Navi-xs User's Guide
4.2.1.4
4.2.1.5
4.2.1.6
4.2.1.7
4.2.1.8
4.2.1.9
4.2.1.10
This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission.

Time to First Position

Snap start
Hot start
Warm start
Cold start

Sensitivity

Hot Start
Warm Start
Cold Start

Dynamic Conditions

Altitude
Velocity
Acceleration
Jerk

DC Power

Power
Operating time
Bluetooth™ Serial Port
Connection :
Protocol messages:
Serial port settings:

Physical

♦ Dimensions:
♦ Weight:

Software

♦ Operating firmware:
< 3 sec., average
< 8 sec., average
< 35 sec., average
< 45 sec., average
23 dBHz
28 dBHz
16 dBHz
18,000 meters (60,000 feet) max.
< 515 meters/second (1000 knots) max.
4 g, max.
20 meters/second³, max.
From two rechargeable NiMH batteries, 2 x
1.2V DC and a capacity of 1000 mA/h inside
the unit.
Default operating time is minimum 6-7 hours
after full charged.
Communicate with
Bluetooth™ (Class 2) Serial Port Profile.
NMEA, Msg.: GSV (1 x ), RMC (1 x ), GLL (1 x )
GGA (1 x) and GSA (1 x )
Baud Rate: up to 115200 bps (default
factory setting is 38400 bps)
Data bits: 8
Parity: NO
Stop bit: 1
Flow control: NO
66 mm x 46 mm x 20 mm (L x B x H)
65 gr.
XTrac-2.2.0
Version 1.01
Host Platform via
Page 12
