Manuel de l'usager du Mux IP vers 2xE1
AN-TDM-IP-1 / 2 E1 A
E1/T1 over Ethernet Multiplexer
User's Manual
AD-net Technology., LTD
contents -1-
www.hypercable.fr

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AN-TDM-IP-1E1/2E1-A and is the answer not in the manual?

Questions and answers

Summary of Contents for AD-net Technology AN-TDM-IP-1E1/2E1-A

  • Page 1 Manuel de l'usager du Mux IP vers 2xE1 AN-TDM-IP-1 / 2 E1 A E1/T1 over Ethernet Multiplexer User’s Manual AD-net Technology., LTD contents -1- www.hypercable.fr...
  • Page 2: Contents

    Manuel de l'usager du Mux IP vers 2xE1 AN-TDM-IP-1E1/2E1-A E1/T1 over Ethernet Multiplexer User’s Manual AD-net Technology., LTD 2012.03 contents -2- www.hypercable.fr...
  • Page 3 Disclaimer The information contained in this document is subject to change without notice and does not represent a commitment on the part of AD-net Technology., co LTD (AD-net). The information in this document is believed to be accurate and reliable; however, AD-net assumes no responsibility or liability for any errors or inaccuracies that may appear in the document.
  • Page 4: Table Of Contents

    Manuel de l'usager du Mux IP vers 2xE1 TABLE OF CONTENTS GENERAL...................1 1.1 O ....................1 VERVIEW 1.2 F .....................1 EATURES 1.3 A ..................1 PPLICATIONS 1.4 T ..................2 IMING MODES SYSTEM ARCHITECTURE............4 2.1 F ................4 UNCTION ESCRIPTION 2.2 S ...................5 TRUCTURE 2.3 F ..................5 RONT PANEL...
  • Page 5 Manuel de l'usager du Mux IP vers 2xE1 5.3.1 Alarm Shielding Management .............16 5.4 E ..............16 THERNET ANAGEMENT 5.4.1 Ethernet Management ..............17 5.4.2 Ethernet Senior Management ............18 5.4.3 VLAN Management ..............19 5.5 E1 M ................21 ANAGEMENT 5.5.1 E1 Service Management..............21 5.5.2 E1 Senior Management ...............22 5.6 SNMP M...
  • Page 6 Manuel de l'usager du Mux IP vers 2xE1 www.hypercable.fr...
  • Page 7: General

    Overview Thank you for selecting the AN-TDM-IP-1E1/2E1-A E1/T1 over Ethernet multiplexer product designed and made by AD-net Technology., LTD The product adopt the innovative TDM over IP technology, with IP circuit emulation that supports transportation of 1~2 E1 /T1 over FE port, that can be used to provide E1 communication channels over Ethernet or IP networks.
  • Page 8: Timing Modes

    1.4 Timing modes To emulate a transparent E1 channel over a packet network, the AN-TDM-IP-1E1/2E1-A not only conveys data stream content correctly from the source to the destination, but also recovers the E1/T1 timing from the source at the - 2 - www.ad-net.com.tw...
  • Page 9 (such as PBX remote module or PCM terminal) to adaptive mode, is probably better than setting both to adaptive modes. It’s better to set the both sides AN-TDM-IP-1E1/2E1-A to loop back timing mode when the both sides equipments synchronous master clock.
  • Page 10: System Architecture

    System Architecture Function Description The core of AN-TDM-IP-1E1/2E1-A is the TDM/Packet processing unit. It truncates E1/T1 data stream, and encapsulates the data into Ethernet packet with or without IP headers. The packets are passed to the Ethernet switch unit via MII interface, and are sent out through the uplink ports.
  • Page 11: Structure

    Manuel de l'usager du Mux IP vers 2xE1 AD-net Technology., CO LTD 2.2 Structure AN-TDM-IP-1E1/2E1-A adopt standard 1U box (W x H x D: 195 mm×35 mm×140 mm), which is composed by system board and power supply card. AN-TDM-IP-1E1/2E1-A system structure is shown in Fig 2.2-1: Fig 2.2-1 AN-TDM-IP-1E1/2E1-A system structure...
  • Page 12: Led's

    Manuel de l'usager du Mux IP vers 2xE1 AD-net Technology. CO LTD 2.3.2 LED’s The definition is shown in Table 2.3.2-1: Table 2.3.2-1 the indicators definition of AN-TDM-IP-1E1/2E1-A Identification Color Quantity Definition Remark System working state instructions Blink: Normal Green...
  • Page 13: Dip Switches Definition

    Manuel de l'usager du Mux IP vers 2xE1 AD-net Technology., CO LTD 1 ~ 2 channel E1 / T1 addressing the remote equipment link state FAR-END instructions Green On: Addressing the remote MAC address Off: unaddressing the remote MAC address...
  • Page 14: E1/T1 Port

    Manuel de l'usager du Mux IP vers 2xE1 AD-net Technology. CO LTD OFF: use the user’s Setting IP address There are 4 group dips on the bottom of panel, used for controlling the E1 / T1 interface impedance and 75 unbalanced interface shell grounding, as the Table 2.3-3.
  • Page 15: Ethernet Ports

    Manuel de l'usager du Mux IP vers 2xE1 AD-net Technology., CO LTD Adopt 75 E1/T1 unbalanced interface, can be used for BH4.815.122 conversion cable which convert RJ45 to BNC connector. Fig 2.3-6 75 dedicated cable E1/T1 interface provide Rx Tx 、 Tx Rx loop back operation through network management , it is convenient for operating and maintain test .
  • Page 16: Power Switch And Power Socket

    Fig 3.1.-1: Fig 3.1-1 E1/T1 loop back Rx Tx can test E1/T1 connection cable, and Tx Rx is used to test the whole circuit including AN-TDM-IP-1E1/2E1-A in the two ends and the link between them. - 10 - www.ad-net.com.tw www.hypercable.fr...
  • Page 17: Ethernet/Optic Fiber Connections

    AD-net Technology., CO LTD 3.2 Ethernet/optic fiber connections AN-TDM-IP-1E1/2E1-A provides four 100Base-Tx Ethernet electrical interfaces (two ports are uplink ports used to connect with transmission network and the other two are local data ports used to connect with local Ethernet), and one 100Base-Fx optical interface used as either uplink port or local Ethernet port such as switch.
  • Page 18: Sys Led Does Not Blink

    Manuel de l'usager du Mux IP vers 2xE1 AD-net Technology. CO LTD complete plugged in or not connected with, please check the following subject: the power supply to meet the requirements or not, the power plug is connected, the switch is open.
  • Page 19: Two Ends Devices Cannot Connect

    Check both sides devices AN-TDM-IP-1E1 E1/T1 clock setting, at least one of device should be Master-Clock. Check AN-TDM-IP-1E1/2E1-A time mode setting. If both sides of the E1/T1 equipment are not in the state of the synchronization, units timing model must be adaptive timing, not loop timing.
  • Page 20: System Info

    Manuel de l'usager du Mux IP vers 2xE1 AD-net Technology. CO LTD All Web Server include 7 parts: System Info, Alarm Status, Alarm Management, ETH Management, E1 Management, SNMP Management, and System. Following will introduce Server Management AN-TDM-IP-1E1/2E1-A. System Info After login Web Server, will show Welcome page.
  • Page 21: Ethernet Port Status

    Manuel de l'usager du Mux IP vers 2xE1 AD-net Technology., CO LTD 图 5.2-1 E1 Alarm Status 5.2.2 Ethernet Port Status Click Left side Alarm Status – ETH Port will show 4 Ethernet electrical ports and 1 optical port LINK UP/DOWN stats, as shown in Fig5.2-2.
  • Page 22: Ber Test

    Manuel de l'usager du Mux IP vers 2xE1 AD-net Technology. CO LTD 5.2.5 BER Test Click BER Test will show picture as below, include BER Enable, Testing Port, Start and Stop, Port Status (Frame synchronization or Frame Desynchronization), Bit Error Rate and Error timing, as shown in Fig 5.1-5. If you need test Error for one link, first you should click “enable”...
  • Page 23: Ethernet Management

    Manuel de l'usager du Mux IP vers 2xE1 AD-net Technology., CO LTD (MAC address aging time, QoS management and port Throughput limiting) and VLAN management. Management 5.4.1 Ethernet Fig.5.4-1 Ethernet Management Table 5.4-1 Ethernet management parameters Parameters Options Explanation 5 Ethernet ports number Port Ethernet service No.: support at most 15...
  • Page 24: Ethernet Senior Management

    Manuel de l'usager du Mux IP vers 2xE1 AD-net Technology. CO LTD Senior Management 5.4.2 Ethernet Ethernet senior management supports MAC address aging time, Ethernet port QoS management and throughput limiting. MAC address aging time range is 0~99999 s (default: 300s).
  • Page 25: Vlan Management

    Fig 5.4-5 uplink 1+1 protect configuration Fig 5.4-6 configure Q in Q VLAN automatically AN-TDM-IP-1E1/2E1-A Ethernet supports 802.1 Q VLAN and Q in Q VLAN. 802.1Q VLAN is that adding the VLAN tag in front of Ethernet frame type. Q in Q VLAN is that nesting the VLAN (S-Tag) of operators in 802.1Q outer layer to enable the VLAN stacking.
  • Page 26 Manuel de l'usager du Mux IP vers 2xE1 AD-net Technology. CO LTD Fig 5.4-9 VLAN management 3—Ethernet port configuration Fig 5.4-10 VLAN management 4—VLAN Table Fig 5.4-11 VLAN management 5—VLAN configuration confirmation Table 5.4-3 VLAN management parameters Parameters Options Explanation...
  • Page 27: E1 Management

    Manuel de l'usager du Mux IP vers 2xE1 AD-net Technology., CO LTD Parameters Options Explanation VLAN VLAN ID, support 4094 VLAN, ID, range Configuration (1-4094) Define customer priority, including 8 PRI Priority degrees (0-7). PRI is higher when this number is bigger.
  • Page 28: E1 Senior Management

    Manuel de l'usager du Mux IP vers 2xE1 AD-net Technology. CO LTD 5.5.2 E1 Senior Management Fig 5.5-2 E1 channel senior Management Fig 5.5-3 TTL/TOS configuration of E1 channel Management Table 5.5-1 E1 Management parameters Parameters Selections Explanations Service E1 service name Name Enable this E1 channel.
  • Page 29: Snmp Management

    Manuel de l'usager du Mux IP vers 2xE1 AD-net Technology., CO LTD Parameters Selections Explanations Encapsul IP Encapsulation IPv4_UDP ation Every Ethernet packet encapsulation length can 1×128 select 1×128/2×128 字节/4×128 byte. The byte longer the packet is, the more E1 data 2×128...
  • Page 30: System Configuration

    Manuel de l'usager du Mux IP vers 2xE1 AD-net Technology. CO LTD Parameters Option Explanations Configure commands SNMP Write device nodes Community Default: private SNMP Trap Receive commands of Trap Community Default: public communication ports SNMP connecting the devices with...
  • Page 31: Change The Password

    Then we need to restart Web Server. Fig 5.7-3 default parameters recovery AN-TDM-IP-1E1/2E1-A supports changing E1/T1 port number. For example, change AN-TDM-IP-2E1/A E1/T1 port number to 1. It is shown as follows: Step 1. Generate the configuration code by verification code. Input the MAC address of AN-TDM-IP-2E1/A and set E1 number as 1 and then click Generate.
  • Page 32: Upgrade Online

    Fig 5.7-6 change is successful 5.7.4 Upgrade online Both AN-TDM-IP-1E1/2E1-A hardware and software program can be upgraded by ftp. Following will introduce Web Server upgrade online operation. Step 1: Use any FTP tool or input ftp://root:root@192.168.1.2/home/ftp directly in My Computer address bar to access the ftp server. And then copy the - 26 - www.ad-net.com.tw...
  • Page 33 Manuel de l'usager du Mux IP vers 2xE1 AD-net Technology., CO LTD upgrade program to the server, as figure 5.7-7. Note: Hardware program file name is H_Patch.r, and software program file name is S_patch.r. The file name cannot be changed.
  • Page 34: Reboot System

    Manuel de l'usager du Mux IP vers 2xE1 AD-net Technology. CO LTD Fig 5.7-10 upgrade online 4—operate successfully Note: If the power is off during upgrade, it may make equipment not start and need to program procedures with download line.
  • Page 35: Ethernet Port

    Manuel de l'usager du Mux IP vers 2xE1 AD-net Technology., CO LTD H0FL-AN-TDM-IP SA1602: 2 E1/T1 ports 6.3 Ethernet Port Comply with IEEE 802.3、 802.1Q、 802.1ad、 802.1P and relative other protocol. Operating Mode:10M/100M Adaptive, Half/Full Duplex Adaptive MTU: 9720byte Connector:100M Electrical port: RJ45 100M Optical Port: LC Interface no.: 100M Electrical Port:4...
  • Page 36: Appendix

    Manuel de l'usager du Mux IP vers 2xE1 AD-net Technology. CO LTD Appendix Specialized terminologies and acronyms: Acronym Explanations Time Division Multiplex SAToP Structure-Agnostic TDM over Packet DSCP Differentiated Services Code point User Datagram Protocol Quality of Service terms of service...
