FEATURES:
Processor/Cache:
Processor
Upgrades
Cache
Size
System Memory
Memory Size
Memory Sites
ECC/EC
DIMM Type
Memory Speed
Chipset
ISA/PCI Bus
Graphics Support
"AGP"
Video Memory
Memory Capacity
Integrated I/O
I/O Controller
Infrared Interface Infrared port with FIR, IrDA and ASKIR
Parallel Port
Hard Disk Controller
Hard Disk Connector
Floppy Controller 720 KB, 1.2, 1.44 and 2.88 MB support in non-FIR mode
Keyboard Port
Mouse Port
Real Time Clock
System Monitor
External Communication Ports
Serial Bus
BCM Advanced Research
Intel "Deschutes", "Klamath", Celeron" Pentium II 233 ~ 333 MHz Operation with
FSB (Front Side Bus) 66 MHz
Slot 1
CPU Cartridge Integrated; Write Back and Write Through, direct mapped
organization "BSB" Cache
0KB or 512KB
8MB Min up to 256MB with Un-buffered SDRAM
2 DIMM Sockets. SDRAM. Auto-detect w/Table Free Configuration Double
Density DIMMs.
Non-ECC support.
8, 16, 32, 64 and 128MB. 64-bit non-ECC
SDRAM 66Mhz parameter for synchronous memory.
82440EX AGP/PCI/ISA Chipset
PCI Level 2.1. 33 MHz Zero Wait State
ATI 3D Rage Pro Turbo 2X or Rage IIC, 66MHz AGP with sidebands and
pipelining 64-bit PCI Graphics Accelerator.
SGRAM @ 66MHz (128Kx32 or 256Kx32x2)
2MB or 4MB on the motherboard
Winbond W83977TF (Plug & Play Compliant) Serial Ports One 9 pin connectors for
dual asynchronous serial ports. High speed 16C550 compatible serial ports.
One 25 pin supporting EPP, ECP and Centronics Interface
PCI Bus Mastering IDE. Native and Compatible Mode Support. IDE Transfer with
Scatter Gather. "Ultra 33" Synchronous DMA. Enhanced IDE PIO mode 4
(16MB/s) Independent IDE timing. FIFOs for PCI Burst Transfers.
Swap-Bay Support. Integrated 8x32-bit buffer for IDE PCI Burst Transfers
2 PCI IDE Connectors for 4 Drives Support
PS/2 (Integrated in the FDC37C77X)
PS/2 (Integrated in the FDC37C77X)
Integrated in the PIIX4 (DS1287 Compatible)
Winbond W83781D; Voltage/Temperature/Fan Speed/Chassis Intrusion
Universal Serial Bus (USB), integrated with Core Logic
,
9
