ACS-2685 Box PC

User Manual

Release Date
Revision
Nov. 2012
V1.0
® 2012 Aplex Technology, Inc.
All Rights Reserved.
Published in Taiwan
Aplex Technology, Inc.
15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan
Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail:
aplex@aplex.com.tw
URL:
www.aplex.com.tw
ACS-2685 User Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ACS-2685 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aplex ACS-2685

Summary of Contents for Aplex ACS-2685

  • Page 1: User Manual

    ACS-2685 Box PC User Manual Release Date Revision Nov. 2012 V1.0 ® 2012 Aplex Technology, Inc. All Rights Reserved. Published in Taiwan Aplex Technology, Inc. 15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail: aplex@aplex.com.tw...

  • Page 2: Warning

    This information in this document is subject to change without notice. In no event shall Aplex Technology Inc. be liable for damages of any kind, whether incidental or consequential, arising from either the use or misuse of information in this document or in any related materials. ACS-2685 User Manual...

  • Page 3: Packing List

    Always disconnect power when the system is not in use. ◆ Disconnect power when you change any hardware devices. For instance, when you connect a jumper or install any cards, a surge of power may damage the electronic components or the whole system. ACS-2685 User Manual...

  • Page 4: Table Of Contents

    3.9 Exit Options..............65 Chapter 4 Installation of Drivers 4.1 Intel Chipset Driver.…………………………...…………………………68 4.2 Intel Graphics Media Accelerator Driver...……………………………..71 4.3 Intel 82574L LAN Device Driver………………………………………….75 4.4 Realtek ALC662 HD Audio Driver Installation…….………….…………78 4.5 Microsoft .NET Framework 3.5 Service Installation……………………80 ACS-2685 User Manual...
  • Page 5 Figures Figure 1.1: Dimensions of the ACS-2685 AC input………………….…..…..8 Figure 1.2: Dimensions of the ACS-2685 AC input with DVD Device…….…8 Figure 1.3: Dimensions of the ACS-2685 DC input…………………………...9 Figure 1.4: Dimensions of the ACS-2685 DC input with DVD Device...9 Figure 1.5: Left-front View of ACS-2685............10 Figure 1.6: Right-front View of ACS-2685...........10...

  • Page 6: Specifications

    Construction / Color Steel and Aluminum Heatsink / White  Mounting Wall Mount default  Din Rail Mount for option Dimensions 211.2x203.5x155 (WxHxD mm) 211.2x203.5x177 (with DVD Device) Net Weight 5.9kgs 0~50 °C Operating Temperature Storage Temperature -20~60 °C ACS-2685 User Manual...
  • Page 7 10%~90%@ 40℃, non-condensing Storage Humidity Vibration MIL-STD-810F 514.5C-2 (with CF or SSD) Shock 50G Half sine(11 msec. duration)/operation with CF/SSD (IEC 60068-2-27) Drop 92cm(1 Corner, 3 Edge, 6 Surface) Certificate CE / FCC Class A ACS-2685 User Manual...

  • Page 8: Dimensions

    1.2 Dimensions System Fan location Figure 1.1: Dimensions of the ACS-2685 AC input Figure 1.2: Dimensions of the ACS-2685 AC input with DVD Device ACS-2685 User Manual...

  • Page 9: Figure 1.3: Dimensions Of The Acs-2685 Dc Input

    System Fan location System Fan location Figure 1.3: Dimensions of the ACS-2685 DC input Figure 1.4: Dimensions of the ACS-2685 DC input with DVD Device ACS-2685 User Manual...

  • Page 10: Brief Description

    1.3 Brief Description of the ACS-2685 The ACS-2685 is a Fan-less High-efficiency Thermal Solution and ultra-compact standalone Box PC, powered by an Intel Core 2 Duo with 45nm, up to P8600 2.4GHz, and supporting 4 x USB 2.0 ports, 4 x COM Ports, 1 x VGA, support PCI or PCIe Expansion, 2 x SATA HDD space, 1 x external CF slot, 9-32V wide-ranging power input etc.

  • Page 11: Installation Of Hdd

    HDD bracket as shown in the picture ACS-2685 Step 3 Loosen screw and draw the HDD bracket out as shown in the picture ACS-2685 Step 4 That’s how it should look after it has been installed. ACS-2685 User Manual...

  • Page 12: Installation Of Pci Add-On

    ** Half Expansion-card limit to be not more than 175mm length Step 3 Tighten the 1 screw as shown in the picture. That’s how it should look after it has been installed. ACS-2685 User Manual...

  • Page 13: Instructions For Use Of Internal Usb Dongle

    ACS-2685 Step 2 Now slide into the USB dongle as shown in the picture ACS-2685 Step 3 Tighten the 1 screw as shown in the picture. That’s how it should look after it has been installed. ACS-2685 User Manual...

  • Page 14: Installation Of Wall Mount Bracket

    1.7 Installation of Wall Mount Bracket Figure 1.7: Wall Mount of ACS-2685 Type 1 ACS-2685 User Manual...

  • Page 15: Figure 1.8: Wall Mount Of Acs-2685 With Dvd Device Type 2

    Figure 1.8: Wall Mount of ACS-2685 with DVD Device Type 2 ACS-2685 User Manual...

  • Page 16: Figure 1.9: Wall Mount Of Acs-2685 With Dvd Device Type 3

    Figure 1.9: Wall Mount of ACS-2685 with DVD Device Type 3 ACS-2685 User Manual...

  • Page 17: Figure 1.10: Wall Mount Of Acs-2685 Type 4

    Figure 1.10: Wall Mount of ACS-2685 Type 4 ACS-2685 User Manual...

  • Page 18: Figure 1.11: Wall Mount Of Acs-2685 Type 5

    Figure 1.11: Wall Mount of ACS-2685 Type 5 ACS-2685 User Manual...

  • Page 19: Chapter 2 Hardware

    Chapter 2 Hardware 2.1 Mainboard Figure 2.1: Mainboard Dimensions ACS-2685 User Manual...

  • Page 20: Installations

    PC104+ type (120 pins, Aplex designed) connector richer extension functions. The product is widely used in various sectors of industrial control. 2.2.1 Jumpers Setting and Connectors Figure 2.2: Jumpers and Connectors Location_ Board Top ACS-2685 User Manual...

  • Page 21: Figure 2.3: Jumpers And Connectors Location_ Board Bottom

    (2.0mm Pitch 1X2 Pin Header),ATX Power and Auto Power on jumper setting. Mode Open ATX Power Close Auto Power on (Default) 2. RTC/SRTC: (2.0mm Pitch 1X2 Pin Header)CMOS clear jumper, CMOS clear operation will permanently reset old BIOS settings to factory defaults. RTC/SRTC CMOS ACS-2685 User Manual...
  • Page 22 Signal Pin# Name Pin1 VBAT PIN2 Ground 4. DCIN: (5.08mm Pitch 1x3 Pin Connector),DC9V ~ DC32V System power input connector。 Power Pin# Input DC+9V~32 Pin1 Pin2 Ground Pin3 Ground Location Location Location (5.4.6.) Power Mode (5.4.4.) (5.4.5.) ACS-2685 User Manual...
  • Page 23 (2.0mm Pitch 1X3 box Pin Header), connect PSON and 5VSB and Ground signal,support ATX Power model. Reserved. Pin# Signal Name Pin1 ATX PSON PIN2 ATX Ground PIN3 ATX 5VSB 7. CPU1: (Socket P), installing the CPU Socket. ACS-2685 User Manual...
  • Page 24 (CRT 2.0mm Pitch 2X5 Pin Header), Video Graphic Array Port, Provide 2x5Pin cable to VGA Port, they can not work at the same time for CRT and VGA1. Signal Name Pin# Pin# Signal Name CRT_RED Ground CRT_GREEN Ground CRT_BLUE VGA_EN CRT_H_SYN CRT_DDCDAT ACS-2685 User Manual...
  • Page 25 Intel GM45 chipset, the interface features dual channel 18/24-bit output. Signal Name Pin# Pin# Signal Name VDD5 VDD5 Ground Ground VDD33 VDD33 LB_D0_N LA_D0_N LB_D0_P LA_D0_P Ground Ground LB_D1_N LA_D1_N LA_D1_P LA_D1_P Ground Ground LB_D2_N LA_D2_N ACS-2685 User Manual...
  • Page 26 (Type DB9),Rear serial port, standard DB9 Male serial port is provided to make a direct connection to serial devices. COM1 port is controlled by pins No.1~6 of JCOM1,select output Signal RI or 5V or 12v, For details, please refer to description of JCOM1. Pin# Signal Name DCD# (Data Carrier Detect) ACS-2685 User Manual...
  • Page 27 RTS (Request To Send) CTS (Clear To Send) RI (Ring Indicator) 18. COM5: (2.0mm Pitch 2X5 Pin Header),COM5 Port, standard RS232 ports are provided. They can be used directly via COM cable connection. Signal Pin# Pin# Signal Name Name Ground ACS-2685 User Manual...
  • Page 28 Rear LAN port, Two standard 10/100/1000M RJ-45 Ethernet ports (RJ45 are provided. Used Intel 82574L chipset, LINK LED (green) and ACTIVE LED (yellow) respectively located at the left-hand and right-hand side of the Ethernet port indicate the activity and transmission state of LAN. ACS-2685 User Manual...
  • Page 29 Onboard buzzer. 26. JP_104P: (2.0mm Pitch 1X3 Pin Header) PC104+ port voltage selection jumper, select voltage The default for this jumper is “all open”, meaning the for PCI-104 Plus devices. user must select the voltage to be used. ACS-2685 User Manual...
  • Page 30 RS485 port, three USB ports, one power led, one power button, via a dedicated cable connected to TB-523 MIO1. Functio Signal Name Pin# Pin# Signal Name Function 422RX+ 485+ / 422TX+ 422RX- 485- / 422TX- COM3 ACS-2685 User Manual...
  • Page 31 Ground MIO_PSON- PSON+ RESET RESET Ground PSON- BUZZER+ BUZZER- BUZZER- BUZZER+ GPIO_IN_1 GPIO_OUT_1 GPIO_I GPIO_OU GPIO_IN_2 GPIO_OUT_2 GPIO_IN_3 GPIO_OUT_3 GPIO_IN_4 GPIO_OUT_4 Ground 5V_S5 PS2_K/ PS2_Mous Ps2_KBDATA PS2_MSDATA PS2_KBCLK PS2_MSCLK 5V_USB_23 5V_USB_23 USB2 USB2_N USB3_N USB3 USB2_P USB3_P ACS-2685 User Manual...
  • Page 32 Note: When connecting LEDs and buzzer and GPIO and USB, pay special attention to the signal polarity. Make sure that the connector pins have a one-to-one correspondence with chassis wiring, or it may cause boot up failure. ACS-2685 User Manual...
  • Page 33 Output current of the connector must not be above 1A. 35. SATA1/SATA2/SATA3/SATA4: SATA Connectors, Four SATA connectors are provided, with transfer speed (SATA 7P), up to 3.0Gb/s. (Option): ASB-M801ET/EB: SATA1/SATA2/SATA3 drives supporting RAID 0 or RAID 1 function. ACS-2685 User Manual...
  • Page 34 CPU FAN SCREW HOLES, 38. H5/H6: mini PCIE card (30mmx30mm) assemble. mini PCIE MPCIE1 SCREW HOLES, H5 for H6 for card (30mmx50.95mm) assemble. 39. LED1: LED STATUS. Green LED for Motherboard Standby Power Good status, Yellow LED for HDD status. ACS-2685 User Manual...
  • Page 35 You may short them temporarily to realize system startup & shutdown or awaken the system from sleep state. PWR LED: status. POWER LED COM3: (Type DB9), I/O serial port, it provides selectable RS422/RS485 serial signal output. ACS-2685 User Manual...
  • Page 36 (2.0mm Pitch 2x10 Pin Header) COM4 function setting jumper. Function JP4 Pin# RS232 Close: 3-5,4-6,10-12,11-13 (Default) RS422 Close: 1-3,2-4,5-7,8-10,9-11,12-14,18-20 (option) RS485 Close: 5-7,8-10,9-11,12-14,16-18 (option) COM4: (Type DB9), I/O serial port, it provides selectable RS232/RS422/RS485 serial signal output. COM4 RS232 Type (Default)： Pin# Signal Name ACS-2685 User Manual...
  • Page 37 (2.0mm Pitch 1x4 box Pin Header), I/O USB connector, it provides one USB2.0 port, speed up to 480Mb/s. Pin# Signal Name 5V_USB1011 USB11_N USB11_P Ground USB10 and USB11 current limited value is 1.5A. If the external USB device current exceeds 1.5A, please separate connectors into different Receptacle. ACS-2685 User Manual...
  • Page 38 Ground GPIO_IN1 GPIO_IN2 GPIO_IN3 GPIO_IN4 GPIO_OUT1 GPIO_OUT2 GPIO_OUT3 GPIO_OUT4 MIO1: (DF13-40P) TB-523 MIO1 via a dedicated Y cable connected to ASB-M801 MIO1 and MIO2. Signal Name Pin# Signal Name 422_RX+ 485+_422TX+ 422_RX- 485-_422TX- Ground GPIO_IN1 GPIO_IN2 GPIO_IN3 ACS-2685 User Manual...
  • Page 39 21 22 5V_USB1011 USB9_N 23 24 USB11_N USB9_P 25 26 USB11_P Ground 27 28 Ground GPIO_OUT1 29 30 GPIO_OUT2 5V_USB1011 31 32 SO_POWER_SENS USB10_N 33 34 PWR_LED- USB10_P 35 36 PS_ON- Ground 37 38 Ground GPIO_OUT3 39 40 GPIO_OUT4 ACS-2685 User Manual...
  • Page 40 TB-521P2 connect to ASB-M801B/EB PC104+ connector, PC104+ is located at the Bottom, It provides two PCI slots. 43. TB-521P1E1: TB-521P1E1 connect to ASB-M801B/EB PC104+ and PCIEX2 connector,PC104+ and PCIEX2 are located at the Bottom, It provides one PCI slot and one PCIE slot. ACS-2685 User Manual...

  • Page 41: Chapter 3 Bios Setup

    Press F11 key to enter Boot Menu during POST, as shown by the following figure. Please select boot device： Network: IBA GE Slot 0200 v1353 Network: IBA GE Slot 0300 v1353 ↑and ↓ to move selection ENTER to select Boot device ESC to boot using defaults ACS-2685 User Manual...

  • Page 42: Bios Setup Utility

    Select a field Build Date : 05/13/11 Use[+] or [-] to : M801V001 configure system Time. Processor Genuine Intel(R) CPU @ 2.00GHz Speed :2000MHz ← Select Screen ↑↓ Select Item System Memory Charge Field Size :1981MB Tab Select Field ACS-2685 User Manual...

  • Page 43: Advanced Settings

    ► CPU Configuration ► IDE Configuration ► Super IO Configuration ► Hardware Health Configuration ► ACPI Configuration ► AHCI Configuration ► MPS Configuration ► PCI Express Configuration ► Smbios Configuration ← Select Screen ► USB Configuration ACS-2685 User Manual...
  • Page 44 Execute-Disable Bit Capability [Enabled] +- Charge Field Intel(R) C-SATAE tech [Disabled] F1 General Help F10 Save and Exit ESC Exit V02.61 © Copyright 1985-2006 American Mega trends , Inc. Hardware Prefetcher: [Enabled] [Disabled] Adjacent Cache Line Prefetch: ACS-2685 User Manual...
  • Page 45 +- Charge Field ► Third IDE Master : [Not F1 General Help Detected] F10 Save and Exit ► Fourth IDE Master : [Hard ESC Exit Disk] Hard Disk Write Protect [Disabled] IDE Detect Time Out (Sec) [35] ACS-2685 User Manual...
  • Page 46 [IDE] [RAID] [AHCI] SATA#2 Configuration: [Enhanced] [Disabled] Hard Disk Write Protect: [Disabled] [Enabled] IDE Detect Time Out : [35] [10] [15] [20] [25] [30] ATA(PI) 80Pin Cable Detection: [Host & Device] [Host] [Device] 3.4.3 Super IO Configuration ACS-2685 User Manual...
  • Page 47 COM3 Options: [RS485 ] [RS422] [RS422] for RS422 Mode [RS485] for RS485 Mode 3.4.4 Hardware Health Configuration BIOS SETUP UTILITY Advanced Hardware Health Configuration System Temperature :33℃/91℉ 55℃/131℉ 60℃/140℉ CPU Temperature :30℃/86℉ 65℃/149℉ CPUFAN Speed :4800 RPM ACS-2685 User Manual...
  • Page 48 Show you the current CPU temperature. CPUFAN Speed: Show you the current CPU Fan operating speed. Maximum CPU Temperature: [60℃/140℉] 55℃/131℉ 65℃/149℉ 70℃/158℉ Minimum PWM Duty for CPU Fan: [60%] [50%] [70%] [80%] 3.4.5 ACPI Configuration ACPI Setting: [Advanced ACPI Configuration] ACS-2685 User Manual...
  • Page 49 High Performance Event Timer: [Disabled] [Enabled] 3.4.6 AHCI Configuration BIOS SETUP UTILITY Advanced AHCI Setting Enables For supporting AHCI BIOS Support [Enabled] AHCI CD/DVD Boot Time out [35] ► AHCI Port0 [Not Detected] ► AHCI Port1 [Not Detected] ACS-2685 User Manual...
  • Page 50 +- Charge Field F1 General Help F10 Save and Exit ECS Exit V02.61 © Copyright 1985-2006 American Mega trends , Inc. MPS Revision: [1.1] [1.4] 3.4.8 PCI Express Configuration BIOS SETUP UTILITY Advanced PCI Express Configuration Enables/Disables ACS-2685 User Manual...

  • Page 51: Smbios Configuration

    Smbios Smi Support [Enabled] Support for PnP Func 50h-54h ← Select Screen ↑↓ Select Item Charge Field General Help F10 Save and Exit ESC Exit V02.61 © Copyright 1985-2006 American Mega trends , Inc. Smbios Smi Support: [Enabled] [Disabled] ACS-2685 User Manual...

  • Page 52: Advanced Pci/Pnp Settings

    Personal Computer Interconnect, is a computer bus that allows I/O device to operate nearly as fast as CPU in its own way. Some technical terms will be mentioned here. We recommend that non-professional users not make changes from factory default settings. ACS-2685 User Manual...
  • Page 53 F10 Save and Exit IRQ5 ESC Exit [Available] IRQ7 [Available] IRQ9 [Available] IRQ10 [Available] IRQ11 [Available] V02.61 © Copyright 1985-2006 American Mega trends , Inc. Clear NVRAM: [No] [Yes] Plug & Play OS: [No] [Yes] PCI Latency Timer: [64] ACS-2685 User Manual...
  • Page 54 Available: Specified IRQ is available to be used by PCI/PnP devices. Reserved: Specified IRQ is reserved for use by legacy ISA devices. DMA Channel 0/1/3/5/6/7: [Available] [Reserved] Available: Specified DMA is available to be used by PCI/PnP devices. ACS-2685 User Manual...

  • Page 55: Boot Settings

    V02.61 © Copyright 1985-2006 American Mega trends , Inc. Boot Setting Configuration： Configure Settings during System Boot. Quick Boot: [Enabled] [Disabled] Allows BIOS to skip certain tests while booting .This will decrease the time needed to boot the system. ACS-2685 User Manual...
  • Page 56 [Disabled] Interrupt 19 Capture: Enabled: Allows option ROMs to trap interrupt 19. [Disabled] [Enabled] Boot Device Priority: Specifies the Boot Device Priority sequence. Hard Disk Devices : Specifies the Boot Device Priority sequence from available Hard Drives. ACS-2685 User Manual...

  • Page 57: Security Settings

    Always: Check password while invoking setup a well as on each boot. Boot Sector Virus Protection: [Disabled] [Enabled] Enabled / Disabled Boot Sector Virus Protection. Type the password with up to 6 characters and then press Enter key. This will ACS-2685 User Manual...

  • Page 58: Advanced Chipset Settings

    ► North Bridge Configuration ► South Bridge Configuration ← Select Screen ↑↓ Select Item Enter Go to sub screen General Help F10 Save and Exit ESC Exit V02.61 © Copyright 1985-2006 American Mega trends , Inc. ACS-2685 User Manual...
  • Page 59 ► Video Function Configuration ESC Exit V02.61 © Copyright 1985-2006 American Mega trends , Inc. Memory Remap Feature: [Enabled] [Disabled] Memory Hole: [Disabled] [15MB-16MB] Initate Graphic Adapter: Select which graphics controller to use as the primary boot device. ACS-2685 User Manual...
  • Page 60 +- Charge option Backlight Control Level [Level 8] F1 General Help Backlight Control Mode [DC] F10 Save and Exit Backlight Image Adaptation ESC Exit [VBIOS-Default] V02.61 © Copyright 1985-2006 American Mega trends , Inc. DVMT Mode Select: ACS-2685 User Manual...
  • Page 61 [1024x768 24bit 2ch] [1280x1024 24bit 2ch] [1440x900 24bit 2ch] [1600x900 24bit 2ch] [1680x1050 24bit 2ch] [1920x1080 24bit 2ch] Backlight Control Support [VBIOS-Default] [Both BLC & BIA Disabled] [BLC Enabled] Backlight Control Control: [Level8] [Level0] [Level1] [Level2] [Level3] [Level4] ACS-2685 User Manual...
  • Page 62 Ports] 2 USB Ports USB2.0 Controller [Enabled] 4 USB Ports 6 USB Ports Keep USB Power at S5 [Enabled] 8 USB Ports Wireless Controller [Enabled] 10 USB Ports HAD Controller [Enabled] 12 USB Ports SMBUS Controller [Enabled] ACS-2685 User Manual...
  • Page 63 [2 USB Ports] [4 USB Ports] [6 USB Ports] [8 USB Ports] [10 USB Ports] USB 2.0 Controller: [Enabled] Keep USB Power at S5: [Enabled] [Disabled] Wireless Controller [Enabled] [Disabled] HDA Controller: [Enabled] [Disabled] SMBUS Controller: [Enabled] [Disabled] ACS-2685 User Manual...
  • Page 64 PCIE Port 0: [Auto] [Enabled] [Disabled] PCIE Port 1: [Auto] [Enabled] [Disabled] PCIE Port 2: [Auto] [Enabled] [Disabled] PCIE Port 3: [Auto] [Enabled] [Disabled] PCIE Port 4: [Auto] [Enabled] [Disabled] PCIE High priority Port: [Disabled] [Port 0] [Port1] [Port2] ACS-2685 User Manual...

  • Page 65: Exit Options

    ← Select Screen ↑↓ Select Item Enter Go to sub screen General Help F10 Save and Exit ESC Exit V02.61 © Copyright 1985-2006 American Mega trends , Inc. Save Changes and Exit: Save configuration changes and exit setup? ACS-2685 User Manual...
  • Page 66 F7 key can be used for this operation) [OK] [Cancel] Load Optimal Defaults: Load Optimal Defaults? F9 key can be used for this operation) [OK] [Cancel] Load FailSafe Defaults: Load FailSafe Defaults? F9 key can be used for this operation) [OK] [Cancel] ACS-2685 User Manual...

  • Page 67: Chapter 4 Installation Of Drivers

    VGA driver LAN drivers Audio driver .NET framework 3.5 driver Installation instructions are given below. Important Note: After installing your Windows operating system (Windows XP), you must install first the Intel Chipset Software Installation Utility before proceeding with the installation of drivers. ACS-2685 User Manual...

  • Page 68: Intel Chipset Driver

    4.1 Intel Chipset Driver To install the Intel chipset driver, please follow the steps below. Step 1: Select Chipset from the list Follow the step-by-step installation process to install the driver. ACS-2685 User Manual...
  • Page 69 ACS-2685 User Manual...
  • Page 70 Click Finish, when the installation process is complete, the Setup Complete screen appears. See as picture. ACS-2685 User Manual...

  • Page 71: Intel Graphics Media Accelerator Driver

    4.2 Intel Graphics Media Accelerator driver To install the VGA drivers, follow the steps below to proceed with the installation. 1. Click Intel(R) GM45 Chipset Family Graphics Driver. Follow the step-by-step installation process to install the Graphics Media Accelerator driver. ACS-2685 User Manual...
  • Page 72 ACS-2685 User Manual...
  • Page 73 ACS-2685 User Manual...
  • Page 74 Click FINISH; A Driver Installation Complete. ACS-2685 User Manual...

  • Page 75: Intel 82574L Lan Device Driver

    4.3 Intel 82574L LAN Device Driver To install the Intel R 82574L Gigabit LAN connect device driver, please follow the steps below. Select LAN from the list Follow the step-by-step installation process to install the LAN driver. ACS-2685 User Manual...
  • Page 76 ACS-2685 User Manual...
  • Page 77 Click FINISH; A Driver Installation Complete. ACS-2685 User Manual...

  • Page 78: Realtek Alc662 Hd Audio Driver Installation

    4.4 Realtek ALC662 HD Audio Driver Installation To install the Realtek High Definition (HD) Audio driver, please follow the steps below. Select Audio from the list Follow the step-by-step installation process to install the Realtek HD Audio driver. ACS-2685 User Manual...
  • Page 79 Click FINISH; A Driver Installation Complete. ACS-2685 User Manual...

  • Page 80: Microsoft .Net Framework 3.5 Service Installation

    4.5 Microsoft .NET Framework 3.5 Service Installation To install the Microsoft .NET Framework 3.5 Service, please follow the steps below. ACS-2685 User Manual...
  • Page 81 ACS-2685 User Manual...
  • Page 82 ACS-2685 User Manual...
