- Page 1 Mod. 1093 DS1093-039 4 CHANNEL VIDEO DVR H.264 Ref. 1093/064SN 8 CHANNEL VIDEO DVR H.264 Ref. 1093/065SN 16 CHANNEL VIDEO DVR H.264 Ref. 1093/066SN USER MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS General information ..........................5 Product description ........................5 1.1.1 General features ..........................5 Opening the package........................7 1.2.1 Contents of the package ........................7 Warnings ............................7 1.3.1 Power ..............................7 1.3.2 Safety precautions ..........................7 1.3.3 Installation precautions......................... - Page 3 Playing Back a Recording ........................30 Understanding the Playback Interface..................30 Playing Back from Search......................31 Playing Back from Live Preview ....................32 Playing Back from System Log....................33 Playing Back Frame-by-Frame ....................33 Using Digital Zoom........................33 Backing up Recorded Files ......................... 34 Exporting Files ...........................
- Page 4 14.2 Configuring RS-232 Port Settings....................64 14.3 Managing User Accounts......................65 14.3.1 Adding a New User ..........................65 14.3.2 Deleting a User ..........................67 14.3.3 Modifying a User ..........................68 14.4 Managing System ........................68 14.5 Updating System Firmware......................69 14.6 Restoring Default Settings ......................
-
Page 5: General Information
Dear Customer, Thank you for purchasing this product. This document describes how to install and use URMET Domus Digital Video Recorder models 1093/064SN, 1093/065SN, 1093/066SN. Read this manual which contains information for correct, safe use carefully. Keep this manual at hand so that you can refer to it when needed. - Page 6 Supports multi-level user management, each user can have individual DVR access rights. • Powerful DVR log, including operation, alarm and exception log. IMPORTANT NOTE (*) Contact an authorised Service Centre for increasing the recording capacity of 1093/064SN, 1093/065SN and 1093/066SN devices. DS1093-039...
-
Page 7: Opening The Package
OPENING THE PACKAGE Check that the packing and the contents are not visibly damaged. Contact the retailer immediately if parts are either missing or damaged. Do not attempt to use the device in this case. Send the product back in its original packing if it is damaged. -
Page 8: Hard Disk
1.3.6 IMAGE RECORDING This device was designed to record images, not as a burglar alarm. URMET Domus S.p.A. cannot be held liable for loss or damage following theft sustained by the user. Make a test recording before using the device to make sure that is working correctly. Please note that URMET Domus S.p.A. -
Page 9: Description Of The Parts
DESCRIPTION OF THE PARTS There are numerous ways to navigate and operate your DVR. You may use the Front Panel Controls, the included IR (Infra-Red) Remote, a Mouse and the Soft Keyboard. FRONT PANEL Figure 1. DVR Front Panel Controls The controls on the front panel include: USB Ports: Universal Serial Bus (USB) ports for additional devices such as USB mouse and USB Hard Disk Drive (HDD). -
Page 10: Rear Panel
DIRECTION/ENTER Buttons: DIRECTION Buttons: The DIRECTION buttons are used to navigate between different fields and items • in menus. In Playback mode, the Up and Down button is used to speed up and slow down recorded video. The Left and Right button will jump 30s backward and forward in a video. In Preview mode, these buttons can be used to cycle through channels. -
Page 11: Ir Remote Control
IR REMOTE CONTROL Figure 3. IR remote control The keys on the remote control closely resemble the ones found on the front panel. Referring to Figure 3, they include: POWER Button: Power off DVR. DEV Button: Enables/Disables Remote Control. Alphanumeric Buttons: Same as Alphanumeric buttons on front panel. EDIT Button: Same as EDIT button on front panel. -
Page 12: Mouse
MOUSE 1 - Left button 2 - Scroll wheel 3 - Right button Figure 4. mouse and control buttons (picture as indication only) A regular 3-button (Left/Right/Scroll-wheel) USB mouse can also be used with this DVR. To use a USB mouse: Plug USB mouse into one of the USB ports on the front panel of the DVR. -
Page 13: Using The Soft Keyboard
USING THE SOFT KEYBOARD When a mouse is used to perform task on the DVR, clicking on a text input field will bring up the Soft Keyboard, shown in Figure 5. Figure 5. Soft Keyboard The buttons on the soft keyboard represents: Lowercase: Designates lowercase input is being used. -
Page 14: Product Application Diagram
PRODUCT APPLICATION DIAGRAM Figure 1. Product Application Diagram DS1093-039... -
Page 15: General Settings
GENERAL SETTINGS Proper startup and shutdown procedures are crucial to expanding the life of your DVR. SWITCH-ON To startup your DVR: Ensure the power supply is plugged into an electrical outlet. It is HIGHLY recommended that an Uninterruptible Power Supply (UPS) be used in conjunction with the unit. Turn on the switch on rear panel After startup, the Status indicator LED will remain green. -
Page 16: Rebooting And Locking Your Dvr
REBOOTING AND LOCKING YOUR DVR While in the Shutdown menu (Figure 1), you may also reboot or lock your DVR. Locking your DVR will return you to the Live Preview mode, which will require an user name and password to exit out of it. The Reboot button will reboot your DVR. - Page 17 Navigate to the Admin Password input field. Enter the admin password into the Admin Password input field. By default, the password is 12345. To change the admin password, check the New Admin Password checkbox. Enter the new password and confirm the password in the given fields. Click the Next button.
- Page 18 Select the Schedule tab, shown in Figure 6. Figure 6. Schedule Settings Click the Edit button. This will open up a new recording schedule, shown in Figure 7. Check both the Enable Schedule and All Day checkbox. This will enable the recording schedule and have it record continuously all day.
-
Page 19: Setting Date & Time
To configure network settings, click the Enter button. Enter the IP Address, Subnet Mask and Default Gateway. Click the OK button to return to the Setup Wizard. If all the settings are entered as desired, click the Done button to finish and exit the Setup Wizard. Congratulations! You’ve completed the Setup Wizard. -
Page 20: Watching A Live Preview
WATCHING A LIVE PREVIEW The Live Preview mode is automatically started after the DVR boots up. It is also at the very top of the menu hierarchy, thus hitting the ESC multiple times (depending on which menu you’re on) will bring you to the Live Preview mode. UNDERSTANDING LIVE PREVIEW ICONS There are multiple icons on each display in Live Preview mode to indicate different camera status. -
Page 21: Using The Mouse In Live Preview
USING THE MOUSE IN LIVE PREVIEW Many features of the Live Preview can be quickly accessed by clicking the right-button of the mouse (shown in Figure 2). These features include: • Single Camera: Switch to a full screen display of the selected camera. Camera can be selected from a drop down list. -
Page 22: Configuring Live Preview Displays
CONFIGURING LIVE PREVIEW DISPLAYS Live Preview displays can be customized to your own needs. These settings can be accessed by entering the Display Settings menu. Figure 4. Display Settings Note: Spot out only has a window division. To access the Display Settings menu: Click the MENU button. -
Page 23: Setting Camera Order
SETTING CAMERA ORDER Setting the camera order allows you to logically position cameras for more efficient monitoring of your own individual location. Note: Spot out only has one window division Figure 5. Camera Order Setting To set the camera order: Enter the Display Settings menu, shown in Figure 5 (Menu >... -
Page 24: Configuring Settings For Recording
CONFIGURING SETTINGS FOR RECORDING There are multiple ways to setup your DVR for recording. They include setting up a recording schedule, triggering a recording by motion detection and/or a sensor alarm, and manually starting the recording. INITIALIZING RECORD SETTINGS Before setting your DVR up for recording, certain settings should be configured first. The steps to configuring these settings are: If you have not initialized a HDD either through the Setup Wizard or through HDD management, you must do so before proceeding. -
Page 25: Scheduling A Recording
Set additional record settings: • Pre-Record: Sets the time in seconds to pre-record before the actual recording begins. • Post-Record: Sets the time in seconds to post-record after the actual recording has ended. • Recording Expired Time: Sets the expiration time in days for recorded video. Recordings after expiration time would be deleted. -
Page 26: Starting A Manual Recording
Select recording Type. Recording type can be based on time and triggered by motion detection and/or alarm. Motion detected and alarm triggered recordings are further explained in Configuring Alarms. Click the OK button to finish configuration. 10. Repeat steps 3-9 for other cameras or copy settings from one schedule to the next under the Copy To section. -
Page 27: Setting Hdd To Read-Only
Search for desired recording by entering search parameters. Search parameters include Camera #, Video/File Type, and Start/End Time. Click the Search button. A list of recordings (similar to Figure 7), matching the search parameters will be displayed. Select the file you would like to lock/unlock. Click on the Lock button to lock file. -
Page 28: Configuring Advanced Hdd Settings
Click the Property button. This will take you to the Property Settings menu, shown in Figure 9. Figure 9. HDD Property Settings Menu 5. Set HDD to Read-Only. 6. Click the OK button. The HDD is now read-only. Note: When a HDD is set to read-only, no more recordings can be written to the disk. In order to enable recordings on that particular disk again, you must set the HDD to R/W (Read/ Write) in the HDD Property Settings menu. - Page 29 Click the OK button to save settings and return to the previous menu. Figure 11. HDD Property Settings Navigate to the Record Settings menu by clicking Menu > Setting > Record Setting. Click on the General tab. Select the Camera to be used for redundancy. Next to More Settings, click on the Set button.
-
Page 30: Playing Back A Recording
PLAYING BACK A RECORDING You must first search for recordings to play them back. There are multiple ways to search for recordings, including searching for them by time, by channel, by file type and by log. UNDERSTANDING THE PLAYBACK INTERFACE There are various controls on the Playback interface that makes viewing recordings more efficient. -
Page 31: Playing Back From Search
PLAYING BACK FROM SEARCH To playback files from a video search: Enter into the Video Search menu by clicking Menu > Video Search. Set the search parameters by selecting cameras to search, video/file type and the start/end time (as shown in Figure 3). Figure 3. -
Page 32: Playing Back From Live Preview
Play button to view the day’s recording for the selected channel. You may also select additional channels (1093/064SN supports up to 4-ch, 1093/065SN supports up to 8-ch, 1093/066SN supports up to 16-ch) for playback from the channel list on the right hand side of the Playback interface, as shown in Figure 5. -
Page 33: Playing Back From System Log
PLAYING BACK FROM SYSTEM LOG You may also playback recordings from the System Log. To playback video from the System Log: Enter the Log Search menu by clicking Menu > Maintenance > Log Search (shown in Figure 6). Figure 6. Log Search Menu Set Major Type setting to Information. -
Page 34: Backing Up Recorded Files
BACKING UP RECORDED FILES Recorded files can be backed up to various devices, such as USB flash drives, USB HDDs or a DVD writer. EXPORTING FILES To export recorded files: Enter the Export Video menu (shown in Figure 1) by clicking Menu > Video Export. Figure 1. - Page 35 Select device to export to from drop-down list (USB Flash Drive, USB HDD, DVD Writer). If backup device is not recognized: • Click the Refresh button. • Reconnect device. • Check for compatibility from vendor. Click Start to begin backup process, shown in Figure 4. Figure 4.
-
Page 36: Exporting Video Clips
EXPORTING VIDEO CLIPS You may also select video clips to export directly during Playback. A maximum of 30 clips can be selected for each channel. To export video clips during Playback: • Using the Mouse: Enter into the Playback interface (See Playing Back a Recording). Using the Clip Start/Stop button in the Playback Control Panel, select the start and end of the video clip during playback. -
Page 37: Configuring Alarms
CONFIGURING ALARMS SETTING UP MOTION DETECTION Set up properly, using motion detected recording will increase the number of days your DVR is able to record. It will only record relevant events rather than recording everything, making searching for an event easier. To set up motion detection: Enter Camera Setting: Enter the Camera Settings interface by navigating to Menu >... - Page 38 Set the Motion Detection Sensitivity, shown in Figure 3. The higher the sensitivity value, the higher the sensitivity. Figure 3. Motion Sensitivity Setting Click OK to return to the Camera Settings menu. Click the Handle button to open the Exception Handle menu, shown in Figure 4. Select the Triggered Camera tab Figure 4.
-
Page 39: Setting Up Sensor Alarms
SETTING UP SENSOR ALARMS Recordings can also be triggered from an external sensor alarm device. To setup sensor alarms: Enter into the Alarm Management menu by navigating to Menu > Setting > Alarm, shown in Figure 5. Figure 5. Alarm Management Menu Select the Alarm Input # and click the Set button. - Page 40 Select cameras to trigger for recording when alarm occurs by checking the checkboxes under the desired cameras, as shown in Figure 7. Figure 7. Triggered Cameras Menu Click the OK button to complete setup. You may now add a schedule to start recording when an alarm is triggered (See Scheduling a Recording). Alarm outputs may also be configured in the Alarm Management menu.
-
Page 41: Triggering Alarm Outputs Manually
Select the output you would like to configure and click the Set button. This will bring up the settings page for the selected channel (Figure 9). Figure 9. Alarm Output Settings Configure the settings for selected output. Select OK to save and exit. Note: If the Hold For option is selected as Manually Stop, the alarm will only stop when you manually stop it (See Triggering Alarm Outputs Manually). -
Page 42: Detecting Video Loss
DETECTING VIDEO LOSS Your DVR can be setup to detect video loss and trigger an action. To setup video loss detection: Enter Camera Settings menu by clicking Menu > Setting > Camera. Select camera under Channel # to configure video loss detection for and click the Set button. Select the Advanced tab. -
Page 43: Detecting Video Tampering
DETECTING VIDEO TAMPERING Video tampering (i.e. moving camera to a different position) can also be detected and set to trigger an action on your DVR. To setup video tempering detection: Enter Camera Management/Settings menu by clicking Menu > Setting > Camera. Select camera under Channel # to configure video loss detection for and click the Set button. -
Page 44: Setting Exception
Click the Handle button to enter the Exception Handle menu, shown in Figure 15. 10. Select the Handle tab to configure exceptions handling. Exception trigger options are further explained in the next section (See Understanding Exception Trigger Options). Figure 15. Exception Handle Menu 11. -
Page 45: Understanding Exception Trigger Options
9.6.1 UNDERSTANDING EXCEPTION TRIGGER OPTIONS When setting up exception handlers for such features as motion detection and sensor alarms, you may select triggering options to alert you of these exceptions. The triggering options that you may select include: • Pop-up Image on Monitor: When an alarm is triggered, the local monitor (VGA or BNC monitor) will display an image under Live Preview mode. -
Page 46: Configuring Network Settings
10 CONFIGURING NETWORK SETTINGS Network settings must be configured before you’re able to use your DVR over the network. 10.1 CONFIGURING BASIC SETTINGS To configure basic network settings: Enter the Network Settings menu, shown in Figure 1 by clicking Menu > Setting > Network. Figure 1. -
Page 47: Configuring Pppoe Settings
10.2 CONFIGURING PPPOE SETTINGS Your DVR also allows for Point-to-Point Protocol over Ethernet (PPPoE) access. To set up PPPoE access: Enter the Network Settings menu by clicking Menu > Setting > Network. Select the General tab. Set the IP address and subnet mask to 0, as shown in Figure 3. When the PPPoE connection is successfully established, the IP address will be added automatically. -
Page 48: Configuring Ddns
Click the Set button next to PPPoE to enter PPPoE settings menu, shown in Figure 5. Figure 5. PPPoE Settings Check the PPPoE checkbox to enable feature. Enter User Name, Password, and Confirm Password for PPPoE access. PPPoE credentials can be obtained from your network administrator. -
Page 49: Configuring An Ntp Server
Select DDNS Type. There are three different DDNS type to choose from, IpServer, PeanutHull and DynDNS. • IpServer: Enter Server Address for IpServer. • PeanutHull: Enter User Name and Password obtained from the PeanutHull website (Figure 6). • DynDNS: Enter Server Address for DynDNS (i.e. members.dyndns.org) (Figure 7). Under DVR Domain Name, enter the domain obtained from the DynDNS web site. -
Page 50: Configuring A Remote Alarm Host
10.5 CONFIGURING A REMOTE ALARM HOST With a remote alarm host set, the DVR will send a signal to the host when an alarm is triggered. The remote alarm host must have the Network Video Surveillance software installed. To set up a remote alarm host: Enter Network settings menu by clicking Menu >... -
Page 51: Configuring Server And Http Ports
10.7 CONFIGURING SERVER AND HTTP PORTS If you would like to change the server and HTTP ports from the default settings, you can do so in the Network Settings menu. The default server port is 8000 while the default HTTP port is 80. To change the default ports: Enter the Network Settings menu by clicking Menu >... -
Page 52: Ptz Controls
11 PTZ CONTROLS 11.1 NAVIGATING PTZ MENUS PTZ menus can be navigated through with either the mouse or the front panel/remote. For quick access to certain PTZ settings, right clicking with the mouse in a display while in PTZ control mode will bring up the PTZ settings menu. This menu is shown in Figure Figure 1. -
Page 53: Configuring Ptz Settings
11.2 CONFIGURING PTZ SETTINGS Settings for a PTZ camera must be configured before it can be used. Before proceeding, verify that the PTZ and RS-485 of the DVR are connected properly. To configure PTZ settings: Enter the PTZ Settings menu by clicking Menu > Setting > PTZ. The PTZ Settings menu is shown in Figure 2. -
Page 54: Customizing Presets
11.3.2 CUSTOMIZING PRESETS Presets can be set to move your PTZ camera to a desired preset location at the click of a button. To setup and use custom PTZ presets: Enter the PTZ Control interface, shown in Figure 3 by clicking PTZ in the mouse menu or the PTZ button on the front panel. - Page 55 In the Patrol Management menu, you may: • Configure Patrol: Select a Patrol Number to set. Select valid presets (See Customizing Presets) and click the Set button to enter the Patrol configuration menu. A sequence should have at least 2 valid presets. Set the Key Point No., Duration, and Speed (Figure 6).
-
Page 56: Customizing Patterns
11.3.4 CUSTOMIZING PATTERNS Patterns can be setup by recording the movement of the PTZ. To setup and use PTZ patterns: Enter the PTZ Control interface, shown in Figure 3 by clicking PTZ in the mouse menu or the PTZ button on the front panel. -
Page 57: Camera Management
12 CAMERA MANAGEMENT 12.1 CONFIGURING OSD SETTINGS On Screen Display (OSD) settings can be configured in the Camera Management menu. The OSD is shown in each display during Live Preview mode and includes the time and date as well as the camera name. To configure OSD settings: Enter the Camera Management/Settings menu, shown in Figure 1 by clicking Menu >... -
Page 58: Adjusting Display Settings
Check the Mask checkbox to enable feature. Click the Area Settings button to enter Area Settings menu. Setup mask area, as shown in Figure 3. Up to 4 areas can be set. Figure 3. Setting Mask Area Select OK to save and exit mask setup. 12.3 ADJUSTING DISPLAY SETTINGS Display settings such as the brightness, contrast, saturation and hue can also be adjusted in the Camera Management menu. -
Page 59: Managing Hdds
13 MANAGING HDDS 13.1 INITIALIZING HDDS A newly installed hard disk drive (HDD) must be first initialize before it can be used with your DVR. Initializing the HDD will erase all data on it. To initialize a HDD: Enter the HDD Management menu, shown in Figure 1 by clicking Menu > HDD. Figure 1. -
Page 60: Setting Hdd Status
13.3 SETTING HDD STATUS You may change the behavior of your HDD by changing its status. The status of a HDD can be set to redundancy, read-only or read/write (R/W). 13.3.1 SETTING HDD TO READ-ONLY A HDD can be set to read-only to avoid important recorded files from being overwritten when the HDD becomes full. To set a HDD to read-only: Enter the HDD Management menu by clicking Menu >... -
Page 61: Checking Hdd Status
13.4 CHECKING HDD STATUS You may check the status of any of the installed HDDs on your DVR at anytime. To check the status of a HDD: 1. Enter the HDD Management menu by clicking Menu > HDD. 2. The status of your HDD is listed under the Status column. If the status is listed as Normal or Hibernate, the HDD is in working order. -
Page 62: Configuring Hdd Alarms
6. Select log item to view and click the Details button. A detail listing of SMART information, as shown in Figure 6 will be displayed. Figure 6. SMART Information 13.5 CONFIGURING HDD ALARMS HDD alarms can be set to trigger when an HDD is uninitialized or in an abnormal state. To set HDD alarms: Enter Exception menu, shown in Figure 7 by clicking Menu >... -
Page 63: Dvr Management
14 DVR MANAGEMENT 14.1 CONFIGURING GENERAL SETTINGS General settings such as the system language can be configured in the General Settings menu of your DVR. To configure general settings: Enter the General Settings menu, shown in Figure 1 by clicking Menu > Setting > General. Figure 1. -
Page 64: Configuring Rs-232 Port Settings
Configure settings, including: • Device Name: Name to use for DVR. • Device No.: Device number to use for DVR. • CVBS Output Brightness: Video output brightness. • Transparency: Menu transparency. • Operation Timeout: Set timeout time for menu inactivity. For example, if timeout time was set to 5 minutes, after 5 minutes of inactivity in the General Settings menu, you’ll be returned to the Live Preview. -
Page 65: Managing User Accounts
14.3 MANAGING USER ACCOUNTS By default, your DVR comes with one user account, the Administrator account. The Administrator user name is admin and the password is 12345. The default password for Administrator should be changed right away for security reasons. The Administrator has the authority to add, delete or configure parameters for many of the system functions. - Page 66 Select the Permission button to enter the Privilege Settings menu, shown in Figure 6. Figure 6. Privilege Settings Menu Configure privileges for local settings under Local Permission tab. The local settings include: • Local Log Search: Search and view logs of DVR. •...
-
Page 67: Deleting A User
Click on the Channel Permission tab to configure channel privileges, as shown in Figure 8. The channel settings include: Figure 8. Channel Privileges Menu • Remote Live View: Select and view live video over the network. • Local Manual Record: Locally start and stop manual recording on any of the channels. •... -
Page 68: Managing System
14.3.3 MODIFYING A USER To modify a user: Enter the User Settings menu by clicking Menu > Settings > User. Select user to modify. Click the Modify button to enter the Modify menu, shown in Figure 9. Figure 9. Modify User Menu Edit user information. -
Page 69: Updating System Firmware
14.5 UPDATING SYSTEM FIRMWARE The firmware on your DVR can be updated using two methods. These methods include updating via an USB device or over the network via a FTP server. To update via an USB device: Connect USB device to DVR. The firmware file must be located in the root directory of your USB device. Enter the Firmware Update menu, shown in Figure 11 by clicking Menu >... -
Page 70: Restoring Default Settings
14.6 RESTORING DEFAULT SETTINGS To restore default factory settings to your DVR: Enter the Default Settings menu, shown in Figure 13 by clicking Menu > Maintenance > Default. Figure 13. Default Settings Menu Select OK to restore factory defaults. Note: Network information such as IP address, subnet mask and gateway will not be restored. -
Page 71: Viewing System Logs
14.8 VIEWING SYSTEM LOGS Many events of your DVR are logged into the system logs. To access the system logs and search for these events: Enter the Log Search menu, shown in Figure 15 by clicking Menu > Maintenance > Log Search. Figure 15. - Page 72 Log files can also be exported onto a USB device. To export a log file, connect a USB device to the DVR, select the log file to export and click the Export button. This will take you to the Log Search Export menu, shown below in Figure 17.
-
Page 73: Specifications (Pal Format)
15 SPECIFICATIONS (PAL FORMAT) Specifications Item 1093/064SN 1093/065SN 1093/066SN Triplex digital video recorder with network Product type H.264 Compression algorithm PAL (compatible with black and white cameras) Video standard H 15625 Hz / V 50 Hz Image preview 704 x 576 resolution “4CIF”, “2CIF”, ”CIF”, “QCIF”... - Page 74 External alarm inputs Relay output Max. n. of unicast ** network connections (TCP,UDP,RTP) Motion detector Event Encoding VoIP Watermark Yes (full USB control: add – rename – delete – play video) USB port control Digital Zoom Live and playback Network protocols TCP/UDP/RTP/MULTICAST and NTP supported Local redundant...
-
Page 75: Glossary
16 GLOSSARY • Dual Stream: Dual stream is a technology used to record high resolution video locally while transmitting a lower resolution stream over the network. The two streams are generated by the DVR, with the main stream having a maximum resolution of 4CIF and the sub-stream having a maximum resolution of QCIF. •... -
Page 76: Faq
There’s a chance that the DVR and your USB device is not compatible. Please refer to our company’s website to view a list of compatible devices. Prodotto in Cina su specifica URMET Domus DS1093-039 Made in China to URMET Domus specification...
