Navi-xs User's Guide
(i) Before running the software, make sure that your PC is recognizing the
(ii) Click the icon on toolbar by the up-down button (marked button in
(iii) The output messages can be displayed in the Development Data screen.
This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission.
NAVI-XS properly. On the activated Data Source Setup window, select
the COM (e.g. COM9) for SiRFdemo program and set the baud rate
e.g. to 38400 bps. See figure below:
figure below) the program will automatically detect the selected COM
port and starts evaluating.
For a description of NMEA messages please download from Falcom's
Website the "SiRFmessages.pdf" file. The valid/invalid protocols can be
recognized on the $GPRMC protocol as shown in figure below. The
capital letter means, incoming protocols are valid and the capital
A
letter means, incoming protocols are invalid.
V
