Thank you for purchasing the Moxa SMG-6100 smart machine-to-machine (M2M) gateway. This manual introduces the hardware installation, connector interfaces and BIOS setup of the SMG-6100. For software configuration and management, please refer to the user’s manual for your operating system.
Introduction Overview The SMG-6100 is based on the Intel x86 processor and supports VGA, 4 Ethernet ports, 2 RS-232 serial ports, and USB. It comes in a standard 19-inch, 1U high form factor with built-in IPSec, making it an ideal communication platform for industrial machine-to-machine M2M applications.
SMG-6100 Hardware Introduction Dimensions 11.9 16,75 Features • Secure communication platform with tunnel server (IPSec) for 2-way IP communication to distributed SMG-1100s (Wireless Modbus Gateway). • Networking host to back-end host computers and Modbus TCP Master/Slave devices. • Supports unlimited Masters on serial or network side.
Page 7
Input Rating 100-240VAC, 47-63Hz, 1.0A-0.5A Regulatory Approvals FCC, CE (Class A), EMC level 4 Safety LVD, UL cUL, CCC Reliability Alert Tools Built-in buzzer and RTC (real-time clock) with battery lithium backup Warranty Warranty Period 3 years (details: see www.moxa.com/warranty)
The LED indicators allow users to monitor performance and identify trouble spots quickly, and multiple ports are provided for connecting a variety of different devices. The SMG-6100 machine-to-machine gateway comes with a reliable and stable hardware platform that lets you devote the bulk of your time to application development.
Place your SMG-6100 on a clean, flat, well-ventilated desktop. For better ventilation, leave some space between the SMG-6100 and other equipment. Do not place equipment or objects on top of the SMG-6100, as this might damage the computer’s internal components.
Page 10
Hardware Installation Step 3: Installing the SMG-6100 to a rack. Gently slide the SMG-6100 onto the rack, and then use screws provided by the rack supplier to fix the rackmount support to the rail. NOTE That four screws are requi red to attach the SMG-6100 to the rack.
Connecting the Power To power on the SMG-6100 connect the power line to the SMG-6100’s AC power connector (located on the right side of the rear panel) using the power cord shipped with the product, and then turn on the power switch. If the power is properly supplied, the Power LED will light up first, and then the Storage LED will start blinking.
Serial port is receiving data. No operation. Connecting to a Display Your SMG-6100 comes with a D-Sub 15-pin female connector to connect to the VGA monitor. Be sure to remove the power before you connect or disconnect the monitor cable. Pin No.
VSYNC Connecting a PS/2 Keyboard and Mouse Your SMG-6100 comes with a PS/2 mini-DIN connector to connect to a PS/2 keyboard and PS/2 mouse by using a Y-type cable. This 6-pin mini-DIN connector has the pin assignments shown below. PS/2 Pin No.
Connecting USB Devices The SMG-6100 has two USB 2.0 ports on the rear panel. All of the ports are UHCI, Rev 2.0 compliant and support Plug & Play and hot swapping. These ports can be used to connect USB devices, such as a keyboard, mouse, USB flash disk, and USB CD-ROM.
Safety Installation Instructions A. RTC Battery Warning CAUTION: There is a risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. B. Rackmount Warning The following or similar rackmount instructions are included with the installation instructions: (1) Elevated Operating Ambient: If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than the room ambient temperature.
Regulatory Statement Approval This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause unde sired operation.
