EPSON Stylus CX3100/3200

5.1.2 Dedicated Tools

Table 5-2 shows the dedicated tools for executing the adjustment items listed above.
Table 5-2. Dedicated Tools
No. Name Adjustment Items
1 Adjustment Program Mechanism setting
2 EFlash3.exe Firmware upload
ROM rewriting limitation
3 RMDEV. exe
invalidation program
Adjustment

5.2 Adjustment by Adjustment Program

This machinery is adjusted by using the dedicated adjustment program. Adjusted
compensation values are written into EEPROM on the Main Board.
This Program is intended to absorb the unevenness of features of individual Printer
Description / Specification
Mechanisms and ensure a satisfactory print quality. When the Printer Mechanism, Print
Dedicated program
Head or Main Board has been replaced, it is necessary to write the correct
compensation values by using this Adjustment Program.
Dedicated program
Dedicated program

5.2.1 Adjustment Program Installation

1.
2.
3.
C A U T I O N
Adjustment by Adjustment Program
Insert the floppy disk storing the Adjustment Program into the floppy disk drive.
Open the floppy disk holder and copy "Adjustment Program" onto the desk top.
Execute the Adjustment Program.
Before installing this program, make sure that the USB Driver
has been installed on the PC.
This program is exclusive for use on windows98/Me. This does
not operate on DOS or Windows3.x or NT.
Do not start the program before connecting the USB cable to
Stylus CX3100/3200.
The Adjustment Program comes with some sub files which
appear by decompressing the compressed file. Be sure to store
the sub files in the same holder where the Adjustment Program
is stored.
Revision A
59
