- Page 1 M133K Ultra-Rugged Windows Tablet Gen. Intel® Core™ i5-7200U Kaby Lake, 2.5 GHz (up to 3.1 GHz) Windows® 10 IoT Enterprise Quick Start Guide Version 1.1 Document Part No. 9152111K101V Please read these instructions carefully before using this product, and save this manual for future use.
-
Page 2: Table Of Contents
M133K Ultra-Rugged Tablet Quick Start Guide Contents Chapter 1: Read Me First 1.1 Advisory Conventions 1.2 Safety Information 1.3 Handling and Maintenance Chapter 2: Getting Started 2.1 Unpacking 2.2 Description of Parts Docking Connector Detail: 2.3 Combination Keys (Keyboard Key Emulation) Chapter 3: First-time Operation 3.1 Inserting SIM card 3.2 Inserting Battery Pack... -
Page 3: Chapter 1: Read Me First
Chapter 1: Read Me First Chapter 1: Read Me First 1.1 Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. Note: A note is used to emphasize helpful information Important:... -
Page 4: Safety Information
M133K Ultra-Rugged Tablet Quick Start Guide 1.2 Safety Information Precaution on Battery Pack Do Not Expose the Battery Pack to Excessive Précaution avec le bloc-pile Heat, or Extreme Heat (Near Fire, in Direct Sunlight for example) Generation of heat, ignition or rupture may result [FR] Ne pas exposer le bloc-pile à... - Page 5 Chapter 1: Read Me First General Product Safety Sécurité générale des produits Do not block any ventilation openings. Do not Use only with its transport carriage, stand, place the product against a wall or in an tripod, console or table specified by the enclosed space as doing so might impede the manufacturer or sold with the product.
-
Page 6: Handling And Maintenance
M133K Ultra-Rugged Tablet Quick Start Guide 1.3 Handling and Maintenance Gently wipe the display with a soft, lint-free cloth. Do not use alcohol or detergent on the product. General Guideline [FR] Essuyer délicatement l'écran avec un Guide Général chiffon doux non pelucheux. Ne pas utiliser d'alcool ou un détergent sur le produit. -
Page 7: Chapter 2: Getting Started
Chapter 2: Getting Started Chapter 2: Getting Started Congratulations on purchasing Winmate® M133K Ultra-Rugged Tablet Computer. The rugged design allows you to use it in harsh outdoor environments. This quick start guide tells you step by step how to get the Tablet Computer up and running. -
Page 8: Description Of Parts
M133K Ultra-Rugged Tablet Quick Start Guide 2.2 Description of Parts Item Description Light Sensor Controls screen brightness. Front Camera 2 Megapixel webcam. Microphone Digital microphones. Speakers Emit sounds. Power Button Turns on/off tablet computer. LED Indicators: Show the current status of the tablet computer. Green –... -
Page 9: Docking Connector Detail
Chapter 2: Getting Started Item Description SD Card Slot Memory card reader port for SD card. Audio Jack Headset or headphone can be connected (Mic is only supported with 3.5mm 4-pin headset). USB Type-C Connector USB Type-C connector to connect to external devices. Note: The USB Type-C connector follows USB 3.0 standard, which does not support Alternate Mode (ALT) or USB Power Delivery (USB-PD). -
Page 10: Chapter 3: First-Time Operation
M133K Ultra-Rugged Tablet Quick Start Guide Chapter 3: First-time Operation 3.1 Inserting SIM card Notice that 3G/LTE is an optional feature and may not be present in your device. The Tablet Computer supports data connection using 3G/LTE SIM cards and fits a Micro-SIM card (Note: 3G/LTE feature is optional). -
Page 11: Using Hot Swappable Battery Feature
Chapter 3: First-time Operation To remove the battery pack: 1. Shut down the tablet computer (or put it to sleep). Disconnect any cords connected to the tablet. 2. Turn the tablet computer over, back facing up. 3. Locate the Battery Lock Latch and push it to the “Unlocked” position. 4. -
Page 12: Kickstand Installation
M133K Ultra-Rugged Tablet Quick Start Guide 3.5 Kickstand Installation Perform the following to install a kickstand: 1. Turn the tablet computer over, so the back of the device is facing up. 2. Place the kickstand bracket with the screw holes in a line. (as the picture above) 3. -
Page 13: Chapter 4: Using Hottab Utility
Chapter 4: Using Hottab Utility Chapter 4: Using Hottab Utility 4.1 Hottab Utility Introduction Hottab provides quick access to the tablet’s functions and features, such as setting up powering on/off built-in devices, programming function key. As operating system starts up, Hottab starts and runs in the background. -
Page 14: Changing Touch Mode
M133K Ultra-Rugged Tablet Quick Start Guide 4.2 Changing Touch Mode The M133K ultra-rugged tablet supports three built-in operating modes, for users to choose under different usage scenarios, when any mode is chosen; the background of the icon will become green. Mode Description In Hand/Rain mode the touchscreen rejects false inputs from liquid drops. -
Page 15: Chapter 6: Basic Troubleshooting
Chapter 6: Basic Troubleshooting Chapter 6: Basic Troubleshooting Problem Solution The removable battery is Make sure the AC adapter is properly connected, and that the removable not charging. battery is properly inserted. Nothing appears on the The tablet computer may be in sleep mode. Press the power button to wake screen. - Page 16 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © 2018 Winmate Inc. All rights reserved.
