SoundTube HP690i Specifications

HP690i
Specifications: HP690i
System Type
Frequency Response (- 3 dB) 1
Low Frequency (-10 dB)
1
Max. Program Power
Max. Continuous Power RMS
2
Max. SPL dB @ 1 M
Sensitivity dB @ 1W/1M
3
Impedance (nominal)
Coverage Angle (-6 dB @ 2 kHz)
Coverage Angle (-6 dB @ 8 kHz)
Directivity Factor (Q)
Directivity Index (DI)
Tap Selector
Transformer Taps
70.7 V Output 100 V
66 W 111 dB 66 W
35 W 108.5 dB 35 W
19 W 106 dB 19 W
10 W 103 dB 10 W
5 W 100 dB
Transducers
Low Frequency Driver
High Frequency Driver
Low Frequency Voice Coil
Crossover Frequency
Network Type
Low Pass
High Pass
Enclosure Material
Motor Board
Grille
Inputs
Colors
Height
Diameter
Weight
Shipping Weight
Accessories
Included
Optional
Packaging
1 Frequency response is measured in full space.
2
Continuous power rating, EIA-426-B test.
3 2.83 Volts at a distance of 1 meter.
SoundTube continually develops new product innovations and improvements. Updates to existing
products without prior notice are an example of SoundTube's drive for constant improvement.
© 2006 SoundTube Entertainment. All rights reserved. PN TS-HP590 REV 04.04.06
Open Ceiling Speaker
Preliminary Technical Information for System Engineers
6.5" Coax, compression tweeter w/ 1" exit, open-ceiling, ported (66
Watt transformer for 25/70.7/100 Volt or voice coil / 8 Ohm direct)
78 Hz - 22 kHz
62 Hz - 22 kHz
200 Watts
100 Watts
112.5 dB
92.5 dB
8 Ohm
120º
150º
4.28 (Averaged 100 Hz - 10 kHz); 5.25 @ 2 kHz
5.44 dB (Averaged 100 Hz - 10 kHz); 7.2 dB @ 2 kHz
6-Position rotary switch with voice coil direct (8 Ohm)
Output 25 V Output
111 dB 5 W 100 dB
108.5 dB 2.5 W 97 dB
106 dB 1.25 W 94 dB
103 dB 0.75 W 92 dB
1 x 165 mm (6.5 in) Treated fiber cone, cloth surround
1 Compression driver with waveguide and 25.4 mm (1 in) exit
34 mm (1.36 in)
3 kHz
18 dB per octave, 3rd order
18 dB per octave, 3rd order
Injection molded ABS, glass fiber reinforced
Cast aluminum
Iridite-plated steel with powder-coat finish
4 Pin, 5 mm Euroblock for individual or daisy chain connection
Black or white
363.6 mm / 14.31 in
307.3 mm / 12.10 in
7.3 kg / 16.2 lbs
N/A
Hanging hardware, Euroblock connector & terminal
weather boot
Surface-Mount Bracket (AC-RS-SM6)
1 per box
Mounting hardware included
Preliminary Technical Information
The information in this document reflects
preliminary data. Items including polar
plots, frequency, phase and impedance
response graphs will be added when final
data are available.

Key Features

• BroadBeamHP waveguide technology
®
delivers a consistent dispersion pattern
for maximum coverage area per speaker
(up to 10 kHz, EASE documented).
™
• One 165 mm (6.5 in) treated fiber driver and
one compression driver with a 25.4 mm
(1 in) exit mounted to a proprietary cast-
aluminum M6 baffle and heat sink.
™
• 66 Watt transformer and high output
(112.5 dB) for the sound reinforcement
and PA markets.
• Easy-access 6-position selectable tap
switch for 25, 70.7, and 100 Volt applica-
tions with voice coil/8 Ohm direct sim-
plifies ordering and inventory tracking.
• Weatherized components for indoor/
outdoor applications
• 92.5 dB average sensitivity offers high-
output capabilities and reduced amplifi-
cation costs.
• Includes hanging hardware with aircraft
cables and integrated SpeedClamp™ self-
locking wire grip for fast, easy & secure
installation. Also includes Euroblock con-
nector & terminal weather boot.
• Optional accessory: surface-mount
bracket (AC-RS-SM6).
• High quality black or white paint finish.
Description
The HP690i is a premium 6.5" 2-
way, ported high-efficiency, high-SPL
loudspeaker for distributed or 8 Ohm
applications. The HP690i incorporates a
dedicated 6.5" treated fiber driver and
high-power compression transducer with
a BroadBeamHP waveguide to deliver a
®
consistent dispersion pattern and superb
intelligibility for the foreground music,
sound reinforcement and PA markets.
The HP690i incorporates a 66 Watt trans-
former with a 6-position tap switch and
voice coil/8 Ohm direct position. Hang-
ing hardware is included and features
a fast-action SpeedClamp
™
secure installation.
Applications
Engineered for installations requiring full-
range background/foreground music plus
for easy and
