Summary of Contents for Winmate M700D
-
Page 1: User Guide
Winmate M700D Tablet PC Windows 8 User Guide Version 1.00 Revision A May 2013... -
Page 2: Table Of Contents
Safety Precautions ....................5 Battery Safety Information ..................5 Electrostatic Discharge ..................5 Driving ........................5 Chapter 2: About Winmate M700D Tablet PC About M700D ....................... 6 Features ....................... 6 Getting started ....................... 7 SIM Card and SD Card Installation ..............8 Secondary Battery Installation ................. - Page 3 Charging Approaches ..................22 Checking the battery level ................22 Battery low signals and actions..............22 Power Management .................... 23 Chapter 6: Expanding M700D Tablet PC Connecting to USB device................... 24 Connecting to Audio device ................. 24 Chapter 7: Using BIOS Setup To use BIOS setup .....................
- Page 4 Winmate M700D Tablet PC User Guide Chapter 9: Using the Camera Open Camera ..................... 31 Take a Picture ..................... 31 Shoot a Video...................... 31 Camera Control Buttons ..................31 Chapter 10: Accessories M700D Standard Accessories ................32 M700D Optional Accessories ................32...
-
Page 5: Chapter 1: Safety Information
User Guide Chapter 1: Safety Information Exposure to Radio Use M700D series is equipped with Bluetooth, WI-Fi and Cellular modem radio. In some situation or area, user may be required to turn off the radios. For example; User’s needs to turn the phone OFF when in an area posted “TURN OFF RADIO SIGNAL.”... -
Page 6: Safety Precautions
If battery fluid leaks onto the skin or cloth, wash the affected area with clean water Please contact your current Winmate distributor or local Winmate vendor if you suspect damage to your Tablet PC or battery for inspection and reparation. -
Page 7: Chapter 2: About Winmate M700D Tablet Pc
1024 x 600 pixel TFT LCD display resolution. Other new era tech includes Built-in WLAN 802.11 2.4GHz a/b/g/n, Bluetooth 2.1+EDR, built-in Neo-6 GPS module, and optional 3G Module. Features This section provides the features of the M700D and describes how to set this device for the first time... -
Page 8: Getting Started
To take photo or video LED Auxiliary Light To provide lighting while using the camera Battery Port For secondary battery Getting started To start using the M700D for the first time: Install SIM Card and SD Card Secondary battery installation ... -
Page 9: Sim Card And Sd Card Installation
Sim Card and SD Card Installation To Install the SIM Card and SD Card: 1. Place the M700D facing up and then locate the protective rubber bumper 2. Open the protective rubbed bumper 3. Locate the SD and SIM Card as follows 4. - Page 10 Winmate M700D Tablet PC User Guide 3. Secure the secondary by screw it within 4 points (marked in red) To remove the Secondary battery: 1. Unscrew the battery from the back side of the device 2. Push it upwards 3. Remove the secondary battery from the device...
-
Page 11: Battery Charging
Please charge the battery before using the Tablet PC for the first time, charge the battery until the LED indicator turns solid green. To charge the M700D, use a cable or a docking with appropriate power supply. For more information about Power management, see chapter xxx. -
Page 12: Turning The M700D Off
Winmate M700D Tablet PC User Guide 3. Press and hold the power button for 3 seconds, located on the right side of the unit Turning the M700D Off 1. To turn off the device, select the “shut down” command from the Windows operating system. -
Page 13: Chapter 3: Operating M700D Tablet Pc
Winmate M700D Tablet PC User Guide Chapter 3: Operating M700D Tablet PC Using the Touch Screen To gain full access of the Windows interface is by using your finger to manipulate icons, on screen keyboard, menu items, and other items on the touch screen. -
Page 14: Using Input Panel
Winmate M700D Tablet PC User Guide Using Input Panel Tablet PC Input panel is an accessory included in Microsoft Windows that allows input of text using stylus, touch screen, on screen soft keyboard or mouse. User can access Tablet PC... -
Page 15: Adjust Input Panel Size
Winmate M700D Tablet PC User Guide 1. Place user tablet pen on the title bar and drag Input Panel to the location of your choice To move input panel when it is closed: 1. Place user tablet pen on the Input Panel tab, and move it up or down along the edge of the screen. -
Page 16: Hot Tab Hotkeys Function
Short Cut User can create shortcuts for some of favorite apps on M700D: 1. Tap on the right corner of the Home Screen to access Winmate Hot Tab button 2. Tap and then select 3. In this example, we try to assign first short cut button to Notepad. After assigned Notepad in the short cut button user can see the notepad icon in the short cut button. -
Page 17: Rotation
Winmate M700D Tablet PC User Guide b. Rotation By default, M700D screen automatically changes it is orientation from landscape to portrait mode depending on the way user hold the tablet. To disable auto rotation: 1. Tap and then tap to disable it. Orange color means Auto rotate is enable and white color means disable. - Page 18 1 and 2 battery life capacity. Performance User can adjust the performance level of their M700D whether it is LOW, MID or HIGH Brightness Tap Brightness to show current brightness. Drag by touch left part to reduce the brightness and drag by touch right part to enhance brightness.
-
Page 19: Chapter 4: Connecting To Network And Devices Connecting To Bluetooth Device
Connecting to Bluetooth Devices Using Bluetooth Feature M700D is equipped with Bluetooth 2.1 + EDR module for default function of the Tablet PC series. Depending on the application, Bluetooth module can give user capability for short range wireless communications between devices without requiring a cable connection. -
Page 20: Disconnect From Bluetooth Device
1. Tap the device in the Bluetooth settings screen 2. Tap Unpair Connecting to Wi-Fi To connect to Wi-Fi: 1. Launch Winmate Hot Tab menu by tapping MENU button. Select Device Activate the WiFi button 2. Please use the default Windows Wireless Network Connection utility Using 3G Function 1. - Page 21 Winmate M700D Tablet PC User Guide 3. Confirm whether to detect the telecommunications system operators and then press connect to connect to 3G network...
-
Page 22: Chapter 5: Power Management
Charging Status The battery LED Indicator indicates the charging status, M700D charges one battery pack at a time. After the first battery is fully charged, it charges the secondary battery pack. Charging the Battery Pack The battery Pack is the internal power source for the Tablet PC. -
Page 23: Charging Approaches
Winmate M700D Tablet PC User Guide To prevent damage, the charging process may stop and the battery charge indicator will flash red light when the environmental temperature exceed C (131 Charging Approaches By connecting the AC adapter to the Tablet PC and an electrical outlet, the battery charge indicator on the tablet PC will turn orange to indicate the charging is in progress. -
Page 24: Power Management
Power Management M700D Tablet PC supports ACPI (Advance configuration and Power Interface) for power management. The power management features allows user to reduce the power consumption for energy saving. With and ACPI-compliant operating system such as Windows XP, power supply to different Tablet PC components is controlled on an as-needed basis. -
Page 25: Chapter 6: Expanding M700D Tablet Pc
Chapter 6: Expanding M700D Tablet PC Connecting USB Device M700D has USB ports for connecting USB devices such as a flash disk drive, scanner, printer, keyboard, or mouse. To connect USB device, plug the device cable into USB port of M700D. -
Page 26: Chapter 7: Using Bios Setup
Chapter 7: Using BIOS Setup To use BIOS setup To enter the Tablet PC BIOS setup, user need to connect M700D with an external keyboard. Press “Del” key when the prompt appears on the screen during start up. The prompt screen shows only few seconds so user need to press “Del”... -
Page 27: Advance Menu
Winmate M700D Tablet PC User Guide Advance Menu Advanced menu consists of the selection of PXE OpROM and Watch Dog Timer, settings of PCI Subsystem, ACPI, and S5 RTC Wake. It also consists of the configuration information of CPU, Thermal, IDE/SATA, USB, and PPM Configuration. -
Page 28: Security Menu
Winmate M700D Tablet PC User Guide Security Menu In the security menu, users can set Administrator password, User password, and HDD security configuration. Save and Exit Menu The Exit menu displays ways of existing BIOS Setup utility. After finishing with the settings,... - Page 29 Winmate M700D Tablet PC User Guide Save & Exit options Function Save changes and Exit Saves the changes and exit BIOS setup utility Discard changes and Exit Exit BIOS setup utility without saving the changes Save Changes and Reset Saves the changes and reset BIOS system...
-
Page 30: Chapter 8: Using Recovery Dvd Hardware Preparation
Connect the USB Hub to M700D’s USB port Make sure the DVD-ROM driver has been recognized by the M700D tablet. Start to recover the system by recovery DVD To recover the system: 1. Reboot the tablet, then press ”Del” key on the keyboard to get into the BIOS setup mode 2. -
Page 31: Chapter 9: Using The Camera
Winmate M700D Tablet PC User Guide Chapter 9: Using Camera Winmate M700D is equipped with 2 MP on the rear side, which user can use to capture photos or video Open Camera 1. Launch Winmate Hot Tab menu by tapping MENU button. Select Device Activate the Camera button 2. -
Page 32: Camera Control Buttons
Winmate M700D Tablet PC User Guide 4. Tap the icon again to stop shooting The Camera Control Buttons Icon Description To select the save location of the Picture and Video To select the Picture Quality [ Low, Medium, High, or Best]... -
Page 33: Chapter 10: Accessories
Adapter with Standard Power Cord Input : AC 100-240V 50/60 Hz (Euro / US standard type, 1.8 m) Output : 12V DC M700D Manual & Driver CD Allows user to make an update Recovery CD Allows users to make a recovery M700D Optional Accessories...
