- Page 1 Advanced Socket 370 Motherboard FX816ELV User’s Manual http://www.bcmcom.com...
-
Page 2: Declaration
Declaration Rights: No part of this manual, including but not limited to the products and software described in it, may be reproduced, transmitted, transcribes, stored in a retrieval system, or translated in any form or by any means without the expressed written permission from the manufacturer. Products and corporate names appearing in this manual may or may not be registered trademarks or copyrights of their respective companies and are used only for identification or explanation purposes without intent to infringe. -
Page 3: Compliance & Certificate
Compliance & Certificate & & ISO 9001 Certificate: This device was produced in our plant with advanced quality system certified by DNV QA Ltd. in according to ISO 9001. This Certificate is valid for: DESIGN & MANUFACTURE OF MOTHERBOARD AND PERSONAL COMPUTERS. CE Declaration: CE marking is a visible declaration by the manufacturer or his authorized representatives that the electrical equipment to which it relates satisfies all the provisions of the 1994... -
Page 4: Easy Installation
Easy Installation Easy Installation Steps The following “Easy Installation” steps are for users accustomed to the assembly of a computer system. For those individuals requiring more specific information, please refer to the more detailed descriptions located within the latter chapters of this manual. -
Page 5: Table Of Contents
Table of Contents Declaration....................... 2 Compliance & Certificate ..................3 Easy Installation...................... 4 1. Introduction ......................6 1.1 How To Use This Manual ................6 1.2 Check Your Device Items ................6 2. Features ....................... 7 2.1 Features Of The Motherboard ................. 7 3. -
Page 6: Introduction
Introduction 1.1 How To Use This Manual This manual provides information necessary for Original USER MANUAL Equipment Manufactures (OEMs) and home users to build for ATX compatible system using Intel Socket 370 CPU motherboard. Follow the installation procedure presented on the Easy Installation Page and refer to the section number following each step if you require more detailed instructions. -
Page 7: Features
Features 2.1 Features Of The Motherboard This product is based on the Flex ATX form factor. It features the advanced multimedia function and provides support for business PC maker. This motherboard incorporates Intel 815 chipset. Providing features such as integrated 2D/3D AGP VGA controller with AGP In-Line Memory Module, DVO Pin Header, Ultra DMA 33/66 IDE interface, ACPI Power Management, 10/100Mbps LAN, USB, IEEE 1394 connectivity, and soft sound support. - Page 8 Features Integrated I/O Winbond W83627HF AW super I/O controller 1 Parallel Port (SPP/ECP/EPP/ECP+EPP) 2 Serial Port (16C550 Fast UART Compatible – 115kbps) 1 PS/2 Mouse Port 1 PS/2 Keyboard Port 1 Floppy connector 4 Standard USB Ports (2 from the header connector and 2 from the back ports) 2 Fan connectors Hardware Monitor Capability (optional) 2 IEEE 1394 Ports (1 from the header connector)
-
Page 9: Installation
Installation 3.1 Motherboard Layout & Main Parts Keyboard/Mouse Printer Mic-In Line-Out COM 2 COM 1 LAN/USB 1394 LAN LED Front 1394 DVO Pin Header Floppy CPU Socket PCI Slot Front USB CPU Fan Front Panel DIMM 1 Connector DIMM 2 Secondary Primary ATX Power... - Page 10 Installation Significant Parts List Expansion Slots Refer to Sec. 3.3 System Memory Refer to Sec. 3.4 Expansion Slots Refer to Sec. 3.5 Front Panel Connectors/Back Panel Ports IrDA Connector (Part of Front Panel Header) Refer to Sec. 3.6.5 Power Switch Connector (Part of Front Panel Header) Refer to Sec.
- Page 11 Installation Precaution Before Start Static Electricity Damage: Static electricity can easily damage your motherboard. Observing a few basic precautions can help safeguard against damage that could result in expensive repairs. Follow the simple measures below to protect your equipment from static electricity damage. Keep the motherboard and other system components in their anti-static packaging until you are ready to install them.
-
Page 12: Connectors And Jumpers
Installation 3.2 Connectors and Jumpers This motherboard requires jumper setting for some features. The following graphic shows you how to set a proper jumper setting. PIN 1 PIN 1 Note: In the following pages, the triangle mark stands for pin 1 of the connector or header. Connectors/Jumpers List J1: Mic-In J2: Line-Out... -
Page 13: Cpu (Central Processing Unit)
Installation 3.3 CPU (Central Processing Unit) This motherboard supports a Flip-Chip PGA 370 Intel Celeron/Pentium III FC-PGA family processor. To complete CPU installation, please install CPU to socket firmly, presented in Sec. 3.3.1. 3.3.1 CPU installation Please follow the below steps to install your CPU. Step 1: Pull the handling bar of the socket upward to the other end to loosen the socket’s openings. -
Page 14: System Memory (Dram)
Installation 3.4 System Memory (DRAM) 3.4.1 DIMM (Dual Inline Memory Module) The motherboard features two 168-pin DIMM sockets, share memory module. If you have only one DIMM RAM, note that you must insert it into DIMM 1. You can configure the system memory size from 16MB to 512MB in a variety of ways by using different combinations of the three 168-pin DIMMs. -
Page 15: Expansion Slots
Installation 3.5 Expansion Slot This motherboard contains 1 32-bit PCI expansion slot. PCI Expansion Slot PCI expansion slot accept PCI bus master cards and are fully supported by the PCI 2.2 specification. -
Page 16: Connectors, Headers, And Ports
Installation 3.6 Connectors, Headers, and Ports This motherboard contains IDE, floppy, power connector, front panel, and additional connectors. 3.6.1 Primary IDE Connector (J27, 39-pin block, Black) This connector supports two primary channel IDE devices as well as the LS120 floppy, Zip, CD- ROM, and DVD-ROM drives via a ribbon cable. - Page 17 Installation The motherboard supports one 2-pin connector for connecting to front Panel Hard Disk activity LED indicator. Power Switch Connector (Pins 17, and 19) This connector supports the ATX case-mounted Power Switch, which in turn supports System Suspend function. When the BIOS sets the Power Button function to “Suspend”, the system can be set to the suspended mode once you push the power switch for no longer than 4 seconds.
- Page 18 Installation COM1 Port (J6) The motherboard has one serial port. The electrical characteristics are compliant with the EIA- 232-D Serial Communications Specifications. The serial port may be disabled through the BIOS. Line-Out (J2) The motherboard also provides external sound system through an user accessible stereo jack connector soldered to the PWA.
- Page 19 Installation A connector is available for audio input from Line-In, Mic-In Header. Line-Out Header (J9, 5-pin) A connector is available for audio output. BIOS Lock Header (JP2, 4-pin) When 1,2 close, boot block protection enable, 3,4 close all block protection enable. Default is 2,3 for all un-protect.
- Page 20 Installation Are You Ready To Turn On The System? Check Again Is the CPU installed exactly and firmly into the socket (Sec. 3.3)? Are all the DRAM modules installed properly (Sec. 3.4)? Are all the add-in peripheral seated and configured properly (Sec. 3.5)? Are you sure that all the connectors (described in Sec.
-
Page 21: Bios Setup
BIOS Setup The motherboard uses Whizpro BIOS, stored in a flash EEPROM. All of the configuration information is stored in the CMOS. 4.1 BIOS Setup The Whizpro BIOS is immediately activated when you first turn on the computer. The BIOS reads system configuration information in CMOS RAM and begins the process of checking the system and configuring it through the Power-On-Self-Test (POST). -
Page 22: Main Setup Menu
BIOS Setup 4.2 Main Setup Menu When you enter the Whizpro BIOS CMOS Setup Utility, a Main Menu appears on the screen. The Main Menu allows you to select from several Setup functions and two exit choices. Use the arrow keys to select among the items and press <ENTER> key to enter the sub-menu. A brief description of each highlighted selection appears at the bottom of the screen. -
Page 23: General Configuration Menu
BIOS Setup 4.3 General Configuration Menu In the Standard CMOS Menu, you can set the system clock and calendar, record disk drive parameters and the video subsystem type, and select the type of errors that stop the BIOS POST. 4.3.1 Date The BIOS determines the day of the week from the other date information. - Page 24 BIOS Setup 4.3.4 First Boot Device This option sets the type of device for the first boot drives that the BIOS attempts to boot from after BIOS Post completes. 4.3.5 Second Boot Device This option sets the type of device for the second boot drives that the BIOS attempts to boot from after BIOS Post completes.
-
Page 25: Advanced Configuration Menu
BIOS Setup 4.4 Advanced Configuration Menu These screens contain industry-standard options additional to the core PC AT BIOS. This section describes all fields offered by Whizpro Software in this screen. Some fields may vary from those in your Setup program. Your system builder may omit or modify some fields. 4.4.1 IDE Drive Delay Configure IDE drive delay. - Page 26 BIOS Setup 4.4.12 Typematic Rate Setting When disabled, the following two items (Typematic Rate and Typematic Delay) are irrelevant. Keystrokes repeat at a rate determined by the keyboard controller in your system. When enabled, you can select a typematic rate and typematic delay. 4.4.13 Typematic Rate (Chars/Sec) When the typematic rate setting is enabled, you can select a typematic rate (the rate at which character repeats when you hold down a key) of 6, 8, 10, 12, 15, 20, 24, or 30 characters per...
-
Page 27: System Specific Setup
BIOS Setup 4.5 System Specific Setup 4.5.1 Auto DIMM and PCI Clock Enable will disconnect clock signals that go to unused DIMMs and PCI slots. -
Page 28: Primary Ide Drives
BIOS Setup 4.6 Primary IDE Drives 4.6.1 Primary Master Select Auto BIOS will detects if a drive is installed and its CHS parameters. If Manual is select, CHS parameters needs to be insert manually. Select None for no IDE drive installed. Drive Type: None No IDE drive is installed... -
Page 29: Secondary Ide Drives
BIOS Setup 4.7 Secondary IDE Drives 4.7.1 Secondary Master Select Auto BIOS will detects if a drive is installed and its CHS parameters. If Manual is select, CHS parameters needs to be manually insert. Select None for no IDE drive installed Drive Type: None No IDE drive is installed... -
Page 30: Peripherals Setup Menu
BIOS Setup 4.8 Peripherals Setup Menu 4.8.1 Floppy Controller Set this option to enable to invoke the floppy drive controller on the motherboard. 4.8.2 Primary IDE Set this option to enable to invoke the Primary IDE channel on the motherboard. 4.8.3 Secondary IDE Set this option to enable to invoke the Secondary IDE channel on the motherboard. -
Page 31: Power Management Setup Menu
BIOS Setup Select allow to set UART mode or IRDA mode. 4.8.6 Parallel Port This option allows to set parallel port configuration. Set to I/O address 3BC IRQ5 Set to I/O address 278 IRQ5 Set to I/O address 378 IRQ5 Set to I/O address 3BC IRQ7 Mode The parallel port can be used with devices that adhere to Standard (SPP) or Enhanced Parallel... - Page 32 BIOS Setup 4.9.1 Power Management Disable No power management. Allows operating system to use APM (Advanced Power Management) mode for power management. ACPI ACPI (Advanced Configuration and Power Interface) evolves the existing motherboard configuration interfaces to support these advanced architectures in a more robust, and potentially more efficient manner.
- Page 33 BIOS Setup 4.9.7 Video Off Set system inactivity time period before BIOS turn off video in APM mode. 4.9.8 Power Button In case of computer being “hung”: Instant-Off allows the power button to shut down the system instantly by the push of the button; Delay 4 Sec. allows the power button to shut down the system after holding the button for 4 seconds.
-
Page 34: Pci /Pnp Configurations Menu
BIOS Setup 4.10 PCI /PnP Configurations Menu 4.10.1 PnP OS Installed Set this option to “Yes” to inform BIOS the operating system can handle plug and play (PnP) devices. 4.10.2 Reset Configure Data Select Enabled to reset Extended System Configuration Date (ESCD) when you exit Setup if you have installed a new add-on and the system reconfiguration has caused such a serious conflict that the operating system cannot boot. -
Page 35: Hardware Monitor
BIOS Setup 4.11 Hardware Monitor 4.11.1 CPU Voltage Display current CPU Vcore voltage. 4.11.2 FSB Voltage Display current FSB voltage. 4.11.3 3.3 Volt Display current 3.3 volt. 4.11.4 5.0 Volt Display current 5 volt. 4.11.5 12 Volt Display current 12 volt. 4.11.6 -12 Volt Display current -12 volt. -
Page 36: Restore Default Settings
BIOS Setup 4.12 Restore Default Settings 4.12.1 Restore Manufacture Settings Restore manufacture settings to recover the optimum settings for the original manufacture configuration. 4.11.2 Restore Fail-Safe Settings Load Fail-Safe settings when you can not boot the system to operating system after change/ add/ remove hardware parts or peripherals. -
Page 37: Troubleshooting
Troubleshooting 5.1 General Troubleshooting Tips Is your system properly assembled and configured? Make sure the BIOS setup is set to default/optimal settings. Pressing <F2> or <DEL> key to enter the setup, select Default or Optimal settings, then save and exit the setup. For Windows 2000, that requires ACPI support, make sure your BIOS is of the latest revision (Some EOL boards will not support it at all). - Page 38 Troubleshooting If you have extra peripherals or components, please do some swapping at a bare setup to narrow down the fault. If the fault is the motherboard and you are certain of it and with all exhaustive attempts to get it to work even at bare minimum and with slowest speed setup, then it may require a repair or a replacement.
