ACS-2120 Box PC User Manual Release Date Revision Feb 2013 V1.0 ® 2012 Aplex Technology, Inc. All Rights Reserved. Published in Taiwan Aplex Technology, Inc. 15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail: aplex@aplex.com.tw...
Disclaimer This information in this document is subject to change without notice. In no event shall Aplex Technology Inc. be liable for damages of any kind, whether incidental or consequential, arising from either the use or misuse of information in this document or in any related materials.
Always disconnect power when the system is not in use. ◆ Disconnect power when you change any hardware devices. For instance, when you connect a jumper or install any cards, a surge of power may damage the electronic components or the whole system. ACS-2120 User Manual...
232(W) x 200(H) x 48 (D) 269(W) x 200(H) x 54 (D) (wall mount) Operating Temperature -20 °C ~50 °C Storage Temperature -30 °C ~60 °C 10%~90%@ 40℃, non-condensing Storage Humidity Certificate CE / FCC Class A ACS-2120 User Manual...
ACS-2120 works very well along with any of our Display Monitor series and it absolutely can provide an easy way to perform control and field maintenance.
Gently remove 8 screws as shown in the picture. Step 2 There is a hard disk tray to put hard disk. Gently remove the 4 screws in hard disk tray to replace hard disk. Step 3 There is a CF slot to replace CF. ACS-2120 User Manual...
Jumpers and Connectors Location-TOP Figure 2.3: Jumpers and Connectors Location- Bottom Figure 2.4: ACS-2120 User Manual...
Page 12
1x PC 104+ connector (PCI master 4, jumper for +3.3V & 5V select) 2x mini-PCI-express slot (1x full size, 1x half-size ) Power DC12V input Management 1 x 2-pin power input connector Front I/O by 2x5-pin header Power on/off switch ACS-2120 User Manual...
Page 13
1 x VGA Port 1 x VGA 2x8 Pin Header Operating: 0℃–60℃ Temperature Storage: -20℃–80℃ Humidity 5% - 95%, non-condensing, operating Power 12V /1.6A (Intel D525 processor with 2GB DDR3 DRAM) Consumption EMI/EMS CE/FCC class A ACS-2120 User Manual...
10 of COM6 port. JP1 Pin# Function Close 1-2 COM6 Pin10=+5V (default) Close 2-3 COM6 Pin10=+12V (option) 5. JP2: (2.0mm Pitch 1X2 Pin Header), ATX Power and Power auto on setting jumper. Mode Open ATX Power Mode ACS-2120 User Manual...
Page 15
Pin9-10: BUZZER, They are used to connect an external buzzer. Note: When connecting LEDs and buzzer, pay special attention to the signal pola- rity. Make sure that the connector pins have a one-to-one correspondence with chassis wiring, or it may cause boot up failure. ACS-2120 User Manual...
Page 16
Note: Since COM3 and COM33 use the same address, they cannot work at the same time. 10. GPIO: (2.0mm Pitch 2x5 Pin Header),General-purpose input/output port, it provides a group of self-programming interfaces to customers for flexible use. ACS-2120 User Manual...
Page 17
Line In is used for the connection of external audio source via a Line in cable. MIC is the port for microphone input audio. Signal Name Pin# Pin# Signal Name FRONT-OUT-L LINEIN_R AUD_AGND AUD_AGND FRONT-OUT- LINEIN_L AUD_AGND AUD_AGND FRONT-MIC1 FRONT-MIC ACS-2120 User Manual...
Page 18
JCOM and COM33 BIOS Setup. 14. KB/MS: (2.0mm Pitch 1x6 box Pin Header), PS/2 keyboard and mouse port, the port can be connected to PS/2 keyboard or mouse via a dedicated cable for direct used. Pin# Signal Name KBDATA MSDATA ACS-2120 User Manual...
Page 19
(CRT 2.0mm Pitch 2x8 Pin Header), Video Graphic Array Port, Provide 2x8 Pin cable to VGA Port, they can not work at the same time for VGA and VGA-PH. Signal Name Pin# Pin# Signal Name CRT_RED Ground ACS-2120 User Manual...
Page 20
22. FAN: (2.54mm Pitch 1x3 Pin Header),Fan connector, cooling fans can be connected directly for use. You may set the rotation condition of cooling fan in menu of BIOS CMOS Setup. Pin# Signal Name Ground Rotation ACS-2120 User Manual...
Page 21
Pin# Signal Name LVDS1_VDD5 LVDS1_VDD5 Ground Ground LVDS1_VDD3 LVDS1_VDD3 LADATAN0 LADATAP0 LADATAN1 LADATAP1 LADATAN2 LADATAP2 LACLKN LACLKP LDDC_CLK LBKLT_EN BKLT_CTRL Ground Ground +V12S +V12S 25. BKL: (2.0mm Pitch 1x5 box Pin Header), Backlight control connector for LVDS1. ACS-2120 User Manual...
Page 22
3.3V or 5V. The default setting of the product is 3.3V. 33. DDR3: the socket is located at the (SO-DIMM 204Pin socket), DDRIII memory socket, bottom of the board and supports 204Pin 1.5V DDRIII 800MHz FSB SO-DIMM memory module up to 2G. ACS-2120 User Manual...
Auto – detecting USB Mass Storage Devices .. 00 USB Mass storage devices found and configured. Checking NVRAM.. 0085 Press F11 to load default values and continue 0085 Press F11 key to enter Boot Menu during POST, as shown by the following figure. ACS-2120 User Manual...
Second : 0 to 59 System Date: Set the system date, the date format is: Note that the „Day‟ automatically changes when you set the date. Day: Month: 01 to 12 Date: 01 to 31 Year: 2010 to 2099 ACS-2120 User Manual...
Page 30
While entering setup, BIOS auto detects the presence of IDE devices. This displays the status of auto detecting of IDE devices 3.4.7 MPS Configuration BIOS SETUP UTILITY Advanced MPS Configuration Select MPS Revision [1.4] Revision ← Select Screen ↑↓ Select Item +- Charge Field ACS-2120 User Manual...
Page 36
Available: Specified DMA is available to be used by PCI/PnP devices. Reserved: Specified DMA is reserved for use by legacy ISA devices. Reserved Memory Size: Size of memory block to reserve for legacy ISA devices. [Disabled] [16k] [32k] [64k] ACS-2120 User Manual...
Allows BIOS to skip certain tests while booting .This will decrease the time needed to boot the system. Quiet Boot: [Disabled] [Enabled] Disabled: Displays normal POST messages. Enabled: Displays OEM logo instead of POST messages. AddOn ROM Display Mode: Set display mode for Option ROM. [Force BIOS] [Keep Current] ACS-2120 User Manual...
Page 38
[Disabled] Hit „DEL‟Messgae Display : Displays “press” DEL to run Setup in POST. [Enabled] [Disabled] Interrupt 19 Capture: [Disabled] [Enabled] Enabled: Allows option ROMs to trap interrupt 19. Boot Device Priority: Specifies the Boot Device Priority sequence. ACS-2120 User Manual...
Install or Change the password. Password Check: [Setup] [Always] Setup: Check password while invoking setup. Always: Check password while invoking setup a well as on each boot. Boot Sector Virus Protection: [Disabled] [Enabled] Enabled / Disabled Boot Sector Virus Protection. ACS-2120 User Manual...
Page 43
[Disabled] +- Charge Field HDA Controller [Disabled] F1 General Help SMBUS Controller [Enabled] F10 Save and Exit ESC Exit SLP_S4# Min. Assertion Width [1 to 2 seconds] Restore on AC Power Loss [Power on] PCIE Ports Configuration ACS-2120 User Manual...
Page 44
[Disabled] [Enabled] HDA Controller: [Enabled] [Disabled] SMBUS Controller: [Enabled] [Disabled] SLP_S4# Min. Assertion Width: [1 to 2 Seconds] [4 to 5 Seconds] [3 to 4 Seconds] [2 to 3 Seconds] Restore on AC Power Loss: [Turn On] ACS-2120 User Manual...
Save Changes and Exit: Save configuration changes and exit setup? F10 key can be used for this operation) [OK] [Cancel] Discard Changes and Exit: Discard Changes and Exit setup? ESC key can be used for this operation) [OK] [Cancel] ACS-2120 User Manual...
Page 46
F7 key can be used for this operation) [OK] [Cancel] Load Optimized Defaults: Load Optimized Defaults? F9 key can be used for this operation) [OK] [Cancel] Load Fail-Safe Defaults: Load Fail-Safe Defaults? F9 key can be used for this operation) [OK] [Cancel] ACS-2120 User Manual...
VGA driver, LAN driver, Audio driver. Installation instructions are given below. Important Note: After installing your Windows operating system (Windows XP), you must install first the Intel Chipset Software Installation Utility before proceeding with the installation of drivers. ACS-2120 User Manual...
4.1 Intel Chipset Driver To install the Intel chipset driver, please follow the steps below. Step 1. Select Intel(R) Chipset Atom D525 + Intel ICH8M from the list. Step 2. Click Next to setup program. ACS-2120 User Manual...
Page 49
Step 3. Read the license agreement. Click Yes to accept the terms of the license agreement. Step 4. Click Next to continue. ACS-2120 User Manual...
Page 50
Step 5. Click Next. Step 6. Select Yes, I want to restart this computer now. Click Finish then remove any installation media from the drives. ACS-2120 User Manual...
4.2 Intel GMA 3150 VGA Chipset Driver To install the VGA drivers, follow the steps below to proceed with the installation. Step 1. Click Intel GMA 3150 VGA Chipset Driver. Step 2. Click Next to continue. ACS-2120 User Manual...
Page 52
Step 3. Click Next. Step 4. Read the license agreement. Click Yes to accept license agreement. ACS-2120 User Manual...
Page 53
Step 5. Click Next. Step 6. Click Next to continue. ACS-2120 User Manual...
Step 7. Select Yes, I want to restart this computer now. Click Finish then remove any installation media from the drives. 4.3 Intel 82574L Network adapter Driver To install the Intel 82574L Network adapter Driver, please follow the steps below. Step 1. Select Intel(R)82574L Network Adapter from the list ACS-2120 User Manual...
Page 55
Step 2. Click Next to continue. Step 3. Read the license agreement. Select I accept the terms in the license agreement then click Next to continue. ACS-2120 User Manual...
Page 56
Step 4. Tick Drivers/Intel(R) PROSet for Windows* Device Manager/Advanced Network Services. Click Next to continue. Step 5. Click Install to begin installation. ACS-2120 User Manual...
Step 6. Click Finish to complete the installation. 4.4 Realtek HD Audio Driver Installation To install the Realtek High Definition (HD) Audio driver, please follow the steps below. Step 1. Select Realtek ALC662 HD Audio Driver from the list ACS-2120 User Manual...
Page 58
Step 2. Click Next to continue the installation. Step 3. Click Yes. ACS-2120 User Manual...
Page 59
Step 4. Wait for installation. Step 5. Select Yes, I want to restart my computer now. Then click OK. ACS-2120 User Manual...
