INSTALLATION AND OPERATION MANUAL
AMC+ MIX
4 INPUT MICROPHONE/LINE MIXER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AMC+ MIX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AUSTRALIAN MONITOR AMC+ MIX

Summary of Contents for AUSTRALIAN MONITOR AMC+ MIX

  • Page 1 INSTALLATION AND OPERATION MANUAL AMC+ MIX 4 INPUT MICROPHONE/LINE MIXER...

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION PRÉCAUTIONS DURANT UTILISATION LISEZ ces instructions. Read these instructions. Tenez ces instructions. Keep these instructions. Notez tous les avertissements. Heed all warnings. Suivez toutes les avertissements. Follow all instructions. N’utilisez pas ce produit près de l’eau (la piscine, la plage, le lac, etc.). Do not use this apparatus near water.

  • Page 3: Introduction And Contents

    INSTALLATION The AMC+ Mix is a 1 RU mixer with 4 universal mic/line inputs. TROUBLESHOOTING AND BLOCK DIAGRAM Master volume and overall treble and bass controls are provided,...

  • Page 4: Front Panel

    FRONT PANEL CH 1–4 These control the levels for each channel input. Bass There is 12dB of cut and boost at 100Hz. Treble There is 9dB of cut and boost at 10kHz. Master This controls the overall mixed output level. On Indicator This LED indicates the unit is powered “on”.

  • Page 5: Rear Panel

    These terminals are for use with an optional tone module (not supplied). microphone input. It has an input sensitivity of 1mV. RCA input – This is an Use Australian Monitor ATC5488 module. unbalanced line level input. It has an input sensitivity of 150mV. The two RCA sockets are summed to mono internally.

  • Page 6: Installation

    INSTALLATION Mounting Montage Your amplifier is designed for standard 19” rack mounting and occupies 1 EIA Cet ampli convient pour un montage en rack de 19” et a 1 unité de 1.75”. rackunit (1.75”). Les centres de montage sont: The mounting centres are: Vertical: 1.5”...

  • Page 7: Troubleshooting Guide

    TROUBLESHOOTING AND BLOCK DIAGRAM TROUBLESHOOTING GUIDE Trouble Likely Cause Remedy Power LED not on Check power switch is on Check plug pack connection Distorted sound Input is overloaded Reduce input level at source Output is being over driven Reduce volume levels on front panel Bass control is turned up Reduce Bass control level No sound but mixer is on...
  • Page 8 FUNCTIONAL NOTES AND INTERNAL ADJUSTMENTS Priority Channel 1 will mute channels 2, 3 and 4. This will only occur when signal appears on channel 1, irrespective of the channel volume control. Priority can be disabled. (See below). The release time is approx. 3 secs and is NOT adjustable. The mute depth is approx.
  • Page 9 DIMENSIONS AMC + MIX INSTALLATION AND OPERATION MANUAL PAGE 9...

  • Page 10: Specifications

    SPECIFICATIONS FREQUENCY RESPONSE 20Hz - 20kHz (+0,-3dB) TOTAL HARMONIC DISTORTION < 0.5% @ 1kHz SIGNAL TO NOISE RATIO > 84dB (all pots at centre position) CROSSTALK > 60dB TONE CONTROLS Bass @ 100HZ +/- 12dB Treble @ 10KHZ +/- 10dB SENSITIVITY Mic Sens 1mV, -61dBu Imp 1k3ohm RCA 150mV, -4dBu Imp >100kohm...
  • Page 11 NOTES AMC + MIX INSTALLATION AND OPERATION MANUAL PAGE 11...
  • Page 12 ENGINEERED BY AUSTRALIAN MONITOR Address: Level 7, 130 Pitt Street, Sydney NSW 2000 Australia. Website: www.australianmonitor.com.au International enquiries email: international@australianmonitor.com.au...
