INSTALLATION AND OPERATION MANUAL
AMC+ MIX

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AMC+ MIX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AUSTRALIAN MONITOR AMC+ MIX

Summary of Contents for AUSTRALIAN MONITOR AMC+ MIX

  • Page 1 INSTALLATION AND OPERATION MANUAL AMC+ MIX...

  • Page 2: Important Safety Information

    Do not parallel- or series-connect an amplifier output with any other 32. To be completely disconnect the power input, the mains plug of AC/AC amplifier output. Australian Monitor Inc is not responsible for damage to adaptor shall be disconnected from the mains .

  • Page 3: Introduction And Contents

    INSTALLATION The AMC+ Mix is a 1 RU mixer with 4 universal mic/line inputs. TROUBLESHOOTING AND BLOCK DIAGRAM Master volume and overall treble and bass controls are provided,...

  • Page 4: Front Panel

    FRONT PANEL CH 1–4 These control the levels for each channel input. Bass There is 12dB of cut and boost at 100Hz. Treble There is 9dB of cut and boost at 10kHz. Master This controls the overall mixed output level. This LED indicates the unit is powered “on”.

  • Page 5: Rear Panel

    These terminals are for use with an optional tone module (not supplied). microphone input. It has an input sensitivity of 1mV. RCA input – This is an Use Australian Monitor ATC5488 module. unbalanced line level input. It has an input sensitivity of 150mV. The two RCA sockets are summed to mono internally.

  • Page 6: Installation

    INSTALLATION Mounting Montage Your amplifier is designed for standard 19” rack mounting and occupies 2 EIA Cet ampli convient pour un montage en rack de 19” et a 2 unités de 3.5”. rackunits (3.5”). Les centres de montage sont: The mounting centres are: Vertical: 1.5”...

  • Page 7: Troubleshooting Guide

    TROUBLESHOOTING AND BLOCK DIAGRAM TROUBLESHOOTING GUIDE Trouble Likely Cause Remedy Power LED not on Check power switch is on Check plug pack connection Distorted sound Input is overloaded Reduce input level at source Output is being over driven Reduce volume levels on front panel Bass control is turned up Reduce Bass control level No sound but mixer is on...
  • Page 8 FUNCTIONAL NOTES AND INTERNAL ADJUSTMENTS Priority Channel 1 will mute channels 2, 3 and 4. This will only occur when signal appears on channel 1, irrespective of the channel volume control. Priority can be disabled. (See below). The release time is approx. 3 secs and is NOT adjustable. The mute depth is approx.
  • Page 9 DIMENSIONS MIX INSTALLATION AND OPERATION MANUAL PAGE 9...

  • Page 10: Specifications

    SPECIFICATIONS Frequency Response 20Hz - 20kHz (+0,-3dB) Total Harmonic Distortion < 0.5% @ 1kHz Signal To Noise Ratio > 84dB (all pots at centre position) Crosstalk > 60dB Tone Controls Bass @ 100Hz +/- 12dB Treble @ 10kHz +/- 9dB Sensitivity Mic Sens 0.7mV, -61dBu Imp 1k3ohm RCA 150mV, -4dBu Imp >100kohm...
  • Page 11 NOTES MIX INSTALLATION AND OPERATION MANUAL PAGE 11...
  • Page 12 ENGINEERED BY AUSTRALIAN MONITOR Address: 1 Clyde Street, Silverwater, Sydney NSW 2128 Australia. Private Bag 149, Silverwater NSW 1811 ACN 007 573 417 Website: www.australianmonitor.com.au International enquiries email: international@australianmonitor.com.au DISTRIBUTED IN AUSTRALIA AND NEW ZEALAND BY HILLS SVL www.hillssvl.com.au P: 02 9647 1411...
