Rear Entertainment Function; Switching Display Modes - Alpine iXA-W404E Owner's Manual

1
Touch [DX SEEK]* to choose the tuning mode.
2
SEEK * DX SEEK
(MANUAL)
1
* The button displays the current tuning mode.
2
* For detailed operation of the buttons, refer to "Listening to the
Radio" on page 10.
Sound Controller (Sound Cont.)
By this function, you can adjust Treble level, Bass level and Subwoofer
level directly.
Adjusting Treble/Bass
1
Touch the dial of Treble/Bass to adjust the desired
setting level.
Setting contents:
Treble level: -7 ~ +7
Bass level: -7 ~ +7
2
Touch [X] to return to Multi Information main screen.
Adjusting Subwoofer
1
Touch [ ] or [ ] of Subwoofer to adjust the desired
setting level.
Setting contents:
Subwoofer level: 0 ~ 15
2
Touch [X] to return to Multi Information main screen.
• When you return to Multi Information main screen, the adjusted
value of Treble level, Bass level and Subwoofer level will be
displayed.
• This adjustment can also be made as described under "Setting the
Bass level" (page 12), "Setting the Treble Level" (page 12), and
"Adjusting the Subwoofer Level" (page 12).
IMPRINT Controller
When the IMPRINT audio processor (PXA-H100) (sold separately) is
connected to this unit, you can select the MultEQ mode by this function.
1
Touch area to activate MultEQ mode.
A
The indicator lights up and the IMPRINT logo emerges on
the background.
Touching area again will cancel MultEQ mode.
A
IMPRINT logo
2
After the indicator lights up, touch
to Memory 1 (Curve 1) mode and Memory 2 (Curve 2)
mode.
• The above settings can also be made referring to "Changing MultEQ
mode" on page 29.
14
-EN
2 2
* LOCAL SEEK *
Indicator
area to switch
B

Rear Entertainment Function

The rear entertainment function independently routes different sources
to the front and the rear inside a car. For example, while listening to the
radio or other audio source in the front, the video of iPhone/iPod can be
enjoyed in the rear with the optional rear monitor and headphones.
1
Press SOURCE.
The mode switching selection screen is displayed.
2
Touch [RSE].
Rear Select screen appears.
• Touching [ ] will return to mode switching screen.
3
Touch the desired source such as visual (Auxiliary
Output) to select.
• When the "Setting the AUX Mode" (page 19) is set to OFF, the
auxiliary source is not displayed.
• When the "Setting the Picture Output" (page 19) is set to OFF, the
"RSE" item is not displayed.

Switching Display Modes

While your vehicle is parked, touch [WIDE] on the visual
source screen.
Each touch changes the display modes as follows:
MODE 1 MODE 2
(WIDE) (CINEMA)
In Mode 1 (Wide), the monitor displays a normal picture wider to
fit in a wide-screen monitor by evenly stretching out the picture
horizontally.
In Mode 2 (Cinema), the monitor displays a normal picture by
stretching out the picture horizontally and vertically. This mode is
good for displaying a cinema type picture at the 16:9 ratio.
In Mode 3 (Normal), the monitor displays a normal picture at the
centre of the screen with a vertical black band at each side.
MODE 3 MODE 1
(NORMAL) (WIDE)
