RS-EZ series
Cover Plate
Screws (4)
Hanging Bracket
Terminal
Block
Speaker
Warning
SoundTube speakers must be installed by a professional audio installer/contractor. For safety and for
optimum audio performance, installer must follow all directions issued by SoundTube Entertainment.
Install Instructions For:
RS42-EZ, RS62-EZ, RS82-EZ, HP82-EZ
Weather plug
Cover Plate
Hanging Hardware
Tap Switch
1.435.647.9555
© 2012 SoundTube Entertainment, Inc. All rights reserved. PN INS-RS-EZ Rev 03.01.12
Warning
Do not spec or install speaker near support beam, ventilation duct or
other structure that may interfere with speaker function or dispersion.
Box contents
1 Speaker
1 Cover Plate w/ 4 screws
1 Rubber weather plug
1 Hanging kit
|
|
800.647.TUBE
www.soundtube.com
Advertisement
Related Manuals for SoundTube RS-EZ Series
Summary of Contents for SoundTube RS-EZ Series
- Page 1 Warning Warning SoundTube speakers must be installed by a professional audio installer/contractor. For safety and for Do not spec or install speaker near support beam, ventilation duct or optimum audio performance, installer must follow all directions issued by SoundTube Entertainment.
- Page 2 RS-EZ series Install Instructions For: 1.435.647.9555 800.647.TUBE www.soundtube.com RS42-EZ, RS62-EZ, RS82-EZ, HP82-EZ Unpack speaker and Thread hanging or safety Attach the hanging cable Thread cable end(s) SpeedClamp™ mounting cable through SpeedClamp™ by securing it and safety through SpeedClamp™ hardware. mechanisms as shown.
- Page 3 RS-EZ series Install Instructions For: 1.435.647.9555 800.647.TUBE www.soundtube.com RS42-EZ, RS62-EZ, RS82-EZ, HP82-EZ Conduit Installation: 4. Run signal wire and at Unpack speaker from box. 2. Securely mount conduit 3. Thread cover plate on to least one safety cable to structure. Conduit must conduit until secure.
