  • Page 2 Intel Celeron N2930 Fanless BOX PC User Manual Release Date Revision Jun. 2017 V1.1 ®2017 Aplex Technology, Inc. All Rights Reserved. Published in Taiwan Aplex Technology, Inc. 15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail: sales@aplex.com.tw...
  • Page 3 Revision History Reversion Date Description 2016/02/16 Official Version  2017/06/03 Add ACS-2311 BOX PC  Modify motherboard ACS-2310_2311 User Manual...

  • Page 4: War N In G! /D Iscla Im Er

    This information in this document is subject to change without notice. In no event shall Aplex Technology Inc. be liable for damages of any kind, whether incidental or consequential, arising from either the use or misuse of information in this document or in any related materials.

  • Page 5: Packin G List /Safet Y Pre Cau Tion S

    Packing List Accessories (as ticked) included in this package are: □ Adaptor □ Driver & manual CD disc □ Other.___________________(please specify) Safety Precautions Follow the messages below to prevent your systems from damage: ◆ Avoid your system from static electricity on all occasions. ◆...

  • Page 6: Table Of Contents

    Figure 1.1: Dimensions of ACS-2310…………..…………………………..…...7 Figure 1.2: Dimensions of ACS-2311 (Din rail mount)………………..…...7 Figure 1.3: Dimensions of ACS-2311 (Wall mount)….………………..…...8 Figure 1.4: Front View of ACS-2310…………………………………..……...9 Figure 1.5: Rear View of ACS-2310……………………………………..………..9 Figure 1.6: Overview of ACS-2311……………………………………..………..9 Figure 2.1: Dimensions of Motherboard SBC-7116………………….……12 Figure 2.2: Top of Motherboard SBC-7116………………..…………….……13...

  • Page 7: Getting Started

     Ultra Slim design  1 x 2.5” SATA2 HDD Space 1.2 Specifications System Model name ACS-2310 ACS-2311 Processor Intel Celeron N2930 1.83GHz Processor System Chipset System Memory 1 x 204-pin SO-DIMM slot up to 8GB DDR3L 1333MHz Outside I/O 2 x USB3.0 type A...
  • Page 8 Expansion Expansion Slots 1 x Mini-PCIe slot full size 1 x Mini-PCIe slot full size (shared with mSATA) Power Power Input DC 9~36V Power Consumption MAX: 19W MAX: 17W Mechanical Construction Plating Titanium Gray Aluminum Heatsink and Black Steel Chassis Dimension 180 x 130 x 35.5 mm 180 x 130 x 55 mm...

  • Page 9: Dimensions

    1.3 Dimensions Figure 1.1: Dimensions of ACS-2310 Figure 1.2: Dimensions of ACS-2311 (Din rail mount) ACS-2310_2311 User Manual...

  • Page 10: Figure 1.3: Dimensions Of Acs-2311 (Wall Mount)

    Figure 1.3: Dimensions of ACS-2311 (Wall mount) ACS-2310_2311 User Manual...

  • Page 11: Brief Description Of Acs-2310/2311

    (shared with mSATA) for expansion. The model is plating titanium gray aluminum heatsink and black steel chassis design. The ACS-2310/2311 works very well along with any of our display series and it absolutely can provide an easy way to perform control and field maintenance.

  • Page 12: Chapter 2 Motherboard

    Chapter 2 Motherboard SBC-7116 is a 3.5” industrial motherboard developed on the basis of Intel BayTrail,which provides abundant peripheral interfaces to meet the needs of different customers.Also,it features two GbE ports, 4-COM ports and one Mini PCIE and one mSATA configuration. To satisfy the special needs of high-end customers, Due to its compact size, the product is widely used in various sectors of industrial control.
  • Page 13 4-bit digital Input 4-bit digital Output Battery Support CR2477 Li battery by 2-pin header (1000mAh) Audio Support Audio via Realtek ALC269-VB HD audio codec 1x Stack audio Jack（Line out） Line in/Line out/Mic by 2 x 6 Pin header 1x 4Pin Wafer Connector,Amplifier 2 channel output (SPK1) 1x SIM Card Holder,1x 6Pin Wafer by SIM1 Power 1x 2-pin power input connector (Wide range DC+9V~36V)

  • Page 14: Board Dimensions

    2.2 Board Dimensions (units :mm) Figure 2.1: Dimensions of motherboard SBC-7116 ACS-2310_2311 User Manual...

  • Page 15: Jumpers And Connectors Location

    2.3 Jumpers and Connectors Location Figure 2.2: Top of motherboard SBC-7116 Figure 2.3: Bottom of motherboard SBC-7116 ACS-2310_2311 User Manual...

  • Page 16: Jumpers Setting And Connectors

    2.4 Jumpers Setting and Connectors 1. BAT1 : (1.25mm Pitch 1x2 wafer Pin Header) 3.0V Li battery is embedded to provide power for CMOS. Pin# Signal Name Pin1 Ground Pin2 VCC_RTC 2. SW1(1，2): (Swich),ATX Power and Auto Power on jumper setting. Mode Pin1 on Auto Power on (Default)
  • Page 17 4. CPU1: (FCBGA1170), onboard Intel Bay trail-I/M Processors. Processor Model Numbe Cores/ Remarks Threads SBC-7116-N2930 N2930 2.16GHz 4 / 4 4.5/7.5W SBC-7116-J1900 J1900 2.42GHz 4 / 4 option 5. H1/H2/H3/H4(CPU SCREW HOLES): Four screw holes for fixed CPU Cooler assemble. CPU FAN SCREW HOLES, 6.
  • Page 18 10. SW1(PIN3，PIN4): (Swich),18bit or 24bit LVDS setting. Mode Pin3 on Single Channel LVDS Pin3 off Dual Channel LVDS Pin4 on 18bit LVDS Pin4 off 24bit LVDS 11. U11: AT24C02-DIP8,The EEPROM IC（U11）is the set of LVDS resolution. If you need other resolution settings, please upgrade U11 data. Model LVDS resolution 1280*1024 (Default)
  • Page 19 13. LVDS1： (1.25mm Pitch 2x20 Connector,DF13-40P),For 18/24-bit LVDS output connector,Fully supported by Parad PS8625(DDI1 to LVDS), the interface features dual channel 24-bit output. Low Voltage Differential Signaling, A high speed, low power data transmission standard used for display connections to LCD panels. Signal Name Pin# Pin#...
  • Page 20 15. COM1: (2.0mm Pitch 2X5 Pin Header),COM1 Port, standard RS232 ports are provided. They can be used directly via COM cable connection. ACS-2310_2311 User Manual...
  • Page 21 16. JP2: (2.0mm Pitch 2x3 Pin Header),COM2 jumper setting, pin 1~6 are used to select signal out of pin 9 of COM2 port. JP2 Pin# Function Close 1-2 COM2 Pin9 RI (Ring Indicator) (default) Close 3-4 COM2 Pin9 = +5V/1A (option) Close 5-6 COM2 Pin9 = +12V/1A...
  • Page 22 20. USB30: E-USB3-1/E-USB3-2：(Double stack USB typeA),Rear USB 3.0 connector, it provides up to 2 USB3.0 ports,USB 3.0 allows data transfers up to 5.0Gb/s ,support USB2.0 and full-speed and low-speed signaling. Each USB Type A Receptacle (2 Ports) Current limited value is 2.0A. If the external USB device current exceeds 2.0A, please separate connectors into different Receptacle.
  • Page 23 Note: Before connection, make sure that pinout of the USB Cable is in accordance with that of the said tables. Any inconformity may cause system down and even hardware damages. Each USB Type A Receptacle (2 Ports) Current limited value is 2.0A. If the external USB device current exceeds 2.0A, please separate connectors into different Receptacle.
  • Page 24 26. SPK1: (2.0mm Pitch 1x4 Wafer Pin Header),support a stereo Class-D Speaker Amplifier with 2 watt per channel output power Pin# Signal Name SPK_OUTL_P SPK_OUTL_N SPK_OUTR_N SPK_OUTR_P 27. SATA_P2: (2.5mm Pitch 1x2 Wafer Pin Header), Two onboard 5V output connectors are reserved to provide power for SATA devices. Pin# Signal Name +DC5V_S0...
  • Page 25 31. M-PCIE1: (Socket 52Pin),mini PCIe socket, it is located at the top, it supports mini PCIe devices with USB2.0 and SIM and SMBUS and PCIe signal. MPCIe card size is 30 x 50.95mm. Function Support Mini PCie ● SIM Signal ●...
  • Page 26 36. BUZZER1: Onboard buzzer. 37. FP1: (2.0mm Pitch 2X5 Pin Header), Front panel connector. Signal Name Pin# Pin# Signal Name HDD_LED+ POWER LED+ HDD LED- Ground Ground RESET+ Ground BUZZER+ BUZZER- Pin1-3: HDD LED, They are used to connect hard disk activity LED. The LED blinks when the hard disk is reading or writing data.

  • Page 27: Chapter 3 Bios Setup

    Chapter 3 BIOS Setup 3.1 Operations after POST Screen After CMOS discharge or BIOS flashing operation,.Press [Delete] key to enter CMOS Setup. After optimizing and exiting CMOS Setup Press F11 to load default values and continue 0085 3.2 BIOS SETUP UTILITY Press [Delete] key to enter BIOS Setup utility during POST, and then a main menu containing system summary information will appear.

  • Page 28: R E V I S I O N H I S T O R Y

    3.3 Main Settings System Time: Set the system time, the time format is: Hour : 0 to 23 Minute : 0 to 59 Second : 0 to 59 System Date: Set the system date, the date format is: Day: Note that the ‘Day’ automatically changes when you set the date.

  • Page 29: Advanced Settings

    3.4 Advanced Settings 3.4.1 ACPI Settings Enable ACPI Auto Configuration: [Disabled] [Enabled] Enable Hibernation: [Enabled] [Disabled] ACPI Sleep State: [S3 (Suspend to RAM) ] [Suspend Disabled] Lock Legacy Resources: [Disabled] [Enabled] ACS-2310_2311 User Manual...
  • Page 30 3.4.2 NCT6106D Super IO Configuration Super IO Chip NCT6106D Serial Port 1 Configuration Serial port [Enabled] [Disabled] Device Settings IO=3F8h； IRQ=4； Change Settings [Auto] [IO=3F8h； IRQ=4] [IO=3F8h ;IRQ=3,4,5,6,7,9,10,11,12 ;] [IO=2F8h ;IRQ=3,4,5,6,7,9,10,11,12 ;] [IO=3E8h ;IRQ=3,4,5,6,7,9,10,11,12 ;] [IO=2E8h ;IRQ=3,4,5,6,7,9,10,11,12 ;] COM1 Mode Selection [RS-232] [RS-485] [RS-422]...
  • Page 31 Change Settings [Auto] [IO=3E8h;IRQ=7] [IO=3E8h ;IRQ=3,4,5,6,7,9,10,11,12 ;] [IO=2E8h ;IRQ=3,4,5,6,7,9,10,11,12 ;] [IO=2F0h ;IRQ=3,4,5,6,7,9,10,11,12 ;] [IO=2E0h ;IRQ=3,4,5,6,7,9,10,11,12 ;] Serial Port 4 Configuration Serial port [Enabled] [Disabled] Device Settings IO=2E8h； IRQ=3； Change Settings [Auto] [IO=2E8h;IRQ=7] [IO=3E8h ;IRQ=3,4,5,6,7,9,10,11,12 ;] [IO=2E8h ;IRQ=3,4,5,6,7,9,10,11,12 ;] [IO=2F0h ;IRQ=3,4,5,6,7,9,10,11,12 ;] [IO=2E0h ;IRQ=3,4,5,6,7,9,10,11,12 ;] 3.4.3 NCT6106D HW Monitor...
  • Page 32 3.4.5 CPU Configuration Socket 0 CPU Information Intel(R) Celeron(R) CPU J1900 @ 1.99GHz CPU Signature 30678 Microcode Patch Max CPU Speed 1990MHz Min CPU Speed 1334MHz Processor Cores Intel HT Technology Not Supported Intel VT-x Technology Supported L1 Data Cache 24KB x 4 L1 Code Cache 32KB x 4...
  • Page 33 3.4.6 PPM Configuration EIST [Enabled] [Disabled] CPU c state Report [Enabled] [Disabled] Max CPU C-state [C7] [C6] [C1] SOix [Enabled] [Disabled] 3.4.7 Thermal Configuration Parameters Critical Trip Point [90C] Passive Trip Point [85C] Dynamic Platform&Thermal Framework DPTF [Disabled] [Enabled] CPU Sensor Participant Critical [70C] Passive...
  • Page 34 3.4.8 IDE Configuration Serial-ATA(SATA) [Enabled] [Disabled] SATA Test Mode [Enabled] [Disabled] SATA Speed Support [Gen2] [Gen1] SATA ODD Port [No ODD] [Port0 ODD] [Port1 ODD] SATA Mode [AHCI Mode] [IDE Mode] Serial-ATA Port 0 [Enabled] [Disabled] SATA Port0 HotPlug [Enabled] [Disabled] Serial-ATA Port 1 [Enabled]...
  • Page 35 PCI Express Dynamic Clock Gating [Enabled] [Disabled] OS Selection [Windows 8.X] [Android] [Windows 7] 3.4.10 LPSS & SCC Configuration LPSS & SCC Devices Mode [ACPI mode] [PCI mode] SCC Configuration SCC eMMC Support [Disabled] [Enabled] eMMC Secure Erase [Disabled] [Enabled] SCC SDIO Support [Disabled] [Enabled]...
  • Page 36 LPSS I2C #3 Support [Disabled] [Enabled] LPSS I2C #4 Support [Disabled] [Enabled] LPSS I2C #5 Support [Disabled] [Enabled] LPSS I2C #6 Support [Disabled] [Enabled] LPSS I2C #7 Support [Disabled] [Enabled] I2C touch Device Address [AUTO] [0x4B] [0x4A] LPSS HSUART #1 Support [Disabled] [Enabled] LPSS HSUART #2 Support...
  • Page 37 Witt Setting [Disabled] [Enabled] 3.4.12 Network Stack Configuration Network Stack [Disabled] [Enabled] 3.4.13 CSM Configuration Compatibility Support Module Configuration CSM Support [Disabled] [Enabled] CSM16 Module Version 07.74 GateA20 Active [Upon Request] [Always] Option ROM Messages [Force BIOS] [Keep Current] INT19 Trap Response [Immediate] [Postponed] Boot option filter...
  • Page 38 Video [Do not launch] [UEFI] [Legacy] Other PCI devices [UEFI] [Legacy] 3.4.14 Trusted Computing Configuration Security Device Support [Disabled] [Enabled] Current Status Information NO Securtiy Device Found 3.4.15 USB Configuration USB Module Version 8.11.01 USB Devices: 1 Keyboard,1 Mouse,2 Hubs Legacy USB Support [Disabled] [Enabled]...
  • Page 39 Device power-up delay [Auto] [Manual] 3.4.16 Platform Trust Technology TPM Configuraion fTPM [Disabled] [Enabled] 3.4.17 Security Configuration Intel(R) TXE Configuration [Disabled] [Enabled] TXE HMRFPO [Disabled] [Enabled] TXE Firmware Update [Disabled] [Enabled] TXE EOP Message [Disabled] [Enabled] TXE Unconfiguration Perform Intel(R) Anti-Theft Technology Configuration Intel(R) AT [Disabled] [Enabled]...

  • Page 40: Chipset Settings

    Chipset Settings 3.5.1 North Bridge ►Intel IGD Configuration GOP Configuration GOP Driver [Enabled] [Disabled] Intel IGD Configuration Integrated Graphics Device [Enabled] [Disabled] IGD Turbo Enable [Enabled] [Disabled] Primary Display [IGD] GFX Boost [Enabled] [Disabled] PAVC [LITE Mode] DVMT Pre-Allocated [64M] DVMT Total Gfx Mem [256MB] Aperture Size...
  • Page 41 GTT Size [2MB] IGD Thermal [Enabled] [Disabled] Spread Spectrum clock [Enabled] [Disabled] ISP Enable/Disable [Enabled] [Disabled] ISP PCI Device Selection [Enabled] [Disabled] Vcc,Vnn Configuration for Power state2: Vcc_Vnn Config for Power state2 [Enabled] [Disabled] ►IGD-LCD Control Force Lid Status [Off] [On] [Auto] ALS Support...
  • Page 42 BIOS Control Backlight Level [Level 7] Max TOLUD [Dynamic] 3.5.2 South Bridge ►Azalia HD Audio Audio Configuration LPE Audio Support [Enabled] [Disabled] Audio Controller [Enabled] [Disabled] Azalia VCi Enable [Enabled] [Disabled] Azalia Docking Support Enable [Enabled] [Disabled] Azalia PME Enable [Enabled] [Disabled] Azalia HDMI Codec...
  • Page 43 XHCI Mode [Smart Auto] USB2 Link Power Management [Enabled] [Disabled] USB 2.0(ENCI) Support [Disabled] USB Per Port Control [Enabled] [Disabled] USB Port 0 [Enabled] [Disabled] USB Port 1 [Enabled] [Disabled] USB Port 2 [Enabled] [Disabled] USB Port 3 [Enabled] [Disabled] ►PCI Express Configuration PCI Express Port 0 [Enabled]...
  • Page 44 Hot Plug [Enabled] [Disabled] Speed [Auto] Extra Bus Reserved Reserved Memory Reserved Memory Alignment Prefetchable Memory Prefetchable Memory Alignment Reserved I/O PCI Express Port 2 [Enabled] [Disabled] Hot Plug [Enabled] [Disabled] Speed [Auto] Extra Bus Reserved Reserved Memory Reserved Memory Alignment Prefetchable Memory Prefetchable Memory Alignment Reserved I/O...
  • Page 45 Restore AC Power Loss [Power Off] {Power On} [Last State] LCD PWM DC Mode [PWM] [DC] Serial IRQ Mode [Quiet] [Continuous] Global SMI Lock [Enabled] [Disabled] BIOS Read/Write Protection [Enabled] [Disabled] ACS-2310_2311 User Manual...

  • Page 46: Security Settings

    Security Settings 3.6.1 Administrator Password 3.6.2 User Password Type the password with up to 20 characters and then press Enter key. This will clear all previously typed CMOS passwords. You will be requested to confirm the password. Type the password again and press Enter...

  • Page 47: Boot Settings

    Boot Settings Setup Prompt Timeout Bootup Numlock State [On] [off] Quiet Boot [Disabled] [Enabled] Fast Boot [Disabled] [Enabled] VGA Support [Auto] [EFI Driver] USB Support [Disabled] [Full Initial] [Partial Initial] PS2 Devices Support [Disabled] [Enabled] Network Stack Driver Support [Disabled] [Enabled] Boot Option Priorities Boot Option #1...

  • Page 48: Save &Exit Settings

    Save & Exit Settings Save Changes and Exit Save & Exit Setup save Configuration and exit ? [Yes] [No] Discard Changes and Ext Exit Without Saving Quit without saving? [Yes] [No] Save Changes and Reset Reset the system affer Saving The changes? [Yes] [No] Discard Changes and Reset...
  • Page 49 Restore Defaults Restore /Load Defaults values for all the setup options? [Yes] [No] Save as user Defaults Save the changes done so far as User Defaults? [Yes] [No] Restore user Defaults Restore the User Defaults to all the setup options? [Yes] [No] Boot Override...

  • Page 50: Chapter 4 Installation Of Drivers

    Chapter 4 Installation of Drivers This chapter describes the installation procedures for software and drivers under the windows 8.1/10. The software and drivers are included with the motherboard. The contents include Intel chipset driver, VGA driver, Audio driver, and TXE driver Installation instructions are given below.

  • Page 51: Intel(R) Atomtm Soc Chipset

    4.1 Intel(R) AtomTM SoC Chipset To install the Intel chipset driver, please follow the steps below. Step 1. Select Intel (R) AtomTM SoC Chipset from the list Step 2. Here is welcome page. Please make sure you save and exit all programs before install.
  • Page 52 Step 3. Read the license agreement. Click Accept to accept all of the terms of the license agreement. Step 4. Click Install to begin the installation. ACS-2310_2311 User Manual...
  • Page 53 Step 5. Click Finish to exit the wizard. ACS-2310_2311 User Manual...

  • Page 54: Intel(R) Vga Chipset

    4.2 Intel(R) VGA Chipset To install the Intel (R) VGA Chipset, please follow the steps below. Step 1. Select Intel(R) VGA Chipset from the list. Step 2. . Click Next. ACS-2310_2311 User Manual...
  • Page 55 Step 3. Choose automatically run function and Click Next to setup program. Step 4. Read the license agreement. Click Yes to accept all of the terms of the license agreement. ACS-2310_2311 User Manual...
  • Page 56 Step 5. Click Next to continue. Step 6. Click Next to continue. ACS-2310_2311 User Manual...
  • Page 57 Step 7. Select Yes, I want to restart this computer now. Click Finish, then remove any installation media from the drives. ACS-2310_2311 User Manual...

  • Page 58: Realtek Alc662 Hd Audio Driver Installation

    4.3 Realtek ALC662 HD Audio Driver Installation To install the Realtek ALC662 HD Audio Driver, please follow the steps below. Step 1. Select Realtek AL662 HD Audio Driver from the list Step 2. Click Next to continue. ACS-2310_2311 User Manual...
  • Page 59 Step 3. Click Yes, I want to restart my computer now. Click Finish to complete the installation. ACS-2310_2311 User Manual...

  • Page 60: Intel_Txe(Win) Driver

    4.4 Intel_TXE(Win) Driver To install the Intel_TXE(Win) Driver, please follow the steps below. Step 1. Select Intel_TXE(Win) Driver from the list Step 2. Click Next to continue. ACS-2310_2311 User Manual...
  • Page 61 Step 3. Read the license agreement. Choose Accept and click Next to accept all of the terms of the license agreement. Step 4. Click Next to continue. ACS-2310_2311 User Manual...
  • Page 62 Step 5. Click Finish to complete the installation. ACS-2310_2311 User Manual...
