.-.Exit.or.Communicating.Lock Trim Lever Knob Description Dane Sutro Avalon Quantum Hana AS76280 AS76526 AS76029 AS76140 AS76100 KNOB/LEVER SECTIONAL INSIDE TRIM KNOB/LEVER ESCUTCHEON AE77280 AE77526 AE77029 AE77140 AE77100 ESCUTCHEON E77012-IP KNOB/LEVER SECTIONAL KNOB/LEVER ESCUTCHEON OUTSIDE TRIM ESCUTCHEON ROSE S76012...
  • Page 10: Ma301.-.Privacy,.Bedroom/Bath

    MA-Series Service Manual Lock Case Assemblies MA301.-.Privacy,.Bedroom/Bath Trim Lever Knob Description Dane Sutro Avalon Quantum Hana KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140 AS76100 INSIDE TRIM AE77280 AE77526 AE77029 AE77140 AE77100 KNOB/LEVER ESCUTCHEON ESCUTCHEON AE77012-IT KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140 AS76100 OUTSIDE TRIM KNOB/LEVER ESCUTCHEON...
  • Page 11: Ma311.-.Privacy,.Bedroom/Bath

    MA-Series Service Manual Lock Case Assemblies MA311.-.Privacy,.Bedroom/Bath Trim Lever Knob Description Dane Sutro Avalon Quantum Hana KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140 AS76100 INSIDE TRIM AE77280 AE77526 AE77029 AE77140 AE77100 KNOB/LEVER ESCUTCHEON ESCUTCHEON AE77012-IT KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140 AS76100 KNOB/LEVER ESCUTCHEON AE77280...
  • Page 12: Ma321.-.Privacy,.Bedroom/Bath

    MA-Series Service Manual Lock Case Assemblies MA321.-.Privacy,.Bedroom/Bath Trim Lever Knob Description Dane Sutro Avalon Quantum Hana KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140 AS76100 INSIDE TRIM AE77280 AE77526 AE77029 AE77140 AE77100 KNOB/LEVER ESCUTCHEON ESCUTCHEON AE77012-IT KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140 AS76100 KNOB/LEVER ESCUTCHEON AE77280...
  • Page 13: Ma371.-.Store.door.lock

    MA-Series Service Manual Lock Case Assemblies MA371.-.Store.Door.Lock SFIC Not Shown Trim Lever Knob Description Dane Sutro Avalon Quantum Hana KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140 AS76100 INSIDE TRIM AE77280 AE77526 AE77029 AE77140 AE77100 KNOB/LEVER ESCUTCHEON ESCUTCHEON E77012-IC KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140...
  • Page 14: Ma381.-.Apartment,.Exit

    MA-Series Service Manual Lock Case Assemblies MA381.-.Apartment,.Exit SFIC Not Shown Trim Lever Knob Description Dane Sutro Avalon Quantum Hana KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140 AS76100 INSIDE TRIM AE77280 AE77526 AE77029 AE77140 AE77100 KNOB/LEVER ESCUTCHEON ESCUTCHEON E77012-IC KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140...
  • Page 15: Ma411.-.Asylum.or.institutional.lock

    MA-Series Service Manual Lock Case Assemblies MA411.-.Asylum.or.Institutional.Lock SFIC Not Shown Trim Lever Knob Description Dane Sutro Avalon Quantum Hana KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140 AS76100 INSIDE TRIM AE77280 AE77526 AE77029 AE77140 AE77100 KNOB/LEVER ESCUTCHEON ESCUTCHEON E77012-IC KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140...
  • Page 16: Ma431.-.Classroom.security.lock.with.deadbolt

    MA-Series Service Manual Lock Case Assemblies MA431.-.Classroom.Security.Lock.with.Deadbolt SFIC Not Shown Trim Lever Knob Description Dane Sutro Avalon Quantum Hana KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140 AS76100 INSIDE TRIM AE77280 AE77526 AE77029 AE77140 AE77100 KNOB/LEVER ESCUTCHEON ESCUTCHEON E77012-IC KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140...
  • Page 17: Ma441.-.Classroom.security.lock

    MA-Series Service Manual Lock Case Assemblies MA441.-.Classroom.Security.Lock SFIC Not Shown Trim Lever Knob Description Dane Sutro Avalon Quantum Hana KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140 AS76100 INSIDE TRIM KNOB/LEVER ESCUTCHEON AE77280 AE77526 AE77029 AE77140 AE77100 ESCUTCHEON E77012-IC KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140...
  • Page 18: Ma451.-.Hotel.guest.lock

    MA-Series Service Manual Lock Case Assemblies MA451.-.Hotel.Guest.Lock SFIC Not Shown Trim Lever Knob Description Dane Sutro Avalon Quantum Hana KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140 AS76100 INSIDE TRIM AE77280 AE77526 AE77029 AE77140 AE77100 KNOB/LEVER ESCUTCHEON ESCUTCHEON AE77012-IT KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140...
  • Page 19: Ma521.-.Entry/Office.lock

    MA-Series Service Manual Lock Case Assemblies MA521.-.Entry/Office.Lock SFIC Not Shown Trim Lever Knob Description Dane Sutro Avalon Quantum Hana AS76280 AS76526 AS76029 AS76140 AS76100 KNOB/LEVER SECTIONAL INSIDE TRIM KNOB/LEVER ESCUTCHEON AE77280 AE77526 AE77029 AE77140 AE77100 ESCUTCHEON E77012-IP KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140...
  • Page 20: Ma531.-.Apartment.corridor.door.lock

    MA-Series Service Manual Lock Case Assemblies MA531.-.Apartment.Corridor.Door.Lock SFIC Not Shown Trim Lever Knob Description Dane Sutro Avalon Quantum Hana KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140 AS76100 INSIDE TRIM AE77280 AE77526 AE77029 AE77140 AE77100 KNOB/LEVER ESCUTCHEON ESCUTCHEON AE77012-IT KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140...
  • Page 21: Ma541.-.Apartment.corridor.door.lock

    MA-Series Service Manual Lock Case Assemblies MA541.-.Apartment.Corridor.Door.Lock SFIC Not Shown Trim Lever Knob Description Dane Sutro Avalon Quantum Hana KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140 AS76100 INSIDE TRIM KNOB/LEVER ESCUTCHEON AE77280 AE77526 AE77029 AE77140 AE77100 ESCUTCHEON AE77012-IT KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140...
  • Page 22: Ma551.-.Holdback.lock

    MA-Series Service Manual Lock Case Assemblies MA551.-.Holdback.Lock SFIC Not Shown Trim Lever Knob Description Dane Sutro Avalon Quantum Hana KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140 AS76100 INSIDE TRIM AE77280 AE77526 AE77029 AE77140 AE77100 KNOB/LEVER ESCUTCHEON ESCUTCHEON E77012-IP KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140...
  • Page 23: Ma561.-.Classroom.lock

    MA-Series Service Manual Lock Case Assemblies MA561.-.Classroom.Lock SFIC Not Shown Trim Lever Knob Description Dane Sutro Avalon Quantum Hana KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140 AS76100 INSIDE TRIM AE77280 AE77526 AE77029 AE77140 AE77100 KNOB/LEVER ESCUTCHEON ESCUTCHEON E77012-IP KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140...
  • Page 24: Ma571.-.Dormitory.or.exit.lock

    MA-Series Service Manual Lock Case Assemblies MA571.-.Dormitory.or.Exit.Lock SFIC Not Shown Trim Lever Knob Description Dane Sutro Avalon Quantum Hana KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140 AS76100 INSIDE TRIM AE77280 AE77526 AE77029 AE77140 AE77100 KNOB/LEVER ESCUTCHEON ESCUTCHEON AE77012-IT KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140...
  • Page 25: Ma581.-.Storeroom./.Closet.lock

    MA-Series Service Manual Lock Case Assemblies MA581.-.Storeroom./.Closet.Lock SFIC Not Shown Trim Lever Knob Description Dane Sutro Avalon Quantum Hana KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140 AS76100 INSIDE TRIM AE77280 AE77526 AE77029 AE77140 AE77100 KNOB/LEVER ESCUTCHEON ESCUTCHEON E77012-IP KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140...
  • Page 26: Ma621.-.Front.door./.Apartment.corridor. 2

    MA-Series Service Manual Lock Case Assemblies MA621.-.Front.Door./.Apartment.Corridor SFIC Not Shown Trim Lever Knob Description Dane Sutro Avalon Quantum Hana KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140 AS76100 INSIDE TRIM AE77280 AE77526 AE77029 AE77140 AE77100 KNOB/LEVER ESCUTCHEON ESCUTCHEON AE77012-IT KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140...
  • Page 27: Ma641.-.Dormitory.lock

    MA-Series Service Manual Lock Case Assemblies MA641.-.Dormitory.Lock SFIC Not Shown Trim Lever Knob Description Dane Sutro Avalon Quantum Hana KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140 AS76100 INSIDE TRIM AE77280 AE77526 AE77029 AE77140 AE77100 KNOB/LEVER ESCUTCHEON ESCUTCHEON AE77012-IT KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140...
  • Page 28: Ma851.-.Electrified.el.-.12.&.24.(Fail.safe)

    MA-Series Service Manual Lock Case Assemblies MA851.-.Electrified.EL.-.12.&.24.(Fail.Safe) SFIC Not Shown Trim Lever Knob Description Dane Sutro Avalon Quantum Hana AS76280 AS76526 AS76029 AS76140 AS76100 KNOB/LEVER SECTIONAL INSIDE TRIM KNOB/LEVER ESCUTCHEON AE77280 AE77526 AE77029 AE77140 AE77100 ESCUTCHEON E77012-IP KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140...
  • Page 29: Ma881.-.Electrified.eu.-.12.&.24.(Fail.secure)

    MA-Series Service Manual Lock Case Assemblies MA881.-.Electrified.EU.-.12.&.24.(Fail.Secure) SFIC Not Shown Trim Lever Knob Description Dane Sutro Avalon Quantum Hana KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140 AS76100 INSIDE TRIM KNOB/LEVER ESCUTCHEON AE77280 AE77526 AE77029 AE77140 AE77100 ESCUTCHEON E77012-IP KNOB/LEVER SECTIONAL AS76280 AS76526 AS76029 AS76140...
  • Page 30: Ma911.-.Classroom.dead.lock

    MA-Series Service Manual Lock Case Assemblies MA911.-.Classroom.Dead.Lock SFIC Not Shown Trim Lever Knob Description Dane Sutro Avalon Quantum Hana KNOB/LEVER SECTIONAL INSIDE TRIM KNOB/LEVER ESCUTCHEON ESCUTCHEON AE77012-IE KNOB/LEVER SECTIONAL OUTSIDE TRIM KNOB/LEVER ESCUTCHEON AE77012-OK ESCUTCHEON ASSY, LOCK UNIT A7829 FACEPLATE S77816 STRIKE ASSY A8737-X...
  • Page 31: Ma921.-.Dead.lock

    MA-Series Service Manual Lock Case Assemblies MA921.-.Dead.Lock Trim Lever Knob Description Dane Sutro Avalon Quantum Hana KNOB/LEVER SECTIONAL INSIDE TRIM KNOB/LEVER ESCUTCHEON ESCUTCHEON E77012-IB KNOB/LEVER SECTIONAL KNOB/LEVER ESCUTCHEON OUTSIDE TRIM ESCUTCHEON AE77012-OK ASSY, LOCK UNIT A7816 FACEPLATE S77816 STRIKE ASSY A8737-X PE1396 STRIKE BOX...
  • Page 32: Ma931.-.Dead.lock

    MA-Series Service Manual Lock Case Assemblies MA931.-.Dead.Lock SFIC Not Shown Trim Lever Knob Description Dane Sutro Avalon Quantum Hana KNOB/LEVER SECTIONAL INSIDE TRIM KNOB/LEVER ESCUTCHEON ESCUTCHEON E77012-IK KNOB/LEVER SECTIONAL KNOB/LEVER ESCUTCHEON OUTSIDE TRIM ESCUTCHEON AE77012-OK ASSY, LOCK UNIT A7816 FACEPLATE S77816 STRIKE ASSY A8737-X...
  • Page 33: Ma941.-.Dead.lock

    MA-Series Service Manual Lock Case Assemblies MA941.-.Dead.Lock SFIC Not Shown Trim Lever Knob Description Dane Sutro Avalon Quantum Hana KNOB/LEVER SECTIONAL INSIDE TRIM KNOB/LEVER ESCUTCHEON ESCUTCHEON E77012-IK KNOB/LEVER SECTIONAL KNOB/LEVER ESCUTCHEON OUTSIDE TRIM ESCUTCHEON AE77012-OK ASSY, LOCK UNIT A7816 FACEPLATE S77816 STRIKE ASSY A8737-X...
  • Page 34: Ma12.-.Single.dummy

    MA-Series Service Manual Lock Case Assemblies MA12.-.Single.Dummy Trim Knob/Lever.on.One.Side.Fixed Lever Knob Description Dane Sutro Avalon Quantum Hana AS76280-D AS76526-D AS76029-D AS76140-D AS76100-D KNOB/LEVER SECTIONAL TRIM KNOB/LEVER ESCUTCHEON AE77280-D AE77526-D AE77029-D AE77140-D AE77100-D ESCUTCHEON E77012-IP ROSE S76012 Q513-068 DOOR MARKER SCREW PACK E77331 TORX SCREW PACK (OPTIONAL) E77308...
  • Page 35: Ma18.-.Double.dummy

    MA-Series Service Manual Lock Case Assemblies MA18.-.Double.Dummy Trim Knob/Lever.on.Both.Sides.Fixed Lever Knob Description Dane Sutro Avalon Quantum Hana KNOB/LEVER SECTIONAL AS76280-D AS76526-D AS76029-D AS76140-D AS76100-D INSIDE TRIM AE77280-D AE77526-D AE77029-D AE77140-D AE77100-D KNOB/LEVER ESCUTCHEON ESCUTCHEON E77012-IP KNOB/LEVER SECTIONAL AS76280-D AS76526-D AS76029-D AS76140-D AS76100-D OUTSIDE TRIM...
  • Page 36: Knob.and.lever.designs

    Knob and Lever Designs MA-Series Service Manual Levers Gala AG (Avalon-Gala) DG (Dane-Gala) QG (Quantum-Gala) SG (Sutro-Gala) Napa AN (Avalon-Napa) DN (Dane-Napa) QN (Quantum-Napa) SN (Sutro-Napa) Knobs HG (Hana-Gala) HN (Hana-Napa)
  • Page 37: Ma-Series.screw.packs

    Screw Packs MA-Series Service Manual MA-Series.Screw.Packs Part. Specify. Description Number Finish #8-32 x Z⁄v” L Machine Screw #12-12/ #12-24 x 1Z⁄x” L Wood/machine Combination Screw #12-12/ #12-24 x 1Z⁄v” L Wood/machine Combination Screw 1³⁄,”-1M⁄,” door thickness, sectional trim with S76300 #8-32 x 1Z⁄v”...
  • Page 38 MA-Series Service Manual Screw Packs Part. Specify. Description Number Finish #8-32 x Z⁄v” L Machine Screw #12-12/ #12-24 x 1Z⁄x” L Wood/machine Combination Screw #12-12/ #12-24 x 1Z⁄v” L Wood/machine Combination Screw S76331 #8-32 x 1Z⁄v” L Mounting Screw Single Dummy Screw Pack •...
  • Page 39: Strikes

    Screw Packs/Strikes MA-Series Service Manual Part. Specify. Description Number Finish #8-32 x Z⁄v” L Torx Head Machine Screw #12-12/#12-24 x 1Z⁄x” L Torx Head Wood/machine Combination Torx screw pack, escutcheon trim, E77306 • Screw standard door thickness* #10-24 x 1Z⁄v” L Torx Head, Machine Screw #8-32 x Z⁄v”...
  • Page 40: Cams

    The Falcon MA Series requires a different CAM for keyed functions than its predecessor, the Falcon M Series. For all keyed functions except the MA381 function, the MA Series uses a single CAM for all standard mortise cylinders and a single CAM for all interchangeable core mortise cylinders.
  • Page 41 Cams MA-Series Service Manual Falcon MA381 Cylinder CAM Falcon MA381 Cylinder CAM Configuration Chart (Interchangeable Configuration Chart Core) Door Hand Inside Cyl. Cam Outside Cyl. Cam Door Hand Inside Cyl. Cam Outside Cyl. Cam RH/RHR 5620-STD (R3) 5621-STD (R4) RH/RHR...
  • Page 42: Mortise,.Rim.and.cam.lock.for.standard.cylinders

    MA-Series Service Manual Mortise Cylinders Mortise,.Rim.and.Cam.Lock.for.Standard.Cylinders Mortise.Cylinder Keyed.Mortise.Cylinders 900 Series Cylinders are Catalog furnished with #4 straight Length Pins Application Number cam and 250 Series with #1 cloverleaf cam unless 1-1/8” 5 or 6 Generic otherwise specified. 1-1/4” 5 or 6 Generic See table for product numbers.
  • Page 43: Cylinder.collars

    MA-Series Service Manual Mortise Cylinders Cylinder.Collars Standard.Collars.for.Cylinders.Ordered.Separately Length Cylinder Non-AR.Cams AR.Cam 1” 984D A08794-000 1-1/8” 250, 965, 966, 973, 974, 985 Series A08794-000 008876-002 1-1/4” 251, 986 Series A08794-001 008876-003 1-3/8” 252, 253, 987, C987, C997 A08794-002 008876-004 Longer C260 Series, (C)988, (C)990, (C)992 A08794-000 008876-000 Escutcheon.Trim.Rings...
  • Page 44: Trim.rings.&.Collars

    MA-Series Service Manual Mortise Cylinders Trim.Rings.&.Collars Dim. A Dim. B Part No. 3/32” 9/32” A08790-000 7/32” 13/32” A08790-001 11/32” 17/32” A08790-002 15/32” 21/32” A08790-003 43/64” 55/64” A08790-004 3/32” 9/32” A08794-000 7/32” 13/32” A08794-001 11/32” 17/32” A08794-002 Wave washer included. 15/32” 21/32”...
  • Page 45: Electrically.locking

    MA-Series Service Manual Mortise Cylinders Electrically.Locking MA851 Electrically Locked (Fail Safe): Outside trim is continuously locked electrically. The latchbolt is retracted by a key outside or by the knob/lever inside. Switch or power failure allows the outside knob/lever to retract the latchbolt. The auxiliary latch deadlocks the latchbolt when the door is closed.
  • Page 46: Ordering.procedures

    To order product with an interchangeable core, add “SFIC” (with interchangeable core). Ex: “G” with Falcon SFIC core. Example: DG-D for Dane lever followed by G for Gala rose. Keyway: “G” is standard on regular cylinders, “A” is standard on Finish: When the finish is the same for the outside and inside...
  • Page 47: Instructions

    Q513-067 Installation Instructions Instrucciones de instalación Notice d'installation Falcon MA-Lock *For MA12, MA18, and MA161 Function Installation, See Last Page *Para obtener información sobre la instalación de las funciones MA12, MA18 y MA161, vea la última página *Pour l'installation des options MA12, MA18 et MA161, consultez la dernière page...
  • Page 48 Instructions MA-Series Service Manual Install Lever Posts and Screws Identify Trim and Install Instale los postes de la palanca y los tornillos Identifique el ribete e instálelo Installer les tiges de levier et les vis Identifiez la garniture et installez Escutcheon with Thumbturn Escudo con tuerca mariposa Écusson et barrette tournante...
  • Page 49 Instructions MA-Series Service Manual Identify Trim and Secure to Door If Included, Install Cylinder Identifique el ribete y asegúrelo en la puerta Si el cilindro está incluido, instálelo Identifiez la garniture et fixez à la porte Installez le cylindre, si inclus Escutcheon with Thumbturn Escudo con tuerca mariposa Écusson et barrette tournante...
  • Page 50 Instructions MA-Series Service Manual Mortise Rehanding (If Required) d. Move Handing Screws to Opposite Side Remanipulación de la cerradura de muescas (si se requiere) d. Mueva los tornillos de manejo al lado opuesto Déplacement de la mortaise (si nécessaire) d. Déplacer les vis de réglage du côté opposé a.
  • Page 51 MA-Series Service Manual Instructions Special Function Installation MA551 Holdback Instalación de funciones especiales MA551 la función de retención Installation des fonctions spéciales MA551 la fonction de retenue MA12 - Single Dummy Installation To Activate Holdback Function MA12 - Instalación de vástago simple Para activar la función de retención MA12 - Installation d'une fausse poignée Pour activer la fonction de retenue...
  • Page 52 MA-Series Service Manual Instructions Electrically Locking Cerradura eléctrica Verrouillage électrique MA851 Electrically Locked (Fail Safe): Outside trim is continuously locked electrically. The latchbolt is retracted by a key outside or by the knob/lever inside. Switch or power failure allows the outside knob/lever to retract the latchbolt. The auxiliary latch deadlocks the latchbolt when the door is closed.
  • Page 53 MA-Series Service Manual Instructions Flat (No Bevel) Low Edge Low Edge Plano Right-Handed Door Borde inferior Plat Borde inferior Q513-068 Bord inférieur High Edge Bord inférieur Puerta con bisagras a la derecha Borde superior Porte ouvrant à droite MA-Series Template Bord inférieur 2³⁄₄"...
  • Page 54 The sector’s market-leading products include electronic and biometric access-control systems; time-and-attendance and personnel scheduling systems; mechanical locks; portable security; door closers, exit devices, architectural hardware, and steel doors and frames; and other technologies and services for global security markets. 800.847.1864 www.falcon.ingersollrand.com ©2010 Ingersoll Rand Company FA-5885 Rev. 9/2010...
