System Specifications

Personal PA
Dimensions:
Weight:
Battery Type:
Battery Life:
Charging Contacts:
Carrier Frequency:
Controls:
Channel Selector:
Indicators:
Output Connector:
Audio Output Power: 15 mW max at 32 Ω
Acoustic Output:
Approvals:
Warranty:
RX22-4 Receiver
®
4.1" L x 2.85" W x 1.2" H (104.1 mm x 72.4
mm x 30.4 mm)
4.5 oz (127 g) with batteries
2x AA, alkaline (BAT 001) or NiMH (BAT 026)
Alkaline: 60 hours, NiMH: 30 hours/charge
For use only with CHG 3512
Channel 1: 2.3 MHz, Channel 2: 2.8 MHz
Channel 3: 3.3 MHz, Channel 4: 3.8 MHz
ON/OFF/VOLUME: Combination thumbwheel
knob
four-position rotary switch
Red LED "ON" indicator, flashes to indicate
Low battery
3.5 mm stereo phone jack, accepts either
stereo or mono plug
125 dB SSPL90 with HED 021; 110 dB
SSPL90 w/ EAR 013
CE, FCC, RoHS, WEEE
5 years on receiver, 90 days on accessories
