Table scales – WTC series
MANUFACTURER OF ELECTRONIC WEIGHING INSTRUMENTS
RADWAG 26 – 600 Bracka 28 street, POLAND
Radom, phone +48483848 800, phone/fax +4848 385 00 10,
Sales department +4848 366 80 06
www.radwag.com
MAY 2007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WTC series and is the answer not in the manual?

Questions and answers

Summary of Contents for RADWAG WTC series

  • Page 1: User Manual

    User Manual Table scales – WTC series MANUFACTURER OF ELECTRONIC WEIGHING INSTRUMENTS RADWAG 26 – 600 Bracka 28 street, POLAND Radom, phone +48483848 800, phone/fax +4848 385 00 10, Sales department +4848 366 80 06 www.radwag.com MAY 2007...
  • Page 2: Table Of Contents

    Content 1. MAIN FUNCTIONS..................3 2. STRUCTURE..................... 4 2.1. Montage drawings ....................4 2.2. Display window overlay ..................4 2.3. Indicators and pictograms ...................5 3. KEYS ......................5 4. PREPARATION TO WORK ..............6 4.1. Switching on ......................6 4.2. Zeroing ........................6 4.3. Tarring.........................7 4.4.
  • Page 3: Main Functions

    1. MAIN FUNCTIONS • Zeroing after switch on • Tare in whole measuring range • Autozero • Filter setting • Change of measuring unit • Battery save mode (LED) • Low battery indication. • Backlight operation • Auto-switch off • Simple calibration •...
  • Page 4: Structure

    2. STRUCTURE 2.1. Montage drawings 1 – Weighing pan 2 – Operator display 3 – Cover layer 4 – Level 5 – Panel 6 – Load cell casing 7 – Printed PCB 8 – Base 9 – Battery 10 – Battery casing 11 –...
  • Page 5: Indicators And Pictograms

    2.3. Indicators and pictograms Indicator Description Mass within ±0.25e → 0 ← Power supply from A/C current Low battery Measuring unit – pounds Measuring unit – kilograms Auto Off Auto-switch off started Backlight switched on Stable measurement Gross mass Net mass Pictogram Description Tare applied...
  • Page 6: Preparation To Work

    B. Button OFF - Switches off power supply - Changes options in setting - Change of digit value on each place C. Button ZERO - Zeroing - Used while calibration process - Switching off backlight function D. Button TARE - Tarring - Used while calibration process 4.
  • Page 7: Tarring

    4.3. Tarring Pressing button TARE, will cause appearance of „0” on the display. Additionally, marker „N” or pictogram „T” will be displayed. Another pressing of TARE button, will cancel tare value, and above mentioned indications and pictograms will no longer be lit.
  • Page 8: Backlight

    Setting overloading alarm. Maximal value is set as (max + 9e). for scales with maximal capacity 6kg and resolution e=1g, value of overloading alarm equals 6.009kg. Exceeding this value causes displaying of „FULL” indication on the display and beep sound. Caution: Even if F8=0 (beep signal from keyboard) beep signal on exceeding maximal capacity will not be heard.
  • Page 9: Inserting Digits

    4.10. Inserting digits When inserting warning levels or while calibration, digits are inserted by buttons „ ” and „ ”. Way of inserting digits: - Press button „OFF” in order to move to edit mode (last digit starts flashing). - Press button „ON”, in order to choose digit for change setting . - pressing button „OFF”, scroll through accessible digits 0 1 2 3 4 5 6 7 8 9 0.
  • Page 10: User Recommendations

    6. USER RECOMMENDATIONS Scale should be placed on tough surface. It should not be used in dusted area with big vibrations while weighing please place the load on the central part of the weighing pan. Do not use chemical agents causing corrosion do not weigh loads which mass exceeds maximal scale capacity (including tare value) do not overload the weighing pan.
  • Page 11 O F E L E C T R O N I C W E I G H I N G I N S T R U M E N T S ZAKŁAD MECHANIKI PRECYZYJNEJ ,,RADWAG” 26 – 600 Radom, ul. Bracka 28 POLAND +48 48 38 48 800, phone./fax.

This manual is also suitable for:

Wtc/f 6Wtc/f 15Wtc/f 30
