5.2.2

Ethernet Port Status

Click Left side Alarm Status – ETH Port will show 4 Ethernet electrical ports
and 1 optical port LINK UP/DOWN stats, as shown in Fig5.2-2.
5.2.3

Power Status

Click left side Alarm Status – Power Status will show Power Alarm Status,
include 2 power ad Status information, as shown in Fig 5.2-3.
5.2.4

Alarm Log

Click Left side Alarm Status – Alarm Log, include Alarm Type, Alarm Item,
Port number, time. As shown in Fig 5.2-4.
AD-net Technology., CO LTD
图 5.2-1 E1 Alarm Status
Fig 5.5-2 ETH port Alarm Status
Fig 5.2-3 Power Status
Fig 5.2-4 Alarm Log
