2.2 Structure

AN-TDM-IP-1E1/2E1-A adopt standard 1U box (W x H x D: 195 mm×35
mm×140 mm), which is composed by system board and power supply card.
AN-TDM-IP-1E1/2E1-A system structure is shown in Fig 2.2-1:
Fig 2.2-1 AN-TDM-IP-1E1/2E1-A system structure

2.3 Front panel

2.3.1

Diagram

AN-TDM-IP-1E1/2E1-A, all service interface ,power port ,indicators and dips
are in the front of panel , no indicators or dips in the rear panel ,
AN-TDM-IP-1E1/2E1-A front panel is shown in Fig 2.3-1~Fig 2.3-4.
Fig. 2.3-1 Front panel of AN-TDM-IP-1E1/A (DC-48V)
Fig. 2.3-2 Front panel of AN-TDM-IP-1E1/A (AC-220V)
Fig. 2.3-3 Front panel of AN-TDM-IP-2E1/A (DC-48V)
Fig. 2.3-4 Front panel of AN-TDM-IP-2E1/A (DC-48V)
